Sida 1/26

Description.........................................................................................................1

Elimination of Licensing....................................................................................1

Emergency Operation .......................................................................................1

Controls and Functions.....................................................................................2

Installation..........................................................................................................4

Mobile Station Installation.............................................................................4

Mobile Station Antenna .................................................................................4

Marine Installation .........................................................................................4

Connecting the Power Cords ........................................................................5

Ground Information ......................................................................................5

Negative Ground System ...........................................................................5

Positive Ground System.............................................................................5

To Receive .........................................................................................................6

Weather Information .........................................................................................7

To Transmit........................................................................................................8

Multi-Function Meter.........................................................................................8

Preventive Maintenance ....................................................................................9

Maintenance.......................................................................................................9

Troubleshooting...............................................................................................10

Servicing Your Transceiver .............................................................................10

Radio Code Definitions ...................................................................................11

Specifications ...................................................................................................12

Two-Year Extended Warranty.........................................................................13

Contents

Carefully unpack your PC78 Elite and check the contents against this list:

■PC78 Elite CB 2-way mobile radio

■ Microphone

■ Mounting Bracket Kit

■ DC Power Cord

■ Reference Guide

■ Part 95 Subpart D (FCC Rules)

■ Product Registration Card

If any items are missing or damaged, contact your place of purchase immediately.

Please be sure to complete and mail your

Product Registration Card.

Unpacking

UC343FH 10/23/03 2:32 PM Page ii

Your Uniden PC78 Elite represents the highest quality communications device

designed for use in the Citizens Band Radio Service. It will operate on any of the

40 AM frequencies authorized by the Federal Communications Commission (FCC).

Description

The Citizens Band Radio Service is under the jurisdiction of the

Federal Communications Commission (FCC). Any adjustments or

alterations which would alter the performance of the

transceiver’s original FCC certification, or which would change

the frequency determining method, are strictly prohibited.

Replacement or substitution of crystal, transistors, ICs, regulator

diodes, or any other part of a unique nature, with parts other

than those recommend by Uniden, may cause violations of the

technical regulations in Part 95 of the FCC Rules or in violation

of certification requirements in Part 2 of the rules.

The FCC has ruled that CB Radio Service operators are no longer required to

obtain an FCC License to operate their CB equipment. In doing so, the FCC

also decided to permit CB station operation without station identification.

Elimination of individual station licenses does not reduce the operating

privileges or responsibilities of CB users. An operator of a CB radio station is

still required to comply with the Communications Act and with the rules of

Citizens Band Radio Service.

Uniden is a registered trademark of Uniden America Corporation.

Elimination of Licensing

Emergency Operation

Features, Specifications, and availability of Optional

Accessories are subject to change without notice.

All channels, except Channel 9 may be used for normal

communication. Channel 9 is reserved by the FCC for

emergency communication involving the immediate safety of

individuals or protection of property. Channel 9 may also be

used to render assistance to a motorist.

This is an FCC rule and applies to all operators of CB radios.

1. Set the switch to knob to Channel 9.CH9 or turn Channel Selector

2. Press the microphone PTT switch and speak clearly.

3. If there is no response, select an active channel and ask that party to

relay your emergency broadcast on Channel 9.

UC343FH 10/23/03 2:32 PM Page 1
