TRENDnetUser’sGuide



CoverPage

  



©Copyright2015TRENDnet.AllRightsReserved.  



TRENDnetUser’sGuide



TableofContents

i

Contents



ProductOverview.............................................................................1



PackageContents..........................................................................................................1



Features.........................................................................................................................1



ProductHardwareFeatures...........................................................................................2



InstallingyourPowerlineAdapters...................................................4



BeforeyouInstall...........................................................................................................4



ConnectaPowerlineadaptertoyourrouter................................................................4



Addadapterstoyournetwork......................................................................................5



SecuringyourPowerlineNetwork....................................................5



UsingtheSyncbutton....................................................................................................6



ChangeyourdefaultencryptionkeyusingtheSyncbutton.....................................6



AddadaptersusingtheSyncbutton.........................................................................8



UsingthePowerlineUtility.............................................................10



Installingtheutility......................................................................................................10



PowerlineUtilityOverview.....................................................................................11



Addadaptersintheutilityandcreateacustomizedencryptionkey.....................15



UpgradeFirmware..................................................................................................17



RestartorReset.......................................................................................................18



Troubleshooting.............................................................................19



Appendix........................................................................................20



  



©Copyright2016TRENDnet.AllRightsReserved.  



TRENDnetUser’sGuide



TPL‐407E/TPL‐407E2K

1

ProductOverview



TPL‐407E   TPL‐407E2K



PackageContents

TPL‐407Epackageincludes:

 1xTPL‐407E

 QuickInstallationGuide

 Networkcable(1.5m/5ft.)



TPL‐407E2Kpackageincludes:

 2xTPL‐407E

 QuickInstallationGuide

 2xNetworkcables(1.5m/5ft.)



Features



The Powerline 500 AV Adapter with Built‐In Outlet, model TPL‐407E, uses existing

electrical lines to create a high speed network. Two adapters are needed to start a

network.Connectoneadaptertoyourrouterandpluganotheradapterintoanoutleton

yourelectricalsystemforinstanthigh

speednetworkaccess.Thecompactformfactor

savesspaceandoffersanadditionalelectricaloutlet.



Powerline500

Powerlinenetworkingoverexistingelectricallines**

Built‐InOutlet

Neverloseanelectricaloutletwiththebuilt‐insocket—Plugtheadapterintoanoutlet,

thenpluginotherdevices

NoiseFilter

Advancedelectrical

noisefilterboostsperformance

MultipleAdapters

Twoadaptersareneedstostartanetwork—useupto8adapters*

EasyInstallation

Simplyplugintheadapters

CrossCompatible

TRENDnetPowerlineHomeplugAVadaptersworktogether***

SyncButton

PresstheSyncbuttontochangeexistingencryptionkeys

EnergySavings

PowerSavemode

reduceselectricalconsumptionbyupto80%



*Maximumof8adapters(nodes)recommendedforstreamingvideoacrossyournetwork.

** 500Mbps is the maximum theoretical Powerline data rate.Actual throughput will vary

dependingonenvironment.

***NetworkedPowerlinedevicesneedto beplugged intopoweroutletsthatareonthe same

electricalsystem.

****GFCIoutlets

andAFCIcircuitbreakersmaydegradePowerlinenetworksignals.

Produktspecifikationer

Varumärke:	Trendnet
Kategori:	Nätverkskort/adapter
Modell:	TPL-407E2K
Vikt:	102 g
Bredd:	59 mm
Djup:	55 mm
Höjd:	78 mm
LED-indikatorer:	LAN, Power
Wi-Fi:	Nej
Snabbstartsguide:	Ja
Certifiering:	CE, FCC
Gränssnitt:	Ethernet
Kabelteknik:	10/100BaseT(X)
Maximal räckvidd:	300 m
Kompatibla operativsystem:	Windows 7 (32/64-bit)\nWindows Vista (32/64-bit)\nWindows XP (32/64-bit)
Värdgränssnitt:	PowerPlug
Maximal dataöverföringshastighet:	500 Mbit/s
Full duplex:	Ja
Produktens färg:	Vit
bruksanvisning:	Ja
Windows-operativsystem som stöds:	Ja
Nätverksegenskaper:	Snabb Ethernet
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Strömförbrukning (vanlig):	3 W
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-10 - 55 ° C
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100-240 V
Kryptering/säkerhet:	128-bit AES
Kabel inkluderad:	LAN (RJ-45)
Frekvensområde:	0.002 - 0.068 GHz
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Ja
Stöd för nätverksprotokoll:	IPv6
Växelström Frekvens:	50 - 60 hz
Modulator:	1024-QAM, 256-QAM, 64-QAM, 8-QAM, BPSK, OFDM, QPSK, ROBO
Lednings Protokoll:	IGMP
Kommunikationsstandarder:	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Intern:	Nej
Flödeskontroll:	Ja
Efterlever industristandard:	IEEE 802.3, IEEE 802.3, IEEE 802.3x, IEEE 1901
Strömlysdiod:	Ja
Omgivningstemperatur vid drift:	32 - 104 ° F
Tillgängliga dataöverföringshastigheter:	10/100/200 Mbit/s
Koppar Ethernet-kablar teknik:	100BASE-T, 100BASE-TX, 10BASE-T
Media anslutningsprotokoll:	TDMA, CSMA/CA
