Sida 1/6
Technaxx
®
* User Manual
Air compressor with working light TX-129
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the
device the first time, please read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
Protect yourself and others by observing all safety information. Failure
to comply with instruction could result in personal injury and/or property
damage!
Keep this user manual for future reference or product sharing carefully. Do the
same with the original accessories for this product. In case of warranty, please
contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product. Share your experience and opinion on one of the
well-known internet portals.
Features
Main function: portable air compressor to inflate tires of
bicicles/cars, soccer/beach balls, etc. usable for emergency
roadside tire inflation
Integrated 5W LED as working light
Power supply via 12V connection with cigarette lighter socket
Compressor in a sturdy housing, ideal for air pressure regulation
Compact design with power cord, air hose and adapter storage
compartment
Manometer (pressure gauge) shows the pressure in Bar and PSI
3 extra adapters for bicycle valve, safety valve and ball valve
Maximum pressure 7 bar / 100 PSI
Technical Specification
Power supply DC 12V cigarette lighter socket
Compressor power 140W
Current max. 12A
Fuse 15A (F15AL 250V)
Power cord (L) 3m
Pressure Max. 7 bar / 100PSI
Manometer Analog (PSI, Bar)
Air hose 33cm
LED brightness COB LED 5W / 370 lumen
Protection class
IP30 (protection against impurity/objects
from Ø 2.5mm & access with a tool, not
waterproof)
Material ABS
Weight / Dimensions
1.21kg / (L) 35.5 x (W) 16.5 x (H) 12.1 cm
Package contents
Air compressor with working light TX-129,
Bicycle valve, Safety valve, Ball valve, User
Manual
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution (use a clean drapery).
Avoid using rough, coarse-grained materials or
solvents/aggressive cleaner. Wipe the cleaned device
accurately. Distributor: Technaxx Deutschland GmbH
& Co.KG, Kruppstr. 105, 60388 Frankfurt a.M.,
Germany
Product & Operation
Front Rear
1 360° rotatable hook
2 Manometer
3 5W LED working light
6
Adapter storage compart-
ment / Bicycle valve /
Safety valve / Ball valve
4 On/Off air compressor switch
5 On/Off work light switch 7 Air hose connector
Working light
Plug 12V DC power cord into 12V cigarette lighter socket.
Turn on the working light switch. The 5W LED provides an
output of up to 370 lumen.
