90W 2-Port Industrial 2.5G PoE++ Injector

TI-IG290 (v2.0R)

• 2 x 2.5G PoE++ ports (Data + PoE out)

• 2 x 2.5G ports (Data in)

• 180W PoE power budget

• Supports PoE (15.4W), PoE+ (30W), and PoE++ (95W)

devices

• Uses IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt industry

PoE standards for greater device interoperability

• Network a PoE device located up to 100m (328 ft.) away

• Fanless design eliminates operating noise and lowers energy

consumption

• Extreme operating temperature range -40 to 75 °C (-40 to

167 °F)

• Redundant power inputs with overload current protection

• Includes DIN-Rail mount and wall mount

• Power supply sold separately (model TI-S24048)

• NDAA / TAA compliant (U.S. and Canada only)

TRENDnet’s 90W 2-Port Industrial 2.5G PoE++ Injector, model TI-IG290, allows users to add PoE++ power to a non-PoE 2.5G

switch. Connect the 2-port industrial 2.5G PoE++ injector to a non-PoE 2.5G switch, and then run Ethernet cables up to 100 meters

(328 ft.) to network two PoE/PoE++ devices. This multi-port industrial 2.5G PoE++ injector supplies up to 90W of power to two PoE

devices with a total PoE budget of 180W. The fanless design conveniently eliminates operating noise and lowers unnecessary

energy consumption. The dual port industrial 2.5G PoE++ injector is equipped with an IP30 rated metal enclosure, designed to

withstand a high degree of vibration and shock, while operating within a wide temperature range of -40° – 70° C (-40° – 158° F) for

harsh industrial environments.

TI-IG290

2-Port PoE

This multi-port 2.5G PoE++ injector

supplies up to 90W of power to two PoE

devices with a total PoE budget of 180W.

2.5G Ports

Features two high-speed 2.5G ports

(data in) and two high-speed 2.5G PoE++

ports (data + PoE out).

Industrial Design

IP30 rated metal enclosure with a high

degree of vibration and shock resistance,

and a wide operating temperature range

of -40° – 70° C (-40° – 158° F).

NETWORKING SOLUTION

TI-IG290

FEATURES

2-Port PoE++

The 2-port industrial 802.3 bt

PoE++ injector supplies up to 90W

of power to two PoE (IEEE

802.3af), PoE+ (IEEE 802.3at), or

PoE++ (IEEE 802.3bt) devices

Industrial Design

Equipped with an IP30 rated metal

enclosure, designed to withstand a

high degree of vibration and shock,

while operating within a wide

temperature range of -40° – 70° C

(-40° – 158° F) for industrial

environments

2.5G Ports

2 x 2.5G ports (data in) and 2 x

2.5G PoE++ ports (data + PoE out)

PoE Distance

Provides two PoE network

connections up to 100m (328 ft.)

away from the 2-port industrial

802.3bt PoE++ adapter

LED Indicators

LEDs indicate PoE connectivity and

power status

Shock and Vibration Resistant

Rated for shock (EN 60068-2-27),

freefall (EN 60068-2-32), and

vibration (EN 60068-2-6)

Grounding Point

Grounding point protects equipment

from external electrical surges

Fanless Design

Fanless design on the 2-port

industrial 2.5G PoE++ injector

conveniently eliminates operating

noise and lowers unnecessary

energy consumption

TI-IG290
