INTRODUCTION
I. Description
This device is a high power, audio amplifier. Use it responsibly. Very
loud music can cause permanent hearing loss. This amplifier is intended
for installation in vehicles with a 12-Volt, negative ground electrical
system. Attempting to connect or operate the amplifier in another type of
electrical system may cause damage to the amplifier or the electrical
system.
II. About This Manual
Read the Instructions-
Be sure that you have read all operating instructions and understand all
safety precautions before installing and operating the amplifier. We
recommend that you have your T
3 series amplifier installed by a
specialist.
Follow the Instructions-
The instructions are intended to help you safely obtain the best
performance from the amplifier. Carefully follow all installation and
operating instructions.
Save the Operating Manual-
Keep the manual in a safe place after installing the amplifier. You may
have questions later.
Text Conventions used in this Manual-
Bold-
Headings and important information.
Bold, Underlined-
Very important information.
"Bold"-
As labeled on the amplifier, or quoted from elsewhere in this
manual.
III. Safety and Operating Precautions-
Caution!
This symbol warns the user of a potential risk or hazard if instructions are
not followed.
⇒ This arrow symbol points to a specific instruction for avoiding a
potential hazard.
ii
1
1. Installation
1.1 Installation- Mounting the Amplifier
Step 1- Disconnect the negative (-) battery cable before mounting the
amplifier or making any connections. Check the battery and alternator
ground (-) connections. Make sure they are properly connected and free of
corrosion
Step 2- Choose a mounting location for your amplifier. Find a location on a
flat surface away from heat and moisture. Be sure the mounting location and
the drilling of pilot holes for mounting will not present a hazard to any
wires, control cables, fuel lines, fuel tanks, hydraulic lines, or other vehicle
systems or components. Common mounting locations are under the front
passenger seat, or in the trunk area. Choose a location with unimpaired air
circulation. The amplifier will dissipate heat more efficiently if mounted
vertically.
Step 3- Use the supplied screws. Place the amplifier in the mounting
location, and mark the positions of the holes with a marker, pen or pencil.
Carefully drill the mounting holes in the marked positions.
Caution!
⇒ Check carefully before drilling any pilot holes.
Step 4- Use the supplied mounting screws to securely fasten the amplifier to
the mounting surface.
1.2 Installation- Power Connections
Step 1- Run a power cable from the battery to the amplifier mounting
location. Use rubber grommets to protect the cable anywhere it has to go
through metal.
T3 3 4600,T3 4320,T 2700,T3 3 3 3 2600,T 2300,T 5600,T 1000
Use #8 AWG
or larger power and ground cable.
T3 2160 - Use #10 AWG or larger power and ground cable.
Step 2- Connect one end of an in-line fuse holder to the power cable.
Connect the other end of the fuse holder to the positive battery post with 20
cm (or less) of the same cable. This fuse location will protect the system and
the vehicle against the possibility of a short circuit in the power cable. Be
sure to use a fuse and fuse holder adequate for the application. Do not place
a fuse in the holder at this time.
The maximum fuse rating for each amplifier in the T
3 series is:
T3 3 3 4600 -2 X 30 A. T 4320 - 30 A T 2700 -2 X 30 A.
T3 3 3 2600 -2 X 25 A. T 2300 - 30 A. T 2160 -15 A.
T3 3 5600 -3 X 25 A. T 1000 -2 X 20 A.
Caution!
⇒ Bridging fuses or replacing a fuse with one of a higher rating may
cause damage to the amplifier and the vehicle's electrical system.
POWER
Step 3- Run a remote turn on cable from the switched +12V source you
will be using to turn on the system components. This may be a toggle switch,
a relay, or your source unit’s remote trigger wire, or power antenna trigger
wire. Run this lead to the amplifier mounting location. Use #18 AWG wire
or larger.
+12 V RM T GND Step 4- Locate a secure grounding connection as
close to the amplifier as possible. Make sure the
location is clean and provides a direct electrical
connection to the frame of the vehicle. Connect
one end of a short piece of the same size cable as
the power cable to the grounding point. Run the other end of the cable to the
amplifier mounting location.
Step 5- connect the ground cable to the screw terminal labeled
“POWER, GND”.
