Model: DH2300

Buzzer

StatusBeeper

Beep once

Beep once

Beep 3 times

Beep every 3 seconds

Beep every 2 seconds

Power on

Reset network and password

System reset

Hard drive error

System error

Hardware Specification

Product Name

Model

Operating System

Processor

Memory Capacity

System Storage

Storage Mode

Supported Drive

HDMI Port

RJ45 Ethernet Port

Network Attached Storage

DH2300

UGOS Pro

RK3576

4 GB or 8 GB (depends on the actual

configuration of the device model);

non-expandable

32 GB eMMC

JBOD/Basic/RAID 0/RAID 1

2 SATA (6 Gbps), supports 2.5"/3.5" hard drive

1 HDMI port, supports resolutions up to 4K

1 1GbE port, supports 1 Gbps and backward

compatible

1 Type-C USB 3.2 Gen 1 port, theoretical

transfer rate of up to 5 Gbps

2 USB 3.2 Gen 1 ports, theoretical transfer

rate of up to 5 Gbps

12V 4.2A

Temperature: 0℃~40℃/32℉~104℉

Humidity: 10% to 85%

L151×W98×H213.7 (mm)

Notices

· Please place the NAS device as referred to in the illustrations in

this manual.

· Please put the NAS in an environment with a stable temperature

and low humidity. Avoid direct sunlight or any liquids coming into

contact with the device.

· In the event of a thunderstorm or inconsistent voltage, power off

the device to avoid potential damage.

· Keep the device away from heat sources or humid environments

to reduce the risk of fire or electric shock.

· Do not insert foreign objects into the NAS to avoid damage

caused by abnormal use or short circuit.

· Please power off the NAS device before cleaning. When cleaning,

use a moist wipe. Do not use chemicals or spray cleaners.

· Do not drop, squeeze, violently impact, or throw the NAS.

· This device contains small parts and pieces, please keep it out of

reach of children to prevent choking due to unintended swallowing.

· Do not dismantle or fix the NAS device by yourself. Improper

disassembly and assembly may cause electric shock or other

safety hazards. If repair or replacement parts and/or accessories

are required, please contact UGREEN NAS customer service.

· This product contains a built-in Lithium Manganese Dioxide battery.

Do not dismantle, crush, squeeze, or expose it to fire.

· Do not expose this product to excessive temperatures.

· Please keep this product out of reach from children.

· If the battery has been accidentally swallowed or placed inside

any part of the body, it may cause severe internal burns or other

hazards. Seek medical attention immediately.

· Do not charge the battery. If the battery is low, promptly replace

it. When replacing the battery, ensure the battery polarity is not

reversed.

· If battery leakage occurs, avoid contacting with skin or eyes. In

case of contact with skin or eyes, rinse with water and seek

medical attention immediately.

· Keep depleted batteries out of reach from children, and dispose of

or recycle it properly in accordance to local laws and regulations.

Ⅱ. Hardware Setup

Before Setup

Do NOT insert or remove any hardware components while the NAS

device is powered on. Before performing any installation, removal,

or maintenance tasks, ensure that the device is shut down and

disconnected from the power supply to prevent possible file loss,

data corruption, or damage to the drive.

Tool Preparation

Note:

· It is recommended to use new drives. When installing Any hard drives,

the NAS system will format the drives, erasing ALL existing data. Ensure

any important data is backed up prior to installation.

· When setting up a "RAID mode", it is recommended to use hard drives

with the same capacity. This allows you to maximize storage capacity

utilization and reduces the risk of data loss.

Before installing the hardware, please prepare the following tools

and parts:

Included

screwdriver

Included

screws

At least one 3.5'' or 2.5''

SATA hard drive

123

Install 2.5'' Hard Drive

1. Install the drive: Flip the tray to its back and align the four empty

screw spaces at the bottom of the drive with the screw holes on

the tray.

2. Secure the drive: Tighten the screws to fasten the hard drive to tray.

3. Put back the tray: Insert the loaded drive tray back and push it till

the end, then put back the top cover.

Pull out Hard Drive Tray

1. Remove the top cover.2. Gently press the buckle

on the tray end, then

pull out the drive tray.

Install 3.5'' Hard Drive

1. Install the drive: Put the drive onto the tray. Ensure the screw

holes on the tray (three on each side) are aligned with the screw

holes on the hard drive.

2. Secure the drive: Tighten the screws to fasten the hard drive to tray.

3. Put back the tray: Insert the loaded drive tray back and push it till

the end, then put back the top cover.

Metal connectors

face down

Start up Your NAS

1. Use an Ethernet cable to connect the NAS to a LAN port on the

router or the Ethernet switch.

2. Connect a power supply to the device using the power adapter.

3. Press the power button to turn it on. To turn off, press and hold

the button for about 5s.

Note:

· To ensure data transfer efficiency, it is recommended to use a router or

switch with 10-Gigabit LAN ports or higher and to connect the NAS

using the included Ethernet cable.

· After powering on, you can download "UGREEN NAS" then go to

"Control Panel" > "Hardware & Power" to select automatic startup

after powering on.

Included

power

adapter

Only use the original power adapter or a safety-certified power

adapter that meets the device's power specifications to prevent

potential explosion hazards.

Warning

Firmware Update

ONLY update firmwares with stable power supply.

Do NOT disconnect the power supply during the update process.

Ⅰ. Preparation

Package Contents

UGREEN NASync DH2300

MBO

EJTL!2EJTL!3VTC.D

Product Overview

Indicator

1×

User Manual

1×

Warranty Card

1×

Main Unit

1×

Power Adapter

1×

HDMI Cable

1×

Ethernet Cable

Screws and

Screwdrivers

Power

Indicator

NFC

Detection

Area

Network

Indicator

Hard Drive Indicator

Type-C USB 3.2 Gen 1 Port

Power

Button

2×USB 3.2 Gen 1 Port

1GbE Port

HDMI Port

Reset Hole

Power Port

LED

Power

indicator

Hard drive

indicator

LAN

network

indicator

White

Blinking

(once per 0.5 seconds)

Blinking

(once per second)

Blinking

(once per second)

Blinking

On

Off

Power off

Device error

Error

Internet connected

Read/Write

Running

Hibernation

Internet not connected

Data transfer

(Internet not connected)

On

Blinking

On

Blinking

White

Red

Red

White

Red

ColorStatusDescription

Power on

System hibernation

Data transfer

(Internet connected)

On

USB Port

Power Input

Working Environment

Product Dimensions

KEEP OUT OF REACH

OF CHILDREN

WARNING

MBO

EJTL!2EJTL!3VTC.D

MBO

EJTL!2EJTL!3VTC.D

MBO

EJTL!2EJTL!3VTC.D

MBO

EJTL!2EJTL!3VTC.D

MBO

EJTL!2EJTL!3VTC.D

MBO

EJTL!2EJTL!3VTC.D

MBO

EJTL!2EJTL!3VTC.D

LAN
