Technaxx

* User Manual

HD Outdoor Camera with LED Lamp TX-106

The Declaration of Conformity for this device is under the Internet link:

www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the

device the first time, read the user manual carefully.

Service phone No. for technical support: 01805 012643 (14 cent/minute from

German fixed-line and 42 cent/minute from mobile networks).

Free Email: support@technaxx.de

If you drill a hole in the wall, please make sure that power cables, electrical

cords and/or pipelines are not damaged. When using the supplied mounting

material, we do not take the liability for a professional installation. You are

entirely responsible to ensure that the mounting material is suitable for the

particular masonry, and that the installation is done properly. Also ensure that

the mounting place is strong enough to hold this heavy device. When working

at higher altitudes, there is danger of falling! Therefore, use suitable

safeguards.

Keep this user manual for future reference or product sharing carefully. Do

the same with the original accessories for this product. In case of warranty,

please contact the dealer or the store where you bought this product.

Warranty 2 years

Enjoy your product. Share your experience and opinion on one of the

well-known internet portals.

Features

⚫ Multi functional: video recording with sound, photo, light

⚫ PIR motion detection of 60° angle up to ~7m (open areas)

⚫ PIR trigger time 1–1.5 seconds

⚫ Light in high brightness of 150 lumen (2W) up to ~8m distance

(open areas) & luminous time ~20 seconds

⚫ Alarm at low battery by LED indicator light

⚫ Stand alone device powered by batteries

⚫ Wall mounting (360° rotation, 180° up/down)

⚫ Many other mounting possibilities e.g. in the garden with the

ground mounting holder

⚫ Protection class IP65 (dust & waterproof)

Technical specifications

Image sensor

1/4" CMOS 2MP

Video format / Video file

720p, 25fps / MP4

Photo format / Photo file

1280x720 Pixel / JPEG

Camera lens

F=2.0, FOV 92° horizontal / 92° vertical

PIR

max. distance ~7m / angle 60° / trigger time 1–1.5

sec.

Light

distance ~8m / power 2W, 150 lumen (20W

incandescent bulb) / Colour: 6000–6500 Kelvin

Storage

MicroSD* card up to 32GB (Class10)

[*not included]

Power supply

4x D-cell alkaline batteries* 1.5V

[*not included, not rechargeable]

Ø duration

battery life

Video mode 20x at night ~2.5 month

Photo mode 20x at night ~7 month

Light mode 20x at night ~2 month

Low battery

4.5V (LED is blinking in red)

Operation temperature

–10°C up to +40°C

Weight / Dimensions

400g / (L) 19.5 x (W) 15.0 (H) 10.5 cm

Package

Contents

HD Outdoor camera with LED lamp TX-106, 1x

Ground mounting holder, 3x Screws with dowels,

User Manual

Note: These parts are needed to operate but are not included.

4x D-Alkaline batteries, 1x MicroSD card (Class10) up to 32GB

(FAT32 formated), MicroSD card reader or other device to

download media from MicroSD card to PC, PC to set time and

date (use “time.txt file”) → watch the recorded video and photo

files).

Security and Disposal Hints for Batteries: Hold children off batteries. When

a child swallowed a battery go to a doctors place or bring the child into a

hospital promptly! Look for the right polarity (+) and (–) of batteries! Always

change all batteries. Never use old and new batteries or batteries of different

types together. Never short, open, deform or load up batteries! Risk of injury!

Never throw batteries into fire! Risk of explosion!

Hints for Environment Protection: Packages materials are raw materials

and can be recycled. Do not disposal old devices or batteries into the

domestic waste. Cleaning: Protect the device from contamination and

pollution (use a clean drapery). Avoid using rough, coarse-grained materials

or solvents/aggressive cleaner. Wipe the cleaned device accurately.

Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388

Frankfurt a.M., Germany

Product overview

PIR (motion detection)

LED light

Microphone

Angle adjustment

Camera

Mounting base thumb

Status LED (red / green)

Mounting base

How to use the camera

A.1 A.2

Remove the front

cover by rotating

counter-clockwise

→ picture A.1 and A.2.

B.1 B.2

Open the lock → picture B.1.

Insert 4D-Cell batteries →

picture B.2.

Note: Install batteries with

polarity in correct position.
