Sida 1/16
TRT-BA-PD200-TC2020-28-002-EN
PD200
EN
OPERATING MANUAL
PULSE CURRENT MEASURING
SYSTEM
2 EN
pulse current measuring system PD200
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the device................................................4
Transport and storage...........................................................5
Operation ...............................................................................6
Available accessories..........................................................13
Maintenance and repair ......................................................13
Errors and faults..................................................................14
Disposal ...............................................................................14
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
PD200
https://hub.trotec.com/?id=44626
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Protect the device from permanent direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device.
• Never measure live parts.
• The only party responsible for determining measured
results to be valid, drawing conclusions and deriving
actions is the user! The correctness of the results
presented is excluded from any liability or guarantee.
Liability for damages which have been caused by utilising
the presented measured results is strictly excluded.
EN 3
pulse current measuring system PD200
Intended use
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
The device is a professional measuring device based on the
pulse current method for the pinpoint location of grounded leaks
in non-conducting plastic foils. Fields of application are i.a.:
• warm roofs, cold roofs and greened flat roofs
• roof-top terraces
• balconies
• lined ponds and swimming pools
• plastic covered landfills and dumps
The power supply has to comply with the device type and the
mains connection must be provided with a proper protective
earth conductor. The device may only be used for the given
intended use while complying with the specified technical data.
Any other use is considered misuse and contrary to the intended
use.
Foreseeable misuse
Do not use the device in potentially explosive atmospheres, for
measurements in liquids or at live parts.
Any unauthorised changes, modifications or alterations to the
device are forbidden.
Personnel qualifications
People who use this device must:
• Use the pulse current measuring system in accordance
with safe working procedures.
• be aware of the dangers that occur when working with
electric devices in damp areas.
• take measures to protect themselves from direct contact
with live parts.
• have read and understood the operating manual, especially
the Safety chapter.
Electrically skilled person
Electrically skilled personnel must be able to read and
understand electric circuit diagrams, to put electrical systems
into service and to maintain them, to wire control cabinets, to
ensure the functionality of electrical components and to identify
possible hazards from electrical and electronic systems.
Residual risks
Warning of electrical voltage
Risk of death due to electric shock!
An electric shock can result in severe personal injury or
death! The device may only be used in accordance
with all safety instructions listed here.
Warning of electrical voltage
Risk of electric shock due to incorrect assembly!
Faulty electrical installation or excessive mains voltage
can lead to electric shocks. The device may only be
installed whilst adhering to all listed assembly
instructions and technical data.
Warning of electrical voltage
There is a risk of a short-circuit due to liquids
penetrating the housing!
Do not immerse the device and the accessories in
water. Make sure that no water or other liquids can
enter the housing.
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
