Sida 1/4

MusicMan

MIDI Soundstation

Portable Stereo Speaker with built-in MP3 player + FM radio

User Manual

Declaration of Conformity: www.technaxx.de/ (in bottom bar “Konformitätserklärung”)

Features

 Portable stereo speaker for MP3/4, CD/DVD, iPhone, iPad, iPod, PSP, mobile phones,

PC/Notebook

 Built-in MP3 player and stereo FM radio

 Supports USB flash disk and MicroSD memory cards up to 32GB

 Several power supplys: Built-in, rechargable, replaceable lithium-ion 600mAh battery,

computer USB or AC adapter* (*not included)

 Protection grille for the speaker cone

 Playing time approx. 5–6 hours by medium volume

 Lightweight durable aluminum housing

 Ideal for traveling, easiest installation, excellent sound quality

Key Functions

POWER

ON / OFF

Switch the key to the ON position to turn on the device. When the

device is on, the blue LED in its base lights. Switch the key to the OFF

position to turn off the device. IMPORTANT: In case no USB flash disk

or no MicroSD card is plugged in, the device works as FM radio

automatically when turned on.



(Playback /

Pause)

If musik is played from USB flash disk, MicroSD card or through

Line–IN, press the button /



to pause or to keep on with

playback.

In case the device works as FM radio, press the button /



shortly to start the automatic channel search functon and the automatic

channel storing function.

Press the button /



longer to switch between the USB and

MicroSD mode.

VOL +

(Volume + )

Press the button to increase the volume; Press short the button to

increase the volume step by step; Press long the button to increase the

volume gradually.

VOL –

(Volume – )

Press the button to decrease the volume; Press short the button to

decrease the volume step by step; Press long the button to decrease

the volume gradually.



(Forward)

Press the button to move to next song/track.



(Backward)

Press the button to move to last song/track.

Attention: USB / MicroSD / Line–IN



the last used one has priority.

(In case Line–IN is not recognized by the device, activate it with the button /



Change the 600mAh battery

 Open the battery plastic cover on the bottom of the device and remove the old battery.

Insert the new battery with its contacts in correct polarity. Then close the battery cover.

Insert a MicroSD memory card

 The golden contacts must be directed upwards and forwards. Always do the installing

and removing of the MicroSD card with care, otherwise the contacts of the device and/or

the MircoSD card may be damaged.

Play Music

 MP3 files are played in the same order, like they are stored on the USB flash disk or

MicroSD card.

 If music files are stored in different folders, only the files of the first (!) folder will be played.

Neither jumping between the folders, nor selecting a folder is possible.

 If new MP3 files are stored, the device changes the row of music files by itself. You have

no influence on that.

 If the USB flash disk or MicroSD card is removed from the device, and inserted again

later, playback will start with the last MP3 file you heard.

Handling FM radio

Before starting

the FM radio

Plug the equipped USB cable into the ANT slot (antenna slot) for better

reception.



(Play / Pause)

In case the device works as FM radio, press the button /



shortly to start the automatic channel search functon and the automatic

channel storing function (max. 20 stations). If a channel is found, the

device stores this channel automatically and searches for other

stations. The number of stations found is dependent on the strength of

the transmitter signal!

VOL +

(Volume +)

Press the button to increase the volume; Press short the button to

increase the volume step by step; Press long the button to increase the

volume gradually.

VOL –

(Volume –)

Press the button to decrease the volume; Press short the button to

decrease the volume step by step; Press long the button to decrease

the volume gradually.



(Forward)

Press the button to go forward to the next stored FM channel, or to

scan FM channels forward (means, to go step by step to a FM channel

with a higher number).



(Backward)

Press the button to go backwards to the last stored FM channel, or to

scan FM channels backwards (means, to go step by step to a FM

channel with a lower number).

Produktspecifikationer

Varumärke:	Technaxx
Kategori:	dockningshögtalare
Modell:	MusicMan Midi
Produkttyp:	Bärbar stereohögtalare
Vikt:	140 g
Bredd:	80 mm
Djup:	50 mm
Höjd:	53 mm
LED-indikatorer:	Ja
Laddningstid:	4 h
Batterikapacitet:	600 mAh
Volymkontroll:	Digital
FM-radio:	Ja
Rekommenderad användning:	Universal
Impedans:	4 Ω
USB-laddningsport:	Ja
Ljudutgångskanaler:	2.0 kanaler
Antal förare:	2
Total harmonisk distorsion (THD):	10 %
Förstärkare:	Inbyggd
Produktdesign:	Rektangel
Batteriteknik:	Litium-Ion (Li-Ion)
Batterityp:	Inbyggd
Typ av minneskort:	MicroSD (TransFlash)
Produktens färg:	Rosa
Hörlursutgång:	Ja
Vikt inkl. förpackning:	270 g
Antal per förpackning:	1 styck
Inbyggd kortläsare:	Ja
Uteffekt (RMS):	6 W
3,5 mm kontakt:	Ja
Material, hölje:	Gjuten aluminium
Kabel inkluderad:	Audio (3.5mm), USB
Subwooferns högtalarelement, diameter:	44.9 mm
Frekvensområde:	150 - 18000 hz
Anslutningsteknologi:	Kabel
Strömkälla av typen:	Battery, USB
På / av-knapp:	Ja
Antal USB 2.0 anslutningar:	2
USB-laddning:	Ja
Drifttid för batteri:	6 h
Antal talare:	1
Högtalartyp:	1-vägs
Högtalarelement, diameter:	45 mm
Aux-In:	Ja
Signal/brusförhållande (SNR):	80 dB
