TRT-BA-BX50MID-BX50MIDF-BX50MIDC-TC2019-46-001-EN
BX50 MID / BX50 MID F / BX50 MID C
EN
OPERATING MANUAL
ENERGY CONSUMPTION
MEASURING DEVICE
2 EN
energy consumption measuring device BX50 MID / BX50 MID F / BX50 MID C
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the device................................................3
Transport and storage...........................................................5
Operation ...............................................................................5
Maintenance and repair ........................................................6
Errors and faults....................................................................6
Disposal .................................................................................6
Overview of the MID measuring devices used .....................6
Declaration of conformity .....................................................6
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
BX50 MID
https://hub.trotec.com/?id=43926
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• The device is supplied with a warning sign. Prior to initial
start-up, make sure to paste the corresponding warning
sign in your local language over the one present at the rear
of the device as described in chapter Operation.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Do not immerse the device in water. Do not allow liquids to
penetrate into the device.
• Protect the device from permanent direct sunlight.
• Do not cover the device! With a higher power input the
device will warm up. Covering the device may cause
overheating and consequently may cause a fire!
EN 3
energy consumption measuring device BX50 MID / BX50 MID F / BX50 MID C
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device.
• Check the device for potential damage before each
application. Do not use any defective devices.
• Do not connect several devices by plugging one into
another.
• Only operate the device in dry surroundings.
• Please note that the device is only de-energized when the
plug has been disconnected from the mains.
• Observe the storage and operating conditions as given in
the Technical data chapter.
Intended use
Only use the device for measurements on circuits directly
connected to the low-voltage grid via a plug connection, e. g.
household appliances, portable electrical appliances etc., whilst
adhering to the technical data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Improper use
The device is not suitable for use with any type of extension
cables. The device may not be used in potentially explosive
atmospheres, when wet or very humid.
Personnel qualifications
People who use this device must:
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The device measures the energy demand of aBX50 MID
connected terminal device. The device is MID-calibrated and
cannot be manipulated.
The following values can be indicated on the display's value:
• Total energy consumption (kWh, non-resettable)
• Energy consumption (kWh, resettable)
• Current mains voltage(V)
• Current amperage(A)
• Current power consumption of the connected device(W)
• Power factor
• Current mains frequency(Hz)
• Highest previously measured power consumption in watts
(resettable)
The device comes with display illumination in order to enhance
the legibility.
