Sida 1/17
PH340/PH360
USER MANUAL 2
HANDLEIDING 4
MODE D'EMPLOI 6
MANUAL DEL USUARIO 8
BEDIENUNGSANLEITUNG 10
INSTRUKCJA OBSŁUGI 12
MANUAL DO UTILIZADOR 14
PH340/PH360
V. 01 05/12/2018 2 ©Velleman nv –
USER MANUAL
1. Introduction
Thank you for choosing Toolland. Please read the manual thoroughly before bringing this
device into service. If the device was damaged in transit, do not install or use it and contact
your dealer.
Refer to the Velleman® Service and Quality Warranty on the last pages of this manual.
2. Safety Instructions
Safety gloves are required while operating this machine.
CAUTION The edges of cut tiles are sharp. –
Always keep the appliance away from any crash and corrosive liquid.
This tile-cutting machine is fitted with a replaceable circular blade. Keep the tile cutter and
blade away from children.
After use, the appliance must be stored in a safe and dry place.
This appliance is designed for cutting and breaking glazed tile, and shall not be used for
any other purpose.
When using the appliance, always keep extension leads away from the machine.
Always place the appliance on a level and firm surface.
3. Operation
1. Place the tile on the cutter bed. Set the guide to the width of the tile.
2. Position the tile-cutter wheel on the base of the tile to be cut.
Score the tile by moving the handle forward away from you while pressing down – –
lightly. K steady pressure for the full length of the tile. eep a
At the end of the score, the wheel will bump against the buffer. Make sure the anvil sits
over the score line.
3. Press down slightly applying increasing pressure until the tile snaps. Tip: Press the handle
with one hand and hold the base of the tile with the other.
PH340/PH360
V. 01 05/12/2018 3 ©Velleman nv –
4. Cleaning and Maintenance
Occasionally wipe with a damp cloth to keep free from dust. Do not use harsh chemicals,
cleaning solvents or strong detergents.
Follow the illustrations below to replace the cutting wheel.
5. Technical Specifications
length
PH340 ........................................................................................................... 400 mm
PH360 ........................................................................................................... 600 mm
max. tile thickness ................................................................................................. 12 mm
PH340 ............................................................................................................ 12 mm
PH360 ......................................................................................................... 4-12 mm
cutting wheel size ........................................................... 22 x 6 x 2 mm (order code PH341)
Use this device with original accessories only. Velleman nv cannot be held
responsible in the event of damage or injury resulting from (incorrect) use of this
device. For more info concerning this product and the latest version of this manual,
please visit our website www.toolland.eu. The information in this manual is subject
to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All worldwide rights reserved.
No part of this manual may be copied, reproduced, translated or reduced to any electronic
medium or otherwise without the prior written consent of the copyright holder.