Step 6- Connect the power cable to the amplifier at the screw terminal
labeled “POWER, +12V”.
Step 7- Connect the remote turn on cable to the screw terminal labeled
“POWER, RMT”.
1.3 Installation- Speaker Connections
Step 1- Run #16 AWG or larger connecting wire from your speakers to the
amplifier mounting location. Keep speaker wires away from power cables
and amplifier input cables. Use grommets anywhere the wires have to pass
through holes in the metal frame or sheet metal. Connect to the speakers
according to the type of terminals on each speaker.
Step 2- Strip 3/8" of insulation from the end of each wire and twist the wire
strands together tightly. Make sure there are no stray strands that might
touch other wires or terminals and cause a short circuit.
Step 3- Crimp spade lugs over the wire ends or tin the ends with solder to
provide a secure termination.
Step 4- Connect the wire ends to your amplifier as follows:
2
SPEAKER TERMINALS
3
Follow the (A/B/C/D+) (A/B/C/D-), channel and polarity markings, making
sure they match the channel and polarity of the connections at the
speakers.
MULTIPLE SPEAKER CONNECTION
PARALLEL- Each additional speaker decreases the load impedance
for the amplifier. The amplifier delivers more current and works
harder.
Caution : impedances lower than 2 ohms may cause damage to your
amplifier and is not recommended.
SERIES- Each additional speaker increases the load impedance for the
amplifier. Impedances higher than 8 ohms are rarely used for car
audio.
(+)
(-)
+
-
(+)
(-)
4 Ohm 2 Ohm
PARALLEL CONNECTION USING 4 OHM SPEAKERS
A
M
P
L
I
F
I
E
R
O
U
T
P
U
T
(A+) (A-) (B+) (B-)
( + ) ( - )
BRIDGE
SPEAKER SPEAKER
(C+) (C-) (D+) (D-)
( + ) ( -
)
BRIDGE
SERIES CONNEC
4 Ohm 8 Ohm
4
(A+) (A-) (B+) (B-)
( + ) ( - )
BRIDGE
SPEAKER
1.4 Installation- Self-Bridging, 2+1 Mode
BRIDGED MONO-
Connect a 4Ω ohm speaker to the
terminals marked “(+), BRIDGE, (-)”,
making sure they match the polarity of
the connections at the speakers.
Caution!
⇒ Speaker or multiple speaker loads
totaling less than 4 ohms are not
recommended for “Bridged” or
“2+1 Mode”, and may damage the
amplifier.
T3 3 4600, T 4320-
Set the “MODE” switch to “2CH, 3CH”, or “4CH” and connect the
speakers accordingly. For “3CH” operation, bridge the “C” and “D”
channels.
2+1 MODE- (TRI-MODE)
Simultaneous stereo and mono operation, “2+1 Mode”, requires a passive
crossover to send low frequencies to the mono speaker and higher
frequencies to the stereo speakers. The following table lists the component
values for a 6 dB/Octave crossover at common frequencies using 4 ohm
speakers for stereo and an 8Ω speaker for mono(subwoofer):
FREQUENCY INDUCTOR CAPACITOR
80 Hz 16 mH 470 uF
100 Hz 7.5 mH 330 uF
120 Hz 7.5mH 330 uF
150 Hz 7.5 mH 220 uF
2+1 MODE WIRING DIAGRAM-
Use 100 Volt, non-polar capacitors, and connect them in series with the
stereo speakers as shown in the diagram. Connect the inductor in series with
(+)
(-)
+
-
(+)
(-)
TION USING 4 OHM SPEAKERS
A
M
P
L
I
F
I
E
R
O
U
T
P
U
T
the mono speaker as shown in the diagram. Be sure the inductor is rated to
handle the power of your amplifier.
(+)
(-)
5
HI GH LEVEL
1.5 Installation- Input
Connections
Low Level, High Impedance, Gold Plated
RCA Input Jacks-
For connecting to a source providing preamp level
outputs. Use heavy duty RCA patch cords designed for
mobile applications . Run the patch cables carefully,
maintaining as much distance as possible from power,
speaker, and accessory wiring. Make sure the RCA
plugs fit tightly for a secure connection.
