TRENDnet User’s Guide

Cover Page

TRENDnet User’s Guide

Table of Contents

Contents

Product Overview ........................................................................... 1

Package Contents .......................................................................................................... 1

Features ......................................................................................................................... 1

Product Hardware Features........................................................................................... 2

Basic Installation & Setup ................................................................ 4

Access Point Compatibility ............................................................................................ 4

A. Initial Controller Setup .............................................................................................. 4

B. Connect your wireless access points ......................................................................... 6

C. Initial Wireless Setup ................................................................................................. 7

Mounting Installation .................................................................... 10

Wireless LAN Controller (TEW-WLC100) ..................................................................... 10

 Desktop Hardware Installation .......................................................................... 10

 Rack Mount Hardware Installation .................................................................... 10

Wireless PoE Access Point (TEW-755AP / TEW-821DAP) ............................................ 11

 Ceiling Mount Installation.................................................................................. 11

 Wall Mount Installation ..................................................................................... 11

Controller Management ................................................................ 12

Access your wireless controller management page .................................................... 12

Change your controller administrative login password ............................................... 12

Change your controller LAN IP address ....................................................................... 13

Upgrade your controller firmware .............................................................................. 13

View your controller system log .................................................................................. 14

Backup and restore your controller configuration settings ......................................... 15

Reboot your controller ................................................................................................ 15

Reset your controller to factory defaults .................................................................... 16

Controller default settings ........................................................................................... 16

Set your controller time zone ...................................................................................... 17

Access point management and configuration ................................ 18

Access Point Compatibility .......................................................................................... 18

Manage and configure access points .......................................................................... 18

 Discover and add access points ......................................................................... 18

 Configuring controller managed access points.................................................. 19

 Manually add an access point ........................................................................... 22

 Remove access points from the controller ........................................................ 23

 Simultaneously upgrade firmware for multiple access points .......................... 23

Wireless groups and profiles ....................................................................................... 24

 Creating a wireless profile ................................................................................. 24

 Creating a new wireless group .......................................................................... 27

 Assigning access points to a wireless group ...................................................... 27

Captive Portal .............................................................................................................. 29

 To Internal Portal URL........................................................................................ 29

 To Advertisement URL ....................................................................................... 31

 Captive Portal with RADIUS (CoovaChilli) .......................................................... 32

WAP Maps™ ................................................................................................................ 33

 Upload floor plans ............................................................................................. 33

Monitoring access points and clients .......................................................................... 35

 Viewing the controller dashboard ..................................................................... 35

 View client connections ..................................................................................... 36

Technical Specifications ................................................................ 37

Troubleshooting ........................................................................... 42

Appendix ...................................................................................... 43

TRENDnet User’s Guide

TEW-755AP2KAC / TEW-821DAP2KAC

Product Overview

TEW-755AP2KAC / TEW-821DAP2KAC

Package Contents

The package includes:

 1 x TEW-WLC100 wireless LAN controller

 2 x TEW-755AP N300 PoE access points or TEW-821DAP AC1200 dual band PoE

access points

 2 x TPE-113GI 802.3af Gigabit PoE injectors

 2 x Network cables (1.5 m / 5 ft.)

 TEW-WLC100 power adapter (12V DC, 1A)

 Quick Installation Guide

 CD-ROM (User’s Guide)

 Controller rack mount kit

 Access point mounting plates

If any package contents are missing or damaged, please contact the retail store, online

retailer, or reseller/distributor from which the product was purchased.

Features

TRENDnet's N300 / AC1200 Dual Band Wireless Controller Kit, TEW-755AP2KAC / TEW-

821DAP2KAC, is designed to simplify management and setup processes for your access

points. This new controller kit features seamless WiFi roaming, helping your devices stay

connected when transitioning from one access point to another within the network.

Fast BSS Transition, or fast roaming (802.11r), and OKC (opportunistic key caching)

ensures optimal roaming conditions for your mobile WiFi clients.

TRENDnet’s controller kit includes two wireless N300 / AC1200 access points with PoE

injectors, and a wireless controller. This kit allows you to easily setup and manage

access points across your network from a centralized interface. Simultaneously manage

up to 128 access points, perform batch firmware upgrades, and monitor network

connection status.

Complete Wireless Controller Kit

This complete controller kit includes two wireless N300 / AC1200 access points with PoE

injectors and our wireless hardware controller.

Seamless WiFi Roaming

802.11k provides a more efficient WiFi roaming environment by intelligently managing

neighboring APs and passing mobile clients off to the next best access point; 802.11r and

Opportunistic Key Caching (OKC) preauthenticates those WiFi clients with neighboring

APs making for a fast and seamless transition.

Centralized AP Management

Easily manage up to 128 access points across your network. Reduce AP deployment time

by creating group profiles to provision multiple access points simultaneously.

Simultaneously Upgrade Firmware

Select multiple access points to upgrade firmware at the same time

Captive Portal

Create a customized web portal for users to authenticate using unique user names and

passwords. Ideal for hotels, cafes, and businesses that want to provide public WiFi and

manage wireless usage

Produktspecifikationer

Varumärke:	Trendnet
Kategori:	Inte kategoriserad
Modell:	TEW-755AP2KAC
Vikt:	456 g
Bredd:	187 mm
Djup:	187 mm
Höjd:	46 mm
LED-indikatorer:	Ja
Placering:	Bord
Frekvensband:	2.412 – 2.472 GHz
Snabbstartsguide:	Ja
Strömförbrukning (max):	9.6 W
Certifiering:	FCC, CE
Uteffekt:	1 A
Kompatibla operativsystem:	Windows 8.1, 8, 7, Vista, XP
Återställningsknapp:	Ja
MAC-adressfiltrering:	Ja
Maximal dataöverföringshastighet:	1000 Mbit/s
2,4 GHz:	Ja
5 GHz:	Nej
6 GHz:	Nej
Produktens färg:	Vit
Monteringssats:	Ja
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 40 ° C
VLAN-stöd:	Ja
Utgångsspänning:	12 V
Kryptering/säkerhet:	WEP, WPA, WPA2-PSK, WPA2-RADIUS
Kabel inkluderad:	LAN (RJ-45)
Likströmsingång:	Ja
Firmware kan uppgraderas:	Ja
AC-adapter inkluderad:	Ja
Maximal överföringshastighet för trådlöst LAN:	300 Mbit/s
Modulator:	16-QAM, 256-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK
Webbaserad adminstraion:	Ja
Lednings Protokoll:	SNMP v1/v3
Antenner mängd:	2
Antenn ökningsnivå (max):	4 dBi
Kommunikationsstandarder:	IEEE 802.11b, IEEE 802.11d, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Stöd för garanterad tjänstekvalitet (QoS):	Ja
Antenntyp:	Intern
Intern:	Nej
Wi-Fi Multimedia (WMM)/(WME):	Ja
Antal SSID som stöds:	8
Flödeskontroll:	Ja
Bruksanvisning på CD:	Ja
