Sida 1/26
Note: If the bracket is not suitable for your computer, detach it
from the adapter's board and replace it with the low-prole bracket.
c.
Locate an available
PCIE
slot ( X1, X4, X8, or X16)
and carefully insert the adapter.
Note: If the Bluetooth USB cable is not correctly connected to the
motherboard, the Bluetooth function won’t work even after driver
installation.
d. Locate an available connector and carefully F_USB
plug the Bluetooth USB cable into it.
USB
1 Disable Bluetooth
a. Right-click , select , go to My Computer Manage
Device Manager.
b. Expand the Bluetooth node to nd your existing
Bluetooth device.
c. Right-click the existing Bluetooth device and
select Disable.
Note: Make sure you have disabled all existing Bluetooth devices
(both built-in and the third party).
Bluetooth
Device Manager
Disable
Existing Bluetooth Adapter
Before You Start:
1. Make sure you are using Windows 11(x64) or
above, and your router or access point
supports the Wi-Fi 7 standard.
2. If you plan on using Bluetooth and already have
connected Bluetooth devices, proceed with
Step 1. Otherwise, skip to .Step 2
f. Replace the case panel, plug in the power cable,
and turn on your computer.
To continue, ip the page over.
2 Connect to a Computer
a. Turn off your computer, unplug the power cable,
and then remove the case panel.
b. Connect the provided Bluetooth USB cable to the
adapter.
Bluetooth USB Cable
Adapter
e. Install the antennas on the magnetized antenna
base, then connect the base to the adapter.
Tips:
• To maximize performance, make sure the path between the antenna
and your router is clear.
• connect one SMA male connector directly to another with DO NOT
wires or other conductors to prevent short circuits or adapter
damage.
SMA Male
Connectors
7106510724 REV1.0.0©2023 TP-Link
Images may dier from your actual product.
WLAN Bluetooth
PCI Express Adapter
5 Pair with Bluetooth Devices
c. Select your Bluetooth device from the list and
follow the on-screen instructions to complete
pairing.
Note: Make sure your device’s Bluetooth is enabled and
discoverable.
b. Select Add a Bluetooth Device Add a Device or
to scan for available devices.
Jack’s Pad
Mouse
Anna’s Phone
a. Right-click the (Bluetooth) icon on the
taskbar. If it's not displayed, turn on Bluetooth in
your PC settings rst.
Safety Information
· Keep the device away from water, re, humidity or hot environments.
· Do not attempt to disassemble, repair, or modify the device. If you
need service, please contact us.
· Do not use the device where wireless devices are not allowed.
TP-Link hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/53/EU, 2011 /65/EU and (EU) 2015/863.
The original EU Declaration of Conformity may be found at
https://www.tp-link.com/en/support/ce
TP-Link hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of the Radio
Equipment Regulations 2017.
The original UK Declaration of Conformity may be found at
https://www.tp-link.com/support/ukca
Support
For technical support, user guides and other
information, simply scan the QR code or visit
https://www.tp-link.com/support/
4 Join a Wireless Network
a. . Click the network icon ( ) on the taskbar
b. Select your Wi-Fi network, click , and Connect
enter the password when prompted.
Connect
Secured
TP-Link_XXXX
Network settings
Pair
3 Install Drivers
Need Help?
Windows settings. To enable Bluetooth, go to Start >
Settings > Devices > Bluetooth & other devices and
turn on Bluetooth.
• Make sure there are no other Bluetooth devices on the
computer. If there are, disable all existing Bluetooth
devices in Device Manager, then reinstall the adapter
and try again.
Tip: To access Device Manager: Right-click or My Computer This
PC, select , go to Manage Device Manager, and disable all existing
Bluetooth devices.
Q5. What do I do when the LEDs on the antenna base are
o?
• Make sure the magnetized antenna base is properly
connected to the adapter.
• Refer to Q1 to check if the adapter is detected.
• Refer to to check if you have installed the driver for Q2
your adapter successfully.
• Ensure that the two SMA male connectors on the
adapter are not in contact with any other metal parts or
conductors to prevent short circuits.
• Locate the network icon ( ) in the bottom right corner
of your desktop on your computer and make sure you
have enabled the Wi-Fi Radio signal. If not, click the
network icon ( ) and select the Wi-Fi button to turn
on the Wi-Fi.
• Single press the LED button to turn on the LED.
Appearance
LED Button
• Single press to turn on/off the
LED.
• Press and hold for about 2s to
change the color of the LED.
LED
Antenna
Base
The adapter is working properly.
The adapter is not working properly.
Refer to Q5 for troubleshooting.
LED Status Description
No internet connection.
Breathing
Off
Static
Spectrum
Operating at 320MHz.
LED Explanation
Antenna
b. Double-click the to run the TP-Link CD
installation program.
c. Install the Wi-Fi and Bluetooth drivers .
Tip: You can also check for new releases and download the
latest drivers at https://www.tp-link.com/support/download/
① Wi-Fi: Click and follow the on-screen
instructions to complete the Wi-Fi installation.
② Bluetooth: Click and follow the on-screen
instructions to complete the Bluetooth installation.
Notes:
• If an unknown publisher message pops up, select Yes to
continue.
• If Windows User Account Control requires admin credentials,
type the user name and password of your Windows
administrator account.
a. Insert the provided USB drive into your computer
and go to My Computer This PC or .
Q1. What should I do if the adapter is not detected?
• Make sure the adapter is securely located in the
appropriate PCI-E slot.
• Try a dierent PCI-E slot on the computer.
• Make sure you use the latest driver for your specic
adapter. The latest drivers can be found at the product’s
Support page at https://www.tp-link.com.
• Try restarting the computer or try the adapter on a
dierent computer.
Q2. How do I check if I have installed the drivers
successfully?
• Check your taskbar if there are Wi-Fi and Bluetooth icons.
• If you can see the network icon ( ) on the taskbar, you
have already installed the Wi-Fi driver successfully.
• If you can see the (Bluetooth) icon on the taskbar, you
have already installed the Bluetooth driver successfully.
Q3. What should I do if I can’t connect to the Wi-Fi after
installing the driver?
• Refer to Q1 to check if the adapter is detected.
• Refer to to check if you have installed the drivers for Q2
your adapter successfully.
• Disable the antivirus software and rewall, then try again.
• Reinstall the driver and try again.
Q4. What should I do if the Bluetooth icon doesn’t appear?
• Make sure you have turned on the Bluetooth in your
