Sida 1/24
1
BW515PTR
For more exciting new products please visit our website:
Australia: w.uniden.com.auww
Additional/Standalone Camera
Baby Monitoring System
2
IMPORTANT SAFETY INSTRUCTIONS
This manual contains important information about this product’s operation. If you
are installing this product for others, you must leave this manual or a copy with the
end user.
When using your equipment, always follow basic safety precautions to reduce the
risk of fire, electric shock and injury to persons, including the following:
• This equipment is NOT waterproof. DO NOT expose it to rain or moisture.
• DO NOT immerse any part of the product in water. Do not use this product near
water, e.g., near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
• To avoid any risk of electric shock from lightning, avoid handling any electronic
devices (except battery powered ones) during an electrical storm.
• Use only the power cord and/or batteries indicated in this manual.
• Never tug or pull on any power cord: be sure to leave some slack in the cord
when placing your equipment, and always use the plug to unplug cord from the
wall outlet.
• Never leave power cords where they can become crushed, cut, or frayed; when
running power cords, avoid letting them rub against any sharp edges or lie
across any high traffic areas where people might trip over them.
• Do not use the device if the adaptor cords or plugs have been damaged, the unit
has been exposed to liquids, or the unit has been dropped or is damaged.
When dust and grime builds up on the camera lens and glass, it affects the
camera’s “vision.” Use a microfiber cloth to regularly clean the cameras or when
night vision video is cloudy or unclear.
MAINTAINING YOUR SYSTEM
3
Failure to follow these warnings and the assembly instructions could result in
serious injury or death. This product is not designed or intended for use as a
medical monitor, nor should this product be used as a substitution for medical or
parental supervision. Always be sure that both the transmitter and receiver are
working properly, and are within range of each other.
STRANGULATION HAZARD. Keep the adaptor cords out of the reach of children.
WARNING: KEEP OUT OF THE REACH OF CHILDREN.
Allow for proper ventilation when units are in use. Do not cover the camera or
receiver with any object such as a blanket. Do not place it in a drawer or in any
location which would muffle the sound or interfere with the normal flow of air.
Warning to Parents and Other Users
To avoid damage to your equipment, follow these simple precautions:
• Do not drop, puncture or disassemble any part of the equipment. There are no
user-serviceable parts inside.
• Do not expose the equipment to high temperatures, and avoid leaving the
equipment in direct sunlight for more than a few minutes. Heat can damage the
case or electrical parts.
• Do not place heavy items on top of the equipment or expose the equipment to
heavy pressure.
• Remove the power adaptor during long periods between usages.
• Clean only with a dry cloth.
Failure to follow the instructions in this operating manual will void the
warranty. Uniden assumes no liability for damages to property or injury to
persons caused by improper handling or failure to comply with these safety
instructions.
SAVE THESE INSTRUCTIONS!
For best results
4
CONTENTS
WHAT’S IN THE BOX? ....................................................................................... 5
GETTING STARTED .............................................................................................6
INSTALLATION ..................................................................................................10
CAMERA INSTALLATION ...........................................................................................................................11
PAIRING TO THE MONITOR ................................................................................13
USING THE BABY MONITOR ...............................................................................13
PAN AND TILT .............................. ................................................................................................................. 13
SYSTEM MENUS ...............................................................................................16
SPECIAL FEATURES ........................................................................................ 20
REMOTE VIEWING VIA APP ................................................................................................................. 20
LIVE VIEW..................................................................................................................................................... 25
HISTORY ...................................................................................................................................................... 26
TROUBLESHOOTING ....................................................................................... 27
SPECIFICATION . ........................................................................................... 28
TWO-YEAR LIMITED WARRANTY .................................................................... 30
5
• If any item is missing or damaged, contact your place of purchase immediately.
Never use damaged products!
• Need help? Get answers at our website:
www.uniden.com.au for Australian model
WHAT’S IN THE BOX?
All trademarks are registered trademarks of their respective owners.
