Revised 6/11/18 Copyright © 2018 Trade-Wind Manufacturing, LLC Proverbs 22:29 Page 1
INSTALLATION INSTRUCTIONS &
USE & CARE GUIDE
Trade-Wind
®
VSL 400 Series Liners
For Remote/In-Line Blowers
VSL 400 Series Liner Models
Model
Width
CFM
Type of
Motor &
Blower
VSL430 BF
28
3
/
8
‖
*
Remote
VSL436 BF
34
3
/
8
‖
*
Remote
VSL442 BF
40
3
/
8
‖
*
Remote
VSL448 BF
46
3
/
8
‖
*
Remote
VSL454 BF
52
3
/
8
‖
*
Remote
VSL460 BF
58
3
/
8
‖
*
Remote
*These models connect to an In-Line, Roof or
Wall-Mounted Remote Blower. The blower used
determines the CFM. The Trade-Wind In-Line blowers
are either 836 CFM or 1266 CFM.
Before beginning installation, please thoroughly read and become familiar with these instructions. Installation and
service must be completed by a qualied installer. Failure to properly install this product may void the warranty.
Installer:
Please leave Installation Instructions with the range hood liner.
Owner:
Please keep Installation Instructions for local electrical inspector’s use and for future reference.
WARNINGS: Must be followed carefully to avoid personal injury.
IMPORTANT: Must be followed carefully to avoid damage or incorrect installation.
TIPS: Contain helpful information to facilitate installation.
READ AND SAVE THESE INSTRUCTIONS
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK, OR INJURY TO
PERSONS OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have any questions, please contact the
manufacturer at the address or telephone number listed in the warranty.
b) Before servicing or cleaning unit, switch power o at service panel, lock service panel, and lock the service
disconnection means to prevent power from being switched on accidentally. When the service disconnecting
means cannot be locked, securely fasten a prominent warning device, such as a tag, to the service panel.
CAUTION
-- For general ventilating use only. Do not use to exhaust hazardous or explosive materials and vapors.
WARNING TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:–
a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may
ignite. Heat oils slowly on low or medium settings.
Revised 6/11/18 Copyright © 2018 Trade-Wind Manufacturing, LLC Proverbs 22:29 Page 2
b) Always turn hood ON when cooking at high heat or when ambeing food (i.e. Crepes Suzette, Cherries Jubilee,
Peppercorn Beef Flambe’).
c) Clean ventilating fans frequently. Grease should not be allowed to accumulate on fan or lter.
d) Use proper pan size. Always use cookware appropriate for the size of the surface element.
WARNING! TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A
RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING:
a) SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn o the burner. BE CAREFUL
TO PREVENT BURNS. If the ames do not go out immediately, EVACUATE AND CALL THE FIRE
DEPARTMENT.
b) NEVER PICK UP A FLAMING PAN YOU MAY BE BURNED. —
c) DO NOT USE WATER, including wet dishcloths or towels. A violent steam explosion will result.
d) Use an extinguisher ONLY if:
1. You know you have a Class ABC extinguisher and you already know how to operate it.
2. The re is small and contained in the area where it started.
3. The re department is being called.
4. You can ght the re with your back to an exit.
Recommendations:
1. Consult a licensed ventilation contractor or qualied technician for proper installation of exhaust ducting.
Locate the cooking area for minimum cross drafts-away from doors and windows, when possible.
2. Ducts must be of adequate size and duct runs should be as short as possible. Where turns are necessary,
keep turning radius as large and as smooth as possible.
3. The ducting must be air tight. Use a minimum of 2 sheet metal screws at every duct joint. Then, seal the duct
joints with high quality duct tape.
