IAN 274742IAN 274742
Walser GmbH
Radetzkystraße 114
A-6845 Hohenems
Email: office@walsergroup.com
www.walsergroup.com
Last Information Update/Stand der Informationen: 03 / 2016
Ident.-No.: 274742012016-1
DE
FI
PL
GB IE
SE
AT CH
GB/IE Assembly and safety advice Page 5
FI
Asennus
- ja turvaohjeet
Siv
u
6
SE
Monterings- och säkerhetsanvisningar Sidan 7
PL Wskazówki dotyczące montażu oraz bezpieczeństwa Strona 8
LT
Montav
imo ir saugos nurodymai
Puslapis 9
DE/A
T/CH Montage- und Sicherheitshinweise Seite 10
Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the
product.
Käännä ennen lukemista molemmat kuvalliset sivut esiin ja tutustu seuraavaksi tarkemmin tuotteen kaikkiin
osiin.
Przed przeczytaniem należy rozłożyć obie strony z ilustracjami, a następnie zapoznać się z wszystkimi
funkcjami produktu.
Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend mit
allen Funktionen des Produkts vertraut.
Vik ut båda bildsidorna och p1-ha den till hands när du läser igenom anvisningarna. Gör dig sedan bekant med
produktens funktioner.
LT
Prieš pradėdami skaityti atlenkite abu puslapius su paveikslėliais ir po to susipažinkite su visomis gaminio
funkcijomis.
DE
FI
PL
SE
LT
GB IE
AT CH
CAR SEAT COVER SET
Assembly and safety advice
AUTON ISTUINPÄÄLLINEN
Asennus- ja turvaohjeet
ZESTAW POKROWCÓW
SAMOCHODOWYCH
Wskazówki dotyczące montażu oraz bezpieczeństwa
BILKLÄDSEL-SET
Monterings- och säkerhetsanvisningar
AUTOMOBILIO SĖDYNIŲ
UŽVALKALŲ RINKINYS
Montavimo ir saugos nurodymai
AUTOSITZBEZUG-SET
Montage- und Sicherheitshinweise
CAR SEAT COVER SET
3
FI
PL LT
SE
FI
PL
DE
SE
LT
AT CH
Toimituksen sisältö
2 x etupenkin päällinen (1 tai 2 osaa, aina mallin mukaan)
2–5 x pääntuen päällinen (aina mallin mukaan)
1 x takaistuimen selkänojan päällinen ( 1 - 5 osaa, aina mallin mukaan)
1 x takaistuimen istuinsuojan päällinen (ei voi jakaa osiin)
Metallihakaset (löytyvät pääntuen päällyksistä)
Malliluettelo
Zawartość zestawu
2 pokrowce na fotele przednie (w 1 lub 2 częściach, w zależności od wersji artykułu)
2–5 pokrowców na zagłówki (w zależności od wersji artykułu)
1 pokrowiec na oparcie siedzenia tylnego (w 1 do 5 częściach, w zależności od wersji artykułu)
1 pokrowiec na powierzchnię siedziska siedzenia tylnego (niepodzielny)
Metalowe haki (znajdują się w pokrowcach na zagłówki)
Wykaz modeli
Lieferumfang
2 x Bezüge Vordersitze (in 1 oder 2 Teilen, je nach Artikelausführung)
2–5 x Bezüge Kopfstützen (je nach Artikelausführung)
1 x Bezug Rücksitz-Lehne (in 1 bis 5 Teilen, je nach Artikelausführung)
1 x Bezug Rücksitz- Sitzfläche (nicht teilbar)
Metallhaken (Befinden sich in den Kopfstützenbezügen)
Typenliste
Leveransens omfattning
2 x överdragsklädslar framstolar (i 1 eller 2 delar beroende på artikelutförande)
2–5 x överdrag nackstöd (beroende på artikelutförande)
1 x överdrag baksätesryggstöd (i 1 till 5 delar, beoende på artikelutförande)
1 x överdrag sittyta baksäte (ej delbar)
Metallhake (finns i nackstödsöverdragen)
Typlista
Pristatomas komplektas
2 priekinių sėdynių užvalkalai (1 arba 2 dalių, atsižvelgiant į prekės tipą)
2–5 galvos atramų užvalkalai (atsižvelgiant į prekės tipą)
1 galinės sėdynės atlošo užvalkalas (nuo 1 iki 5 dalių, atsižvelgiant į prekės tipą)
1 galinės sėdynės sėdimojo paviršiaus užvalkalas (nepadalytas)
Metaliniai kabliukai (jie yra galvos atramų užvalkaluose)
Tipų sąrašas
GB IE
Scope of delivery
2 x covers for front seats (in 1 or 2 parts according to design)
2 - 5 x covers for headrests (according to design)
1 x cover for rear backrest (in 1 to 5 parts according to design)
1 x cover for back seat (not separable)
Metal hooks (located in the headrest covers)
List of types
2 3 4
5 6 7 8
9 10 11 12
13 14 15 16
17 18 19 20
21 23 24
1
22
79407_uls_Sitzbezug Racing_cover_LB1.indd 5 18.09.12 11:44
25 26 27
28 29 30
31 32 33 34
35 36 37
38 39 40
43 44 45
41
42
79407_uls_Sitzbezug Racing_cover_LB1.indd 8 18.09.12 11:44
GB/IE 5
Car seat cover set
• Introduction
We congratulate you on your purchase. You have chosen a high quality product.
