Transformer
Harmonic generator & color box
www.tkaudio.se
Key Features:
• Transformer saturation circuit that adds low-end harmonics and a low-end bump
• Passive saturation circuit that adds a lot of odd and even harmonics
• Active germanium stage with a vintage sound and a mix of harmonics
• Class-A stage with a pleasant British 70’s sound
• M/S function for separate processing of the mid and side channels
The Transformer is a recording and mixing tool that transform your sound by using several dif-
ferent harmonic stages. The unit is divided into two sections, a harmonic generating section and
a transformer coupled class-A stage with a punchy, vintage tone.
If you’re working mostly in the box this is the perfect tool to add some analog warmth, punch
and color to your sound/mix.
The first section contains three different harmonic stages; a transformer saturation stage, a
passive saturation/clipping stage and an active germanium circuit.
These three stages does not only generate different kinds of harmonics, they also shape the
tone curve in different ways.
With a blend function you can blend in the desired amount of harmonics. You can also choose to
process the mid and side channels separately by activating the M/S function.
The second section is a selectable vintage transformer coupled class-A stage which also has a
HF boost function.
www.tkaudio.se
TX Drive
TX Drive is the first harmonics stage which is a transformer saturation circuit. With a single con-
trol you can vary the amount of transformer saturation and still keep the level constant.
The circuit generates around 1% of harmonics (distortion) in the low-end and a gentle amount
of higher harmonics. It also adds a 2dB bump in the low-end around 30Hz. By turning the drive
control the bump level and higher harmonics decreases, the low-end harmonics stays around
1%.
Gain
The TX drive is followed by a gain control so you can drive the following Sat and Ge stages har-
der for more harmonics.
Sat
The second stage is a passive saturation circuit which adds a lot of odd harmonics and by enga-
ging the Even switch it also adds even harmonics. The harmonic amount depends on how hard
the stage is driven.
Ge
The third stage is an active germanium stage that adds more even than odd harmonics. It has a
pleasant vintage sound with it’s mix of harmonics and a soft high-end. Like the previous stage
the amount of harmonics depend on how hard it’s driven.
Output trim
The Sat and Ge stages are followed by an output trim to fine adjust the level before it enters the
blend control.
Blend
With the Blend control you can blend the harmonics stages signal with the dry signal.
M/S
An M/S function is provided so you can process the mid and side channels separately with
different harmonic circuits. As an example you can use the TX drive on the mid channel for more
low-end harmonics and the Sat and Ge stages for more harmonics on the side channel.
The class-A stage can’t be used in M/S as it’s placed after the M/S encoder/decoder!
Class-A
The blend control and M/S function are followed by a selectable transformer coupled class-A
stage that adds a fat and punchy sound with mid-character and a silky top end associated with
the British class-A from the early 70’s.
This stage also has a HF boost function that adds a small amount of air to the sound when acti-
vated.
Frequency and harmonic distortion graphs are available on TK Audio webpage.
https://tkaudio.se/transformer
