PAGE 1 OF 6 1124 IH-1205
1-800-295-5510
uline.com
CHROME
WIRE SHELVING
Para en Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Figure 3
ASSEMBLY
SELF-LEVELING FEET OR CASTER INSTALLATION
Figure 1
Figure 2
SELF-LEVELING FEET
NOTE: If installing casters, do not install self-leveling feet.
1. Ensure post is positioned as shown. (See Figure 1)
2. Insert self-leveling foot into open end of post.
3. Use a rubber mallet/hammer or tap on ground until self-leveling foot slides
into post.
4. Repeat steps 2 and 3 for remaining posts.
CASTERS (ULINE MODEL # H-1205WH SOLD SEPARATELY)
1. Ensure post is positioned as shown. (See Figure 2)
2. Engage the wheel brakes to keep casters from rolling during assembly.
Use a rubber mallet to tap caster stems into posts. (See Figure 2)
1. Start with the lowest shelf. Snap the interlocking pieces of a
shelf support (wide end down) around the post at the lowest
groove where shelf is to be located. Slide the support up or
down until it snaps onto the groove. Add a shelf support to the
same place on the remaining posts. (See Figure 3)
NOTE: NSF requires food service applications to keep the
lowest shelf at least 6" above the floor.
SHELF PARTSPOST PARTS
NOTE: Self-leveling feet are located within
post carton.
Self-Leveling Foot x 4Post x 4
NOTE: Two-shelf wire shelving units include
two shelves and eight sets of shelf supports.
Shelf x 4Shelf Support x 16 Sets
TOOL NEEDED
Rubber Mallet
(optional)
