MusicMan

MICRO Bluetooth Soundstation BT–X8

User Manual

Declaration of Conformity is under: www.technaxx.de (in bottom bar “Konformitätserklärung”)

Have fun with this speaker in MICRO format and built-in microphone!

Portable Bluetooth speaker system with wireless audio transfer for CD/DVD, iPhone, iPad,

iPod, Mobile phones, Tablet PC, PC/Notebook.

Features

 Easy conection with Bluetooth compatible devices (= Pairing)

 MicroSD card slot bis 32GB and built-in FM radio

 Line–IN 3.5mm for connection to other audio devices

 Built-in hands-free function with built-in microphone

 Built-in rechargable 3.7V lithium 600mAh battery, charging by USB power cable

 Playing time approx. 5 – 6 hours by medium volume

 Changeable silicone sleeves in different colours

 Bluetooth Version 3.0 with 3W output power

 Ideal for traveling, easy installation, excellent sound quality

Product overview

1 Power On / Power Oﬀ / Hands-free

2 3.5mm Line–IN / AUX slot

3 Indicator Light (LED)

4 Micro USB slot to charge the unit

Key Functions

(1)

Power key / Hands-free key: Press the POWER key for 2 seconds to turn ON

the speaker. The user hears a “BEEP” tone when the speaker is turned ON.

The BLUE LED is blinking. To turn the speaker OFF, press the POWER key for

2 seconds. When the BLUE LED turns off, the speaker is also oﬀ.

Users are able to answer an incoming call or hang up a call with pressing the button

/ shortly once when Bluetooth of speaker and mobile phone are connected.

(6)

/

Play key / Pause key: Short press to play or pause music from Bluetooth

devices and MicroSD card. the BLUE LED shines constantly.

While the speaker plays music through Line–IN/AUX, users play or pause

music on their phones, PC, Tablet PC, MP3, MP4 etc.

(7)



 / –

Back key / Volume – key: Short press to go back to the last song, long press

to decrease the volume (VOL–) while playing music through Bluetooth or from

MicroSD card. While playing music through Line–IN/AUX, please control on

the phone, PC, Tablet PC, MP3, MP4 etc.

(8)

＋

＋＋/ 





Forth key / Volume + key: Short press to go forth to the next song, long press

to increase the volume (VOL+) while playing music through Bluetooth or from

MicroSD card. While playing music through Line–IN/AUX, please control on

the phone, PC, Tablet PC, MP3, MP4 etc.

5 Microphone

6 Play / Pause

7 Back / Volume –

8 Forth / Volume +

9 MicroSD card slot

Charging of the battery

Plug in the Micro USB cable* (* included) into the MicroUSB slot (4) of the speaker. Then

connect the USB port to the USB slot of PC or other USB slot of chargers. When the

speaker is being connected, the LED first shines BLUE and then turns to RED. The LED

will shine RED until the speaker is fully charged, and it will turn oﬀ when the speaker is full

charged. (Recommendation: turn OFF the speaker while charging. When it is working, it will

take a longer time to get it fully charged.) Please always fully upload the battery.

Handling the MicroSD card

Turn ON the speaker and insert a MicroSD memory card (up to 32GB, formatted with

windows FAT32 and MP3 tracks are copied on it) into the MicroSD card slot of the speaker

(9). The speaker starts playing automatically.

Handling Bluetooth

Turn ON speaker. Bluetooth works spontaneously, searching previous pairing Bluetooth set.

If the speaker fails to connect, it starts pairing other Bluetooth devices. In this case, turn ON

your Bluetooth device to search the speaker. The PIN code is “ ”, if necessary! The 0000

user hears one signal tone (diﬀerent from “Beep”) when the speaker is connected to

Bluetooth. Music streams after pairing successfully.

When the key / at the speaker is pressed once, both – the speaker and the

connected Bluetooth compatible device – are paused, the BLUE LED lights constantly.

Press the / the speaker starts playing. Press the ＋

＋

＋＋/



 key shortly to move on to

the next song, press it long to increase the volume.

Press the 



/– key shortly to go back to the last song, press it long to decrease volume.

When the speaker is playing from a Bluetooth compatible device (eg. Smartphone)

connected via Bluetooth, the BLUE LED is blinking.

Handling Hands-free

Before using the hands-free function make sure that Bluetooth is connected. When there

are incoming calls, press the / key of the speaker or on your phone (the answer

button) to answer. When the call ﬁnishes, press the / key of the speaker or on your

phone (the hung up button) to hang up.
