Sida 1/40
FormNo.3448-826RevA
30inTurfMasterHDXWalk-BehindLawnMower
ModelNo.22215—SerialNo.410094837andUp
Operator'sManual
Introduction
Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyprofessional,hiredoperators.Itis
designedprimarilyforcuttinggrassonwell-maintained
lawnsonresidentialorcommercialproperties.Using
thisproductforpurposesotherthanitsintendeduse
couldprovedangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Y ouareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.T oro.comformoreinformation,including
safetytips,trainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineT oroparts,or
additionalinformation,contactanAuthorizedService
DealerorT oroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation
g290587
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.
GrossorNetTorque:Thegrossornettorque
ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.Pleasereferto
theenginemanufacturer’sinformationincludedwith
themachine.
WARNING
CALIFORNIA
Proposition65Warning
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
©2021—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420Registeratwww.T oro.com.
OriginalInstructions(EN)
PrintedinMexico
AllRightsReserved *3448-826*
Contents
Introduction...............................................................1
Safety.......................................................................2
GeneralSafety...................................................2
SafetyandInstructionalDecals..........................3
Setup........................................................................6
1InstallingtheHandle........................................6
2AddingOiltotheEngine...................................7
3AssemblingtheGrassBag...............................7
ProductOverview.....................................................9
Controls.............................................................9
Specications....................................................9
Attachments/Accessories.................................10
Operation................................................................10
BeforeOperation.................................................10
BeforeOperationSafety...................................10
FillingtheFuelTank..........................................10
CheckingtheEngine-OilLevel...........................11
AdjustingtheHandleHeight..............................11
AdjustingtheCuttingHeight.............................12
CheckingtheBlade-StopSystem
Operation......................................................13
DuringOperation.................................................13
DuringOperationSafety...................................13
StartingtheEngine...........................................14
OperatingtheSelf-PropelDriveand
EngagingtheBlades.....................................15
ShuttingOfftheEngine.....................................16
EngagingtheParkingBrake.............................16
DisengagingtheParkingBrake.........................16
RecyclingtheClippings....................................17
BaggingtheClippings.......................................17
Side-DischargingtheClippings.........................18
OperatingTips.................................................19
AfterOperation....................................................19
AfterOperationSafety......................................19
CleaningundertheMachine.............................19
CleaningtheWheels.........................................20
Maintenance...........................................................21
RecommendedMaintenanceSchedule(s)...........21
MaintenanceSafety..........................................21
ServicingtheAirFilter.......................................22
ChangingtheEngineOil...................................22
ChangingtheOilFilter......................................23
ServicingtheSparkPlug...................................24
CheckingtheConditionoftheBelts...................24
EmptyingtheFuelT ankandCleaningthe
Filter..............................................................24
ChangingtheFuelFilter....................................25
ServicingtheBlade-DriveSystem.....................25
ServicingtheBlades.........................................26
ChangingtheBlade-DriveBelt..........................28
ChangingtheBlade-Brake-Clutch(BBC)
Belt................................................................29
AdjustingtheBlade-BrakeCable......................30
ChangingtheTransmissionBelt.......................31
AdjustingtheParking-BrakeCable...................32
AdjustingtheSelf-PropelDrive.........................33
Storage...................................................................34
StorageSafety..................................................34
GeneralInformation..........................................34
PreparingtheFuelSystem...............................34
PreparingtheEngine........................................34
RemovingtheMachinefromStorage................34
Troubleshooting......................................................35
Safety
Thismachinehasbeendesignedinaccordancewith
ANSIB71.4-2017.
GeneralSafety
Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjuryordeath.
•Read,understand,andfollowtheinstructions
andwarningsinthisOperator’sManualandon
themachineandattachmentsbeforestartingthe
engine.
•Donotputyourhandsorfeetnearmovingpartsor
underthemachine.Keepclearofanydischarge
opening.
•Donotoperatethemachinewithoutallguards
andothersafetyprotectivedevicesinplaceand
functioningproperlyonthemachine.
•Keepbystandersandchildrenoutoftheoperating
area.Donotallowchildrentooperatethemachine.
Allowonlypeoplewhoareresponsible,trained,
familiarwiththeinstructions,andphysically
capabletooperatethemachine.
•Stopthemachine,shutofftheengine,andwaitfor
allmovingpartstostopbeforeservicing,fueling,
oruncloggingthemachine.
Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol ,which
meansCaution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
2
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decaloemmarkt
Manufacturer'sMark
1.Thismarkindicatesthatthebladeisidentiedasapart
fromtheoriginalmachinemanufacturer.
decal94-8072
94-8072
decal116-7127
116-7127
1.Heightofcut
decal116-7581
116-7581
1.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts.ReadtheOperator’s
Manualbeforeadjustingservicing,orcleaningthemachine.
decal136-9077
136-9077
1.Heightofcut
decal139-5405
139-5405
1.Parkingbrake—engage2.Parkingbrake—disengage
3
