Sida 1/13
VINIA
VINIA is a multichannel audio generator and processor module.
Each of the 8 channels can be independently configured as a multi effect processor, VCO, sample player…
8 Channels
6 Audio inputs (AC coupled, tracks 7 & 8 use
inputs 1 & 2)
8 Audio outputs (DC coupled)
8 trigger inputs
8 CV inputs (-5V / +5V)
Midi trs input
2,4” color display
LFO, envelope, envelope follower and mini
sequencer per channel
The module can be used both with jacks up or down.
Audio outputs are DC coupled so it can be used to generate complex CV modulation sources too.
There are 2 types of modulation in Vinia, the first is stepped (occurs every 1,4 milliseconds approx.) and very
flexible, any modulation source can modify any parameter of any track. The second is the ‘audio rate
modulation’ (44,1KHz), only a few parameters admit this type and both sources and destinations will be within
the same track.
The Constructor allows configuring the chain of audio source & processors for every channel. Add, replace,
move or mute up to 11 effects per channel. Clinking on any element of the chain will take us to the editor
where each parameter can be adjusted, and clicking on any parameter will take us to the modulation settings
for it.
Firmware update procedure.
1
Audio sources:
● AUDIO INPUT
● FLASH SAMPLE PLAYER
● MICROSD SAMPLE PLAYER
● VCO
● MULTI VCO
● HARMONIC OSCILLATOR
● KARPLUS
● CHORDS
● LFO
● ENVELOPE FOLLOWER
● ENVELOPE
● NOISE
● DRUM SYNTH
Audio processors:
● FM OPERATOR
● MULTIMODE FILTER
● LADDER FILTER
● RUBBER FILTER
● BANDPASS FILTER
● VCA / POLARIZER
● FOLDER
● TUBE SATURATION
● EXPONENTIAL ENVELOPE
● DELAY
● FILTER DELAY
● LONG DELAY
● LONG FILTER DELAY
● REVERB
● METALIZER
● CHORUS
● MODULATOR
● VOCODER 16
● VOCODER 32
● BIT CRUSHER
● RECTIFIER
● RANDOMIZER
● GRAIN PITCH SHIFT
● RING MODULATOR
Output
Master FX
● Stereo plate reverb
Modulation sources:
● Audio in envelope follower 6 unipolar
● CV input 8 bipolar
● Envelope 8 unipolar
● LFO 8 bipolar
● Sequencer 8 unipolar
● Macro 8 (with 8 layers each) bipolar
● Random 16
● Midi CC 128 unipolar
2
3
