AXP-100 C65 Installation Manual
Part List
108
42
4027
2210
121
68
34
26
30
A
G
MNOPQR
HIJKL
B
CDEF
Nylon Tube x5
Anchoring Mount x1
TF4 x1M3L6 Screw x3Mounting Plate x16#32 L17 Screw x5
775 Back Plate Cap x1
AXP-100 C65 x1
TY-100BP x1
Enhanced Fan Mount x1
M3L28 Screw x5M3L4 Screw x5M3L17 Screw x5
Metal Back Plate x1
LGA2011 Double Head Screw x4
Screw Nut x4
LGA 115x Screw Pillars x4
Mylar x1
AMD AM4 Platform
1
22
5
6
7
4
3
A
B
C
D
E
F
Q
M
R
Motherboard Front
www.thermalright.com
Tel: +886-2-2915-5005
Fax: +886-2-2915-5123
Email: sup[email protected]
Please follow the Installation Guide before installing this product.
Please do NOT modify or disassemble this product.
Please keep this product AWAY from children.
Please do NOT use this product for the non-PC environment.
Please do NOT apply too much thermal paste will lower heat conductivity and cooling performance!
To prevent electrical shocks, please turn o system power and unplug the power of the system before
beginning the installation.