The instructions for use are to be considered as part of this product. Before using the
product, please familiarise yourself with all the safety information and instructions
for use. Only use the product as instructed and only for the stated areas of use. If you pass the
product on to anyone else, please ensure that you also pass on all the documentation with it.
• Intended use
Set of car seat covers for the driver‘s seat, passenger‘s seat and the back seats of cars
(according to the enclosed type list).
• Safety instructions
Correct installation res. fastening of the seat covers to the vehicle is essential to guarantee the sa-
fety of the user. Please pay attention to the following information when installing the seat covers:
•
WARNING!
DANGER OF SUFFOCATION! Keep the packaging
out of reach of small children.
• Installation is permissible only in cars that are indicated in the list of types on the pa-
ckaging or in the enclosed, detailed list of types.
• Correct assignment of the seat (driver and front passenger seat). The covers are assig-
ned by the marking „airbag“ attached to the seat cover. This marking must be attached
to the outer side of the backrest (see fig. 1.0).
• Headrest inserts, adjustment levers / wheels for release of backrests or armrests may
not be covered with the seat cover. Allowances must be made for appropriate inserts.
Please observe the instructions given in section “Installation”.
• Displaced seat covers must be repositioned. If this is no longer possible due to a advan-
ced state of wear and tear, the cover must be removed or replaced.
• Manipulation of the opening of the seat covers is not permissible (no covering, sewing
up or repairs by yourself).
This protective cover has been tested by TÜV Rhineland Group.
CAUTION! If the seat covers are installed incorrectly, the proper extension and infla-
tion of the seat air bag cannot be guaranteed in the case of a collision.
• Installation of seat covers
You need a pair of pointed scissors.
Important: Please read the information below before installing the seat covers!
Fig. 1: Remove headrests (in some car models the headrests must be dismantled in
a garage).
Fig. 2: Cover the backrest by pulling the cover downwards.
Fig. 3: Pay attention to the correct assignment of the side airbag label (right / left
seat)! The side airbag label must be located at the outside (door side) of the
respective seat.
Fig. 4: Pull the strap through between the seat and the backrest.
Fig. 5: Then close the fastener.
Fig. 6: Cover the seat from the front to the back.
Fig. 7: Fasten the metal hooks to the rubber loops.
Fig. 8+9: Pull the rear rubber loops between the seat and backrest (as you did with the
strap of the backrest cover). Fasten the metal hooks under the seat according
to the car model (e.g. to the existing metal rods - ATTENTION Do not fasten
to airbag cables!)
Fig. 10: Or fasten all rubber loops together.
ATTENTION!
Openings for backrest releases, adjustment levers, side levers etc. (as described under fig.
11–21) must be cut out.
If your seat is equipped with armrests, proceed as described under fig.
11. Otherwise go to fig. 15.
Fig. 11: Pull the cover down as far as the armrest. The cover must be tightly fitting on top.
Fig 12: Cut the cover in the position of the armrest. The cut-out may not be too large.
Fig. 13: Push up the armrest and pull it through the cut-out opening of the cover.
Fig. 14: Pull the strap through between the seat and the backrest and close with the fastener.
If your seat is equipped with side levers, proceed as described under fig.
