LM339B, LM2901B, LM339, LM239, LM139, LM2901 Quad Differential Comparators

1 Features

•NEW LM339B and LM2901B

•Improved specifications of B-version

–Maximum rating: up to 38V

–ESD rating (HBM): 2kV

–Low input offset: 0.37mV

–Low input bias current: 3.5nA

–Low supply-current: 200µA per comparator

–Faster response time of 1µsec

–Extended temperature range for LM339B

•B-version is drop-in replacement for LM239,

LM339 and LM2901, A and V versions

•Common-mode input voltage range includes

ground

•Differential input voltage range equal to maximum-

rated supply voltage: ±38V

•Low output saturation voltage

•Output compatible with TTL, MOS, and CMOS

•For single version, see the TL331B

•For dual version, see the LM393B or LM2903B

2 Applications

•Vacuum robot

•Single phase UPS

•Server PSU

•Cordless power tool

•Wireless infrastructure

•Applicances

•Building automation

•Factory automation & control

•Motor drives

•Infotainment & cluster

3 Description

The LM339B and LM2901B devices are the

next generation versions of the industry-standard

LM339 and LM2901 comparator family. These next

generation B-version comparators feature lower offset

voltage, higher supply voltage capability, lower supply

current, lower input bias current, lower propagation

delay, and improved 2 kV ESD performance and

input ruggedness through dedicated ESD clamps.

The LM339B and LM2901B can drop-in replace the

LM239, LM339 and LM2901, for both "A" and "V"

grades.

All devices consist of four independent voltage

comparators that are designed to operate from a

single power supply over a wide range of voltages.

Quiescent current is independent of the supply

voltage.

Device Information

PART NUMBERPACKAGE

(1)

BODY SIZE (NOM)

LM139x, LM239x, LM339x,

LM2901x, LM339B,

LM2901B

SOIC (14)8.70mm × 3.90mm

LM239, LM339x, LM2901PDIP (14)19.30mm × 6.40mm

LM239, LM2901, LM339B,

LM2901B

TSSOP (14)5.00mm × 4.40mm

LM339x, LM2901SOP (14)10.20mm × 5.30mm

LM339x, LM2901SSOP (14)6.50mm × 5.30mm

LM2901BSOT-23 (14)4.20mm x 2.00mm

LM339B, LM2901BWQFN (16)3.00mm x 3.00mm

(1)For all available packages, see the orderable addendum at

the end of the data sheet.

Family Comparison Table

SpecificationLM339BLM2901B

LM339

LM339A

LM2901

LM2901A

LM2901V

LM2901AV

LM139

LM139A

LM239

LM239A

Units

Supply Voltage2 to 362 to 362 to 302 to 302 to 322 to 302 to 30V

Total Supply Current

(5V to 36V max)

0.8 to 10.8 to 11 to 2.51 to 2.51 to 2.51 to 2.51 to 2.5mA

Temperature Range−40 to 85−40 to 1250 to 70−40 to 125−40 to 125−55 to 125−25 to 85°C

ESD (HBM)2000200020002000200020002000V

Offset Voltage

(Max over temp)

± 5.5± 5.5

± 9

± 4

± 15

± 4

± 15

± 4

± 9

± 4

± 9

± 4

mV

Input Bias Current (typ / max)3.5 / 253.5 / 2525 / 25025 / 25025 / 25025 / 10025 / 250nA

Response Time (typ)111.31.31.31.31.3µsec

LM139, LM239, LM339, LM339B, LM139A, LM239A

LM339A, LM2901B, LM2901, LM2901AV, LM2901V

SLCS006Z – OCTOBER 1979 – REVISED MAY 2025

An IMPORTANT NOTICE at the end of this data sheet addresses availability, warranty, changes, use in safety-critical applications,

intellectual property matters and other important disclaimers. UNLESS OTHERWISE NOTED, this document contains PRODUCTION

DATA.
