4~32GB High Capacity Secure Digital Card
Transcend Information Inc.
1
Description
Transcend High Capacity SD Card series are
specifically designed to meet the High Capacity, High
Definition Audio and Video requirement for the latest
Digital Cameras, DV Recorders, Mobile Phones, etc,.
The new defined Speed Class enables the host to
support AV applications to perform real time
recording to the SD memory card.
Placement
Front Back
Features
• RoHS compliant product.
• Card Lid material: PC (comply with UL94,Flame
Class:HB)
• Operating Voltage: 2.7 ~ 3.6V
• Operating Temperature: -25 ~ 85°C
• Durability: 10,000 insertion/removal cycles
• Compatible with SD Specification Ver. 2.0
• Comply with SD File System Specification Ver. 2.0
• Mechanical Write Protection Switch
• Supports Speed Class Specification up to Class 6
• Supports Copy Protection for Recorded Media (CPRM)
for SD-Audio
• Seamless compatibility with SDMI-compliant digital audio
devices
• Form Factor: 24mm x 32mm x 2.1mm
Pin Definition
SD Mode SPI Mode
Pin No.
Name Type Description NameTypeDescription
1
CD/DAT
I/O/PP
3
Card Detect/Data Line [Bit3]
CS I
Chip Select (neg true)
2
CMD PP Command/Response
DI I
Data In
3
V
SS1
S Supply voltage ground
VSS S
Supply voltage ground
4
V
DD
S Supply voltage
VDD S
Supply voltage
5
CLK I Clock
SCLKI
Clock
6
V
SS2
S Supply voltage ground
VSS2S
Supply voltage ground
7
DAT0 I/O/PP Data Line [Bit0]
DO O/PP
Data Out
8
DAT1 I/O/PP Data Line [Bit1]
RSV
9
DAT2
I/O/PP Data Line [Bit2] RSV
Produktspecifikationer
| Varumärke: | Transcend |
| Kategori: | minneskort |
| Modell: | 32GB SDHC |
| Certifiering: | RoHS |
| Kapacitet: | 32 GB |
| Spänning: | 2.7 - 3.6 V |
| Produktens färg: | Blå |
| Temperatur vid drift: | 25 - 85 ° C |
| Plug & Play-kompatibel: | Ja |
| Flashkortstyp: | SDHC |
| Skrivskyddsknapp: | Ja |
| Uthållighet: | 10000 cykler per logisk sektor |