BW515PTR
Camera*
AC Adaptor USB Cable
Reset Pin
6
GETTING STARTED
Camera
7
4
6
8
9
5
1
2
3
8
INSTALLATION
CAMERA INSTALLATION
Placement Considerations
The camera can be placed on a shelf or other at surface.
• The camera included is NOT weatherproof; it is an indoor camera.
• Avoid having a direct light source in view of the camera (ceiling or floor lamps).
• Carefully plan where and how the camera will be positioned, and where you will
route the cable that connects the camera to the power adaptor.
• If you are planning to pair it to a monitor, the clearest line-of-sight between the
camera and monitor is best. Walls, especially brick and concrete, can affect
reception quality.
• When pairing to a monitor, to positioning the camera, bring the monitor along; it’s
much easier to get the camera into the right position when you have the display
handy. Check the image on the monitor before you install the camera.
#You can install a maximum of 2 cameras to a BW51xx series monitor. When
pairing the additional camera, you will need to pair the cameras with the
monitor.
Powering the Camera
Insert one end of the micro USB cable to the micro USB port on the cam-
era (at the back of the camera).
Connect the other end of the USB cable into the USB power adaptor.
Connect the USB power adaptor into a 240 volt AC (standard indoor)
power outlet.
Switch on the plug and allow the camera to power up.
9
10
Pairing the camera to the monitor:
1. Press the button on the monitor, and select Menu > Camera Management
> Camera icon that is greyed out .
2. Press and hold the pairing button on the camera until you hear the prompt tone.
3. Press button on the display screen to start pairing.OK
Unpair the camera from the monitor:
1. Press the button on the monitor, and select .Menu > Camera Management
2. Press and hold button on the monitor to unpair the camera.OK
The viewing range is limited to no more than 150m in line of sight. Other factors
such as house walls, layout and electronic devices will affect the transmission
range.
PAIRING TO THE MONITOR
11
Viewing the Camera on Monitor
After the camera is connected to the monitor, you may pan and tilt the camera
(BW515PTR) to adjust the camera viewing angle for an ideal view.
On the live view page, press the button on the monitor to rotate the camera
horizontally and vertically.
USING THE BABY MONITOR
12
BABY WATCH PLUS APP
REMOTE VIEWING VIA APP
You can download Uniden Baby Watch Plus app to remotely view the camera.
To set up the baby monitor camera, please make sure it’s successfully installed and
powered on, and that the status indicator on the camera is flashing red slowly.
The flashing RED (slow) status means that your camera is ready to be paired to the
Baby Watch Plus App.
Prerequisites
• You must have an available Wi-Fi-enabled Smartphone (Android or iOS
smartphone).
• The BW515PTR camera and your smartphone must be within the same Wi-Fi
network range for initial setup (ideally within 3m from the router).
• Wi-Fi router connection is 2.4GHz and password if any.
1. Search and download the free Baby Watch Plus app from the App Store for iOS
devices or Play Store for Android devices. You will need to create an account
specifically for the Baby Watch Plus app. If you already have an account with
Baby Watch Plus app, log in account and skip to Step 6.
2. When the status indicator on the camera starts flashing red slowly, the camera
is ready to be paired with the Wi-Fi network. If the status indicator is not red or
flashing quickly, insert a pin to press and hold the reset button for 5 seconds,
wait for the status indicator to flashing red slowly.
* Please note that app screenshots are for reference only. User Interface for iPhone and
Android Phones might differ in terms of icons layout and functionality and may change
without notice.
As the Baby Watch Plus app is constantly under development to enrich user experience, the icons/
screens shown may vary slightly from the actual app.
Press and hold for
5 seconds
13
2. When launch the Baby Watch app for the first time, you will see the login page.
Tap the “Sign Up” button to create a new Baby Watch Plus account.
3. Enter your email address you wish to register with and check the user
agreement privacy policies. Tap “Next” button to continue.
