AXLE STANDS

Assembly, operating and safety instructions

OPKLODSNINGSBUKKE

Monterings-, betjenings- og sikkerhedshenvisninger

CHANDELLES

Instructions de montage, d‘utilisation et consignes

de sécurité

ASSTEUNEN-SET

Montage-, bedienings- en veiligheidsinstructies

UNTERSTELLBOCK-SET

Montage-, Bedienungs- und Sicherheitshinweise

IAN 374000_2104

AXLE STANDS

GB/IE/NI Assembly, operating and safety instructions Page 3

DK Monterings-, betjenings- og sikkerhedshenvisninger Side 7

FR/BE Instructions de montage, d‘utilisation et consignes de sécurité Page 11

NL/BE Montage-, bedienings- en veiligheidsinstructies Pagina 15

DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 19

3GB/IE/NI

AXLE STANDS

 Introduction

We congratulate you on the purchase of your new

product. You have chosen a high quality product.

Familiarise yourself with the product before using it

for the ﬁrst time. In addition, please carefully refer

to the operating instructions and the safety advice

below. Only use the product as instructed and only

for the indicated ﬁeld of application. Keep these

instructions in a safe place. If you pass the product

on to anyone else, please ensure that you also pass

on all the documentation with it.

 Instructions

Please read the instructions carefully and follow

the safety advice. To avoid personal and property

damage, use the product carefully and only for

the intended use. Damage caused by incorrect

handling or non-observance of the instructions is

not covered by the warranty.

IMPORTANT! RETAIN INSTRUCTIONS FOR

FUTURE REFERENCE.

 Intended use

Only for private use – jacking up a car for tyre

changes.

 Technical speciﬁcations

Model number: HG03066

Max. load: 2000 kg (per axle stand)

Hub height I: 24 cm

Hub height II: 26.7 cm

Hub height III: 29.5 cm

Hub height IV: 32.2 cm

Hub height V: 35 cm

Hub height VI: 37.7 cm

Safety instructions

 Always check that the axle stands are in

perfect working order. Never use damaged

axle stands.

 Use the axle stands only on a level,

stable surface.

 When jacking up a car, always use

both axle stands. Never use single

axle stand when changing tyres.

 Before ﬁrst use: Familiarise yourself with the

axle stands and the folding mechanism.

WARNING! Risk of injury! Ensure that

the holding bolt and the safety pin are seated

correctly. Otherwise, the middle pole might fall

freely through the middle tube.

WARNING! Always let the vehicle oﬀ

the axle stands slowly and carefully.

 Before beginning work on the vehicle, ensure

that the axle stands and vehicle are stable.

 Always use 2 axle stands for a vehicle, never

more than 2.

 Never use the jack on a vehicle that is already

on the axle stands.

 Never use the axles stands for 3-wheeled

vehicles or for trailers.
