Installation

MANUAL

Under Cabinet Drawer Hood

Recirculating Kit

Models RECHMDW30 & RECHMDW36

FOR USE WITH THESE UNDER

WALL HOOD MODELS

Models HMDW30WS & HMDW36WS

ABOUT THIS MANUAL

Signal Words for Safety and Best Use

WARNING

This indicates that death or serious injuries may occur as a

result of non-observance of this warning.

CAUTION

This indicates that minor or moderate injuries may occur

as a result of non-observance of this warning.

NOTICE: This indicates that damage to the appliance or

property may occur as a result of non-compliance with this

advisory.

Note: This alerts you to important information and/or tips.

Pay special attention to the important safety instructions in

the “Safety” section.

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

General Notes

WARNING

Use this unit only in the manner intended by the manufac-

turer. If you have questions, contact the manufacturer.

WARNING

Do not use this recirculation kit with Gas Cooktops.

WARNING

• When cutting or drilling into wall or ceiling, do not

damage electrical wiring and other hidden utilities.

• Ducted fans must always be vented to the outdoors.

INSTALLER: LEAVE THESE INSTRUCTIONS WITH THE

APPLICANCE AFTER INSTALLATION IS COMPLETE.

IMPORTANT: SAVE FOR THE LOCAL INSPECTOR’S USE.

WARNING

When properly cared for, your new appliance has been

designed to be safe and reliable. Read all instructions ca-

refully before use. These precautions will reduce the risk

of burns, electric shock, re, and injury to persons. When

using kitchen appliances, basic safety precautions must

be followed, including those in the following pages.

Proper Installation and Maintenance

WARNING

Remove all tape and packaging before using the applian-

ce. Destroy the packaging after unpacking the appliance.

Never allow children to play with packaging material.

This appliance is intended for normal family household

use only. It is not approved for outdoor use. Refer to the

Statement of Limited Warranty in the Use and Care Ma-

nual. If you have any questions, contact the manufacturer.

Do not store or use corrosive chemicals, vapors, ammables

or nonfood products in or near this appliance. It is spe-

cically designed for use when heating or cooking food.

The use of corrosive chemicals in heating or cleaning will

damage the appliance and could result in injury.

Do not operate this appliance if it is not working properly,

or if it has been damaged. Contact an authorized servicer.

Do not repair or replace any part of the appliance unless

specically recommended in this manual. Refer all servi-

cing to a factory authorized service center.

CAUTION

Grease left on lters can melt and move into the vent.

WARNING

Hidden surfaces may have sharp edges. Use caution when

reaching behind or under appliance.