Speaker Level Input Connector-
Use the supplied wiring harness to connect the speaker outputs from the
source unit(AM/FM/CD/DVD or Cassette) to the “HIGH LEVEL” input.
Wiring Harness Color Code- 2 Channel
White Wire A Channel Positive( + )
White/Black Wire A Channel Negative( - )
Gray Wire B Channel Positive( + )
Gray/Black Wire B Channel Negative( - )
Black Wire Ground
No Other Connection
(+)
(-)
(+)
(-)
(A+)
(A-)
(B+)
(B-)
CAPACITORSINDUCT OR
I N P U T
A
B
HI GH LEVEL
Wiring Harness Color Code- 4 Channel
White Wire Channel A Positive( + )
White/Black Wire Channel A Negative( - )
Gray Wire Channel B Positive( + )
Gray/Black Wire Channel B Negative( - )
Green Wire Channel C Positive( + )
Green/Black Wire Channel C Negative( - )
Violet Wire Channel D Positive( + )
Violet/Black Wire Channel D Negative( - )
Black Wire Ground
No Other Connection
1.6 Installation- Check all Connections
Recheck all connections before reconnecting the negative(-) battery cable.
Insert the correct value fuse in the fuse holder at the battery before
attempting to turn on the system.
2. Operation
2.1 Operation- Input Level adjustments
Adjust the input level for the marked channel(s) with a small
screwdriver through the opening marked “LEVEL”. Turn
CW CCW(clockwise) to increase the level, (counterclockwise)
to decrease. Amplifiers will run cooler and produce less system
noise at lower level settings.
L E V E L
M I N M A X
Consult an experienced installation specialist for assistance in balancing the
levels in multi-amplifier systems, or systems with signal processing
accessories.
2.2 Operation- Built-in Crossovers
CROSSOVER FILTER SELECTION
The T3
series amplifiers have built-in low-pass and high-
pass crossover filters for bi-amplifying your system.
Select " LPF, FULL or HPF" by moving the position of
the slide switch for each pair of channels. "LPF" selects
the low pass filter. "HPF" selects the high pass filter.
Selecting "FULL" defeats the crossover functions
X
- OV ER
LPF- FULL- HPF
FREQUENCY ADJUSTMENT
6
LP F
4 0 - 2 4 0
2.4 Operation- Location of Terminals,
Controls and LED indicators
T3 3 4600, T 4320
1. Power L.E.D. 2. Line level output 3. Line input jacks
4. Input level adjust 5. High pass freq. 6. Low pass Freq. adjust
7. Speaker level input 8. Protection L.E.D 9. Crossover select
10. Bass boost 11. Mode Switch
8
1. Fuse 2. Power terminals 3. Speaker terminals
1 2 3 4 5 6 7 6 5 4 3 8
9 10 11 10 9
2 3 3 1
T3 2700 T3 2600 T3 2300, T3 2160
1. Power L.E.D. 2. Speaker level input 3. Line level input
4. input level adjust 5. Bass boost 6. Low pass freq. adjust
7. Crossover select 8. High pass freq. adjust 9. Line level output
10. Protection L.E.D.
1 2 3 4 7 8 9 5 6 10
1. Fuse 2.Power terminals 3 . Speaker terminals
9
1 2 3
10
Produktspecifikationer
| Varumärke: | Ultimate |
| Kategori: | bilradio |
| Modell: | t3 4320 |
Behöver du hjälp?
Om du behöver hjälp med Ultimate t3 4320 ställ en fråga nedan och andra användare kommer att svara dig
bilradio Ultimate Manualer
8 Januari 2025
27 Oktober 2024
11 September 2024
10 September 2024
10 September 2024
10 September 2024
7 September 2024
7 September 2024
4 September 2024
2 September 2024
bilradio Manualer
- Denver
- Voxx
- Multilaser
- Harman Kardon
- Kunft
- Mystery
- Orava
- Daewoo
- Overmax
- Elta
- Biltema
- US Blaster
- Skoda
- Auna
- Clas Ohlson
Nyaste bilradio Manualer
14 Juni 2025
14 Juni 2025
14 Juni 2025
14 Juni 2025
14 Juni 2025
14 Juni 2025
13 Juni 2025
13 Juni 2025
13 Juni 2025
13 Juni 2025
