TTP-225 Series

Desktop Barcode Printers

User Manual

Series Lists:

TTP-225 / TTP-323

◼ Thermal Transfer

◼ Direct Thermal

The copyright in this manual, the software and firmware in the printer described are owned by TSC Auto ID Technology Co., Ltd.

CG Triumvirate is a trademark of Agfa Corporation. CG Triumvirate Bold Condensed font is under license from the Monotype

Corporation. Windows is a registered trademark of Microsoft Corporation.

All other trademarks are the property of their respective owners. Information in this document is subject to change without

notice and does not represent a commitment on the part of TSC Auto ID Technology Co. No part of this manual may be

reproduced or transmitted in any form or by any means, for any purpose other than the purchaser’s personal use, without the

expressed written permission of TSC Auto ID Technology Co.



II
Table of Contents
Introduction .......................................................................................................................................................................................................1
Operation Overview ...........................................................................................................................................................................................2
1 Unpacking and Inspection ............................................................................................................................................................................2
2 Printer Overview ..........................................................................................................................................................................................3
2.1 Front View .............................................................................................................................................................................................3
2.2 Interior View ..........................................................................................................................................................................................4
2.3 Rear View ..............................................................................................................................................................................................5
Setup .................................................................................................................................................................................................................6
1 Setting up the Printer ...................................................................................................................................................................................6
2 Loading the Ribbon ......................................................................................................................................................................................7
3 Loading the Media .......................................................................................................................................................................................8
4 Loading the Media in Peel-off Mode (Option) ...............................................................................................................................................9
5 Loading the Media in Cutter Mode (Option)................................................................................................................................................ 10
6 Loading Thick Media (Thickness is 0.19 mm) ............................................................................................................................................ 11
7 Install MicroSD Memory Card .................................................................................................................................................................... 12
8 Using the PC USB Keyboard with Printer USB Host Interface (Factory option) .......................................................................................... 13
LED and Button Functions ............................................................................................................................................................................... 14
1 LED Indicator ............................................................................................................................................................................................. 14

Produktspecifikationer

Varumärke:	TSC
Kategori:	Etikettskrivare
Modell:	TTP-225
Vikt:	2450 g
Bredd:	140 mm
Djup:	241 mm
Höjd:	177 mm
Färg:	Nej
Upplösning:	128 x 64 pixlar
Wi-Fi:	Nej
Maximal upplösning:	203 x 203 DPI
Certifiering:	FCC Class B, CE Class B, C-Tick Class B, UL, CUL, TÜV/Safety, CCC, RoHS, WEEE
Internminne:	8 MB
Flashminne:	4 MB
Maximal rulldiameter:	127 mm
Skrivhastighet:	127 mm/sek
Inbyggda streckkoder:	AZTECCODE, CODABAR (NW-7), Code 11, Code 128 (A/B/C), Code 39, Code 93, Data Matrix, EAN128, EAN13, EAN8, GS1 DataBar, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E
Vertikal utskrift:	Ja
Maximal kabellängd:	2.286 m
Produktens färg:	Beige
Windows-operativsystem som stöds:	Ja
Mac-operativsystem som stöds:	Ja
Inbyggd processor:	Ja
Temperatur vid drift:	5 - 40 ° C
Temperaturintervall (förvaring):	-40 - 60 ° C
Intervall för relativ operativ luftfuktighet:	25 - 85 %
Fuktighet (förvaring):	10 - 90 %
Hållbarhetscertifiering:	ENERGY STAR
AC-inspänning:	100 - 240 V
Kabel inkluderad:	AC, USB
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Ja
Växelström Frekvens:	50 - 60 hz
Displaytyp:	LCD
Antal USB 2.0 anslutningar:	1
USB-port:	Ja
Bluetooth:	Nej
Linux operativsystem som stöds:	Ja
Harmonized System (HS)-kod:	84433210
AC-adapter, nätspänning:	24 V
AC-adapter, maxbelastning:	2.5 A
Utskriftsteknologi:	Direkt termisk/termisk överföring
Språk för sidbeskrivning:	TSPL-EZ
Medelströmförbrukning vid utskrift:	60 W
Media-tjocklek:	0.06 - 0.19 mm
Max utskriftsupplösning, bredd:	54 mm
Stöds pappersbredd:	15 - 60 mm
Bandlängd:	90 m
Kortaste utskriftslängd:	2286 mm
Roterad utskrift:	Ja
