TRT-BA-TTV1500-3000-TC221223TTRT01-006-EN

TTV 1500 / TTV 3000

ORIGINAL INSTRUCTIONS

CONVEYING FAN

2 EN

conveying fan TTV 1500 / TTV 3000

Table of contents

Notes regarding the instructions .........................................2

Safety .....................................................................................2

Information about the device................................................4

Transport and storage...........................................................5

Assembly and start-up..........................................................5

Operation ...............................................................................6

Available accessories............................................................6

Errors and faults....................................................................7

Maintenance ..........................................................................7

Technical annex.....................................................................7

Disposal .................................................................................8

Notes regarding the instructions

Symbols

Warning of electrical voltage

This symbol indicates dangers to the life and health of

persons due to electrical voltage.

Warning

This signal word indicates a hazard with an average

risk level which, if not avoided, can result in serious

injury or death.

Caution

This signal word indicates a hazard with a low risk

level which, if not avoided, can result in minor or

moderate injury.

Note

This signal word indicates important information (e.g.

material damage), but does not indicate hazards.

Info

Information marked with this symbol helps you to carry

out your tasks quickly and safely.

Follow the manual

Information marked with this symbol indicates that the

instructions must be observed.

Wear hearing protection

Information marked with this symbol indicates that you

should wear hearing protection.

You can download the current version of the instructions and

the EUdeclaration of conformity via the following link:

TTV 1500

https://hub.trotec.com/?id=39417

TTV 3000

https://hub.trotec.com/?id=43011

Safety

Read this manual carefully before starting or using the

device. Always store the manual in the immediate vicinity

of the device or its site of use.

Warning

Read all safety warnings and all instructions.

Failure to follow the warnings and instructions may

result in electric shock, fire and/or serious injury.

Save all warnings and instructions for future

reference.

This appliance can be used by children aged from

8years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved.

Children shall not play with the appliance. Cleaning and

user maintenance shall not be made by children

without supervision.

• Do not use the device in potentially explosive rooms or

areas and do not install it there.

• Do not use the device in aggressive atmosphere.

• Only put up the device in an upright, stable position on firm

ground.

• Observe a minimum distance of 3m between walls,

objects and the suction side.

• Let the device dry out after a wet clean. Do not operate it

when wet.

• Do not use the device with wet or damp hands.

• Do not expose the device to directly squirting water.

• Never insert any objects or limbs into the device.