15. Otherwise go to fig. 19.
Fig. 15: Cover the seat as described under section 2. The cover must be tightly
fitting on top.
Fig. 16: Cut the cover in the position of the side lever. The cut-out may
not be too large.
Fig. 17+18: With the aid of scissors, push the cover under the guide fitting.
If your seat is equipped with seat frame cladding, proceed as described
under fig. 19. Otherwise go to fig. 22.
Fig. 19: (for Renault) Open the seat frame cladding under the seat.
Fig. 20: (for Mercedes) Open the seat frame cladding under the seat.
Fig. 21: Fold the seat frame cladding under the seat cover. Pull the strap through
between the seat and the backrest. Then close the fastener at the back.
Fig. 22: Cover the headrests.
Fig. 23+24: Position the mounting strip directly above the holes for insertion of the headrest.
Cut open the mounting strip in the exact positions of the headrest holes. With
the aid of the integrated mounting strip, it is not possible for the material to tear.
Fig. 25+26: Push the cover beneath the plastic of the headrest guide covering. In a
few isolated car models, it could be the case that these models have no
headrest guide covering.
Fig. 27+28: Pull the cover for the back seat towards the back of the seat. If necessary,
tilt the back seat forward and fasten the rubber loops at the back to the
metal hooks (according to the car model).
Fig. 29: Position the cover exactly in the location of the seat belt.
Fig. 30: Carefully cut the cover in the position of the seat belt.
Fig. 31: Push the cover under the seat belt holder.
Fig. 32: Pull the cover under the backrest. The cover must be under the seat belt!
Fig. 33: Cut the cover in the position of the belt guide.
Fig. 34+35: Push the cover beneath the plastic of the belt guide.
Fig. 36: The backrest cover is universally suitable for all back seats due to the triple zip faste-
ner division. The zip-in part can be used according to the width of the rear backrest.
Fig. 37: Fasten the rubber loops at the back to the metal hooks.
If your your back seat is equipped with armrests, proceed as described
under fig. 38. Otherwise go to fig. 40.
Fig. 38: Open the zip fasteners. Fold out the armrest. Close the zip fastener up to
the armrest.
Fig. 39: Complete covered armrest.
Fig. 40: In case of divided back seats, open the variable zip fasteners with the
slider facing upwards if necessary.
Fig. 41: Remove the rear headrests.
Fig. 42: Cover the rear headrests.
Fig. 43: Cut the backrest cover in the position of the headrest in an x-shaped form.
Fig. 44+45: Push the cover under the plastic.
• Instructions for care and disposal
Wash the covers by hand Do not iron
Do not use bleach Do not dry clean
Do not dry in a tumbler
The seat covers can be disposed of in the household waste.
Please dispose of the packaging in accordance with the local regulations.
• Service & guarantee
You will receive a 3-year guarantee on this product from the date of purchase. The product
has been carefully produced and conscientiously tested before delivery.
Please retain the till receipt as proof of purchase.
Please use the service hotline set up for you or contact the service point.
Service address: Return address:
Walser Industrie- und Handels GmbH Walser Customer Service Germany
Langenweg 34 Walser GmbH
DE-88131 Lindau, Germany Bleicheweg 15, Postfach 3325
DE-88131 Lindau, Germany
Telephone number of Service-Hotline: 00800 00300030
www.walsergroup.com / clix
IAN 274742
Fig. 1.0
Produktspecifikationer
| Varumärke: | Ultimate Speed |
| Kategori: | Inte kategoriserad |
| Modell: | IAN 274742 |
Behöver du hjälp?
Om du behöver hjälp med Ultimate Speed IAN 274742 ställ en fråga nedan och andra användare kommer att svara dig
Inte kategoriserad Ultimate Speed Manualer
7 Oktober 2024
23 September 2024
22 September 2024
17 September 2024
16 September 2024
14 September 2024
14 September 2024
9 September 2024
8 September 2024
7 September 2024
Inte kategoriserad Manualer
- Magivaac
- Nec
- Enhance
- AudioThing
- TeachLogic
- Geomag
- Fulgor Milano
- ShelterLogic
- NComputing
- Sanus Systems
- ChamSys
- Karran
- Plugwise
- Perlick
- Hoymiles
Nyaste Inte kategoriserad Manualer
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
