Sida 1/20
TRT-BA-VSP3041-TC230915TTRT01-003-EN
VSP3041
EN
INSTRUCTIONS
VSP INSPECTION SYSTEM
2 EN
VSP inspection system VSP3041
Table of contents
Information on the use of these instructions .......................2
Safety .....................................................................................2
Information about the device................................................4
Transport and storage...........................................................8
Operation ...............................................................................8
Software...............................................................................15
Errors and faults..................................................................19
Maintenance and repair ......................................................19
Disposal ...............................................................................20
Information on the use of these instructions
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Notice
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
instructions must be observed.
You can download the current version of the instructions and
the EUdeclaration of conformity via the following link:
VSP3041
https://hub.trotec.com/?id=43120
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Do not use the device in atmospheres containing oil,
sulphur, chlorine or salt.
• Protect the device from permanent direct sunlight.
• Only use the device in de-energized facilities and objects.
For reasons of safety, de-energize all plant components
and objects prior to every inspection.
• Before using the measuring probes and camera heads,
de-energize any circuits located in walls.
• Before using the measuring probes and camera heads in
metal pipes inside a wall, have an authorised specialist
company carry out a check to ensure that the metal pipes
are not electrically charged.
• For reasons of safety, do not use the measuring probes
and camera heads for inspections in moving parts.
• Do not open the device.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Observe the storage and operating conditions (see
Technical data).
Intended use
Only use the device for the visualization of objects.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Any use other than the intended use is regarded as misuse.
EN 3
VSP inspection system VSP3041
Reasonably foreseeable misuse
Do not use the device:
• in potentially explosive atmospheres
• in live environments
• in unsuitable liquids, e.g. acids and alkalis
• on people or animals
Do not use the control unit with display underwater.
Any unauthorised modifications, alterations or structural
changes to the device are forbidden.
Personnel qualification
People who use this device must:
• take measures to protect themselves from direct contact
with live parts.
• have read and understood the instructions, especially the
Safety chapter.
Safety signs and labels on the battery
Observe the label attached to the battery with the following
warnings:
Safety symbol Meaning
This symbol indicates that you must be aware
of the dangers that can occur when working
with the battery.
This symbol indicates that the operating manual
must be read before using the appliance.
Do not let the battery come into contact with
water! Avoid direct moisture. There is a risk of
explosion!
Do not expose the battery pack or tool to fire or
excessive temperature! Do not let the battery
come into contact with fire! Avoid direct solar
radiation. There is a risk of explosion!
This device may only be repaired and serviced
by the manufacturer. Any unauthorised
modifications, alterations or structural changes
to the device are forbidden.
Risk of injury due to electrical voltage. Damage
to the device may occur.
Residual risks
Warning of electrical voltage
Risk of death due to electric shock!
An electric shock can result in severe personal injury or
death! The device may only be used in accordance
with all safety instructions listed here.
Warning of electrical voltage
Electric shock due to contact with live parts! Do not
touch any live parts. Secure neighbouring live parts by
covering them or by switching them off.
Warning of electrical voltage
There is a risk of a short-circuit due to liquids
penetrating the housing!
Do not immerse the device and the accessories in
water. Make sure that no water or other liquids can
enter the housing.
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of explosive substances
Do not expose the batteries to temperatures above
60°C! Do not let the batteries come into contact with
water or fire! Avoid direct sunlight and moisture. There
is a risk of explosion!
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Lithium-ion batteries might catch fire in case of
overheating or damage. Ensure a sufficient distance to
heat sources, do not subject lithium-ion batteries to
direct sunlight and make sure not to damage the
casing. Do not overcharge lithium-ion batteries. If the
battery is not permanently installed in the device, only
use smart chargers that switch off automatically when
the battery is fully charged. Charge lithium-ion
batteries in due time before they are discharged
completely.
