TRIXIE Heimtierbedarf GmbH & Co. KG · D-24963 Tarp · www.trixie.de
Aufbauanleitung & Stückliste/Assembling Instruction & Parts List
Art.-Nr. Item no./ 44601
Pos. 14
Pos. 15
Pos. 17
Art.-Nr./
Item No.
Kratzbaum/
Scratching Post
Farbe/Colour Höhe/Height
Farbschlüssel/
Colour Code
4460 Marta 1beige-fuchsia/beige-fuchsia 130 cm
Pos. Nr./
Pos. No.
Bezeichnung/
Description
Abmessung/
Measurement in mm
Anzahl/
Quantity
Art. Nr./
Item No.
Pos. 1 Bodenplatte/Bottom plate 1000
×
20 × 450 1 44601-10
Pos. 2 Höhle/Cave ø 350 × 590 1 44601-11
Pos. 2a Kissen ø 340 1 44601-40
Pos. 3 Trittbrett/Footboard 280 × 200 × 20 1 44601-12
Pos. 4 Liegeplatte, mit Loch und Ball/Lying plate, with hole and ball 570 × 20 × 450 1 44601-13
Pos. 5 Kratzplatte mit Ball/Scratching plate with ball ø 290 × 25 1 44601-14
Pos. 6 Liegeplatte für Bettchen/Lying plate for bed ø 370 × 20 1 44601-15
Pos. 7 Kuschelsack/Cuddly bag ø 400 × 140 1 44601-50
Pos. 8 Bettchen für Liegeplatte/Bed for lying plate ø 390 × 80 1 44601-51
Pos. 9 Stamm/Post ø 90 × 250 1 4460-30
Pos. 10 Stamm/Post ø 90 × 270 3 4460-31
Pos. 11 Stamm, mit Stehbolzen/Post, with spacer bolt ø 90 × 310 1 4460-32
Pos. 12 Stamm/Post ø 90 × 560 1 4460-33
Pos. 13 Stamm, mit Stehbolzen/Post, with spacer bolt ø 90 × 560 1 4460-34
Pos. 14 Senkkopfschraube/Countersunk bolt M 8 × 50 3 4460-60
Pos. 15 Senkkopfschraube/Countersunk bolt M 8 × 35 1 4460-60
Pos. 16 Gewindestange/Thread rod M 8 × 80 4 4460-60
Pos. 17 Gewindestange/Thread rod M 8 × 48 1 4460-60
Pos. 18 Linsenkopfschraube/Rounded head screw M 6 × 15 1 4460-60
Pos. 19 Unterlegscheibe/Washer M 6 × 12 1 4460-60
Pos. 20 Hutmutter/Cap nut screw M 6 × 10 1 4460-60
Pos. 21 Inbusschlüssel/Allen key 5 1 4460-60
140313
93975
D
Hinweis
Bitte zuerst den Stamm (Pos. 13) an die obere Platte (Pos. 4)
anschrauben.
Dieser Artikel sollte von einer erwachsenen Person aufgebaut werden.
G
Advice
Please fix the the post (pos. 13) at the upper plate (pos.4) first.
This product should be assembled by an adult.
Pos. 18
Pos. 20