4. Do not use this unit with any solid-state speed control device.
5. This unit must be grounded.
INSTALLATION INSTRUCTIONS
WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO –
PERSONS, OBSERVE THE FOLLOWING:
a) Installation work and electrical wiring must be done by qualied person(s) in accordance with all applicable
codes and standards, including re-rated construction codes and standards.
b) Sucient air is needed for proper combustion and exhausting of gasses through the ue (chimney) of fuel
burning equipment to prevent back drafting. Follow the heating equipment manufacturer's guidelines and safety
standards such as those published by the National Fire Protection Association (NFPA) and the American Society
for Heating, Refrigeration and Air Conditioning Engineers (ASHRAE) and the local code authorities.
c) When cutting or drilling into wall or ceiling, do not damage electrical wiring and other hidden utilities.
d) Ducted fans must always be vented to the outdoor.
WARNING TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK. --
CAUTION –T educe the risk of re and to properly exhaust air, be sure to duct air outside o r –
Do not vent exhaust air into spaces within walls, ceilings, cabinets or into attics, crawl spaces, or garages.
Revised 6/11/18 Copyright © 2018 Trade-Wind Manufacturing, LLC Proverbs 22:29 Page 3
To reduce the risk of re and electric shock, install this (range hood) only with. Remote CAUTION –
wer models rated maximum 6 amps. Blo
CONTENTS:
Part 1 - Planning The Installation Part 2 - Securing The Liner
Part 3 - Use & Care Part 4 - Electrical Connection (Give copy of these 2 pages to electrician.)
PART 1 Planning the Installation
Trade-Wind
®
Designer Series Liners are designed for installation inside custom hood canopies. Proper installation
of the liner is directly related to the material from which the custom canopy is constructed. A qualied person must
complete the installation of this unit. Because of the large size and weight of this hood / liner, two installers are
recommended. Plan the installation so that all minimum clearances are met or exceeded. Dimensions shown
provide minimum clearances, unless otherwise specied. You must provide structural framing and tight Important:
backing in the areas in which you are securing the liner inside your custom canopy. Failure to do so could distort
and damage the liner and void the warranty.
For best and quietest performance with In-Line Blower installations, the blower should be installed , near in the attic
or slightly beyond the mid-point of the duct system. In installations requiring the blower be in a chase or wood-type
hood over the range (e.g., no attic above the kitchen), the duct silencer will not be as effective in absorbing motor
noise. In addition, there will likely be motor sound transmitted through the walls of the chase, bypassing the duct
silencer.
Given the high performance of Trade-Wind
®
In-Line Blowers, it is highly recommended that the blower NOT
be attached directly to the liner or in a chase immediately above the liner unless a Trade-Wind
®
brand duct
silencer is installed between the blower and liner and neoprene lined FC Clamps are used. FC Clamps are
available from Trade-Wind
®
through your Trade-Wind
®
supplier. Ask for model numbers FC6 (6‖), FC8 (8‖) or
FC10 (10‖), 2 per box.
In-Line & Remote Ventilators, Duct Silencers, Dampers and Ducting
Trade-Wind
®
VSL Liners (non- - -internal motor models) are also designed for use with ―in line‖ and ―remote mount‖
ventilators. When planning for installations using these products, please refer to the Installation Instructions
provided with the ventilator. Trade-Wind
®
Duct Silencers are available from your local Trade-Wind
®
dealer. When
planning for installation using a duct silencer, please refer to the Installation Instructions provided with the duct
silencer.
Given that most installations are dierent, a back-draft damper is not provided with this unit. Trade-Wind
®
back
draft dampers are also available from your local Trade-Wind
®
dealer. Always install ventilation products with an
approved wall or roof cap. Duct performance is improved by using round, smooth metal duct work instead of
rectangular. Do not rely on duct tape alone to seal duct joints. Use sheet metal screws as required to support the
duct.
WARNING! For maximum ventilation performance, the bottom of the hood or liner should be 30 - 36
inches (76.2 - 91.4 cm) above the cooking surface (minimum is 24”). This would typically result in the
bottom of the hood being 66 - 72 inches (167.6 - 182.9 cm) above the oor. These dimensions provide for
safe and ecient operation of the hood. Always observe local building codes.
