Sida 1/6

TEG1126P-24-410W

24GE+2SFP Ethernet Switch With 24-Port PoE

www.tendacn.com

TE 1126P-24-410WG

24GE+2SFP Ethernet Switch With 24-Port PoE

Products Description

TEG1126P-24-410W is a unmanaged PoE switch independently designed by Tenda. Compliant with

IEEE 802.3af and IEEE 802.3at standards, it can identify PoE-powered devices intelligently. With a

maximum PoE power output of 370 W, and 30 W for a single port, it can supply power when transmitting

data with APs, IP cameras, and IP phones. The switch supports 4 working modes, including standard,

priority, extend and VLAN modes, is an ideal choice for SMBs, hotels, schools, factories with video

surveillance and wireless networking requirements.

24GE+2SFP Ethernet Switch With 24-Port PoE

Key Feature

Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x and

IEEE802.3af/at standards.

24 * 100/100 0Mbps Base-T RJ45 ports for data transmission and power supply,

2 * 1000 MbpsBase-X SFP slots.

8K MAC address table and MAC address auto-learning.

IEEE 802.3x-compliant full-duplex flow control and half-duplex backpressure flow control.

48Gbps backplane bandwidth.

Maximum power consumption of a single port: 30W; Maximum power consumption of the

switch: 410W.

4 modes: standard, priority, extend and VLAN.

Product Features

6 kV lightning protection

The switch offers various safety and protection types, including 6 kV lightening protection,

PSE short-circuit protection, PoE overload protection, surge current protection etc.

Gigabit uplink port

With two 1000 Mbps combo SFP slots, the switch can meet the current demand for

uplink bandwidth of Gigabit WLAN and HD digital surveillance.

370W PoE power supply

The switch features 24 IEEE 802.3at/af-compliant RJ45 ports. The entire switch offers a

maximum PoE power output of 370 W, and 30 W for a single port, to supply power to and

data transmission with 24 PoE-powered devices such as APs and IP cameras.

One-Key to switch 4 modes

It supports 4 working modes, including standard, priority, extend and VLAN modes. The

hardware DIP mode switch makes networking straightforward and effortless.

AF /AT

6KV

Produktspecifikationer

Varumärke:	Tenda
Kategori:	Växla
Modell:	TEG1126P-24-410W
Bredd:	440 mm
Djup:	284 mm
Höjd:	44 mm
LED-indikatorer:	Link, PoE, Power
Certifiering:	FCC, CE, RoHS
Rackmontering:	Ja
Kabeltyper som stöds:	Cat5, Cat5e
Antal Combo SFP-portar:	2
Produktens färg:	Brun
Monteringsbar på väggen:	Ja
Formfaktor:	1U
Datahastighet för Ethernet-LAN:	100,1000 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Total Power over Ethernet (PoE)-budget:	370 W
Power over Ethernet (PoE)-effekt per port:	15.4 W
Temperatur vid drift:	0 - 45 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Fuktighet (förvaring):	5 - 90 %
AC-inspänning:	100 - 240 V
Växelström Frekvens:	50 - 60 hz
Kommunikationsstandarder:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Adresstabellstorlek:	8000 poster
Switch kapacitet:	48 Gbit/s
Hastighet vid vidarebefordran:	35.7 Mpps
10G stöd:	Nej
Antal grundläggande RJ-45 Ethernet-portar:	24
Typ av grundläggande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Antal fläktar:	2 fläkt/-ar
Switch typ:	Ohanterad
Lagra-och-vidarebefordra:	Ja
Koppar Ethernet-kablar teknik:	1000BASE-T
Fläktlös:	Nej
