Complete Manual for the

AV Bridge Nano

Audio Video Encoder

Document 411-0066-30 Rev B

August 2023

Contents

Overview 1

About this guide 1

Features 1

A quick look at the AV Bridge Nano 2

Front panel 2

Back panel 2

Installation 3

Don’t void your warranty! 3

Cabling notes 3

Basic connections 4

Powering up 4

Initial device set-up and system administration tasks 5

Initial device set-up using the Vaddio Device Controller 5

Initial device set-up using the Vaddio Deployment Tool 6

Manual access and initial device set-up 7

Getting the device's IP address 7

Dismissing the data display 7

If the device is at 169.254.1.1 7

Initial access to the web interface 7

Setting access to the web interface 8

System administration 9

Configuring access and other security settings 9

Configuring a static IP address for a device currently at 169.254.1.1 10

Changing from an automatically assigned address to a static IP address 11

Changing the device's hostname 11

Specifying time zone and NTP server 12

Adding room information 12

Performance and behavior settings 13

Configuring streaming behavior 13

Viewing streams 13

Configuring USB streaming 14

Enabling or disabling IP streaming 14

RTSPstreaming protocol and URL 15

Setting up IPstreaming in Easy mode 15

Setting up IPstreaming in Custom mode 16

Configuring RTMP streaming 17

Stopping the IP stream 18

Changing MTU 18

Configuring audio settings 19

Adjusting audio inputs and outputs 19

Routing audio 20

Setting gain between input and output (crosspoint gain) 20

Saving the audio configuration 21

Customizing labels 21

Locking the front panel 21

System maintenance 22

Exporting and importing configuration data 22

Updating the firmware 23

Operating the AV Bridge Nano 24

Muting and audio controls 24

About viewing streams 25

Command Line Interface SHell (CLISH) reference 26

Requirements 26

Usage notes 26

Getting more information 26

Typographical conventions 26

Audio and video management commands 27

Channels available for audio commands 27

audio volume 28

audio mute 29

audio route 29

audio crosspoint-gain 30

video mute 30

Communication and networking commands 31

streaming ip enable 31

streaming settings get 32

network settings get 33

Maintenance and troubleshooting commands 34

network ping 34

version 34

system reboot 35

system factory-reset 35

Information and session management commands 36

help 36

history 37

exit 37

Troubleshooting and care 38

Rebooting 39

Restoring factory defaults 39

Contacting Vaddio Technical Support and viewing diagnostic logs 41

Operation, storage, and care 42

iii

Complete Manual for the AV Bridge Nano Audio Video Encoder

Produktspecifikationer

Varumärke:	Vaddio
Kategori:	Inte kategoriserad
Modell:	AV Bridge Nano
Bredd:	148 mm
Djup:	113 mm
Höjd:	32 mm
Videoformat som stöds:	H.264
Videolägen som stöds:	1080p
Maximal upplösning:	1920 x 1080 pixlar
Snabbstartsguide:	Ja
Antal HDMI-portar:	2
Ljudutgång:	1
Grafikupplösningar som stöds:	640 x 480 (VGA),800 x 600 (SVGA),1024 x 768 (XGA),1280 x 768 (WXGA),1280 x 800 (WXGA),1366 x 768,1600 x 900
Produktens färg:	Svart
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	20 - 80 %
Kabel inkluderad:	DC, Power, USB
Bildfrekvens:	60 fps
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	DC
Ingående ström:	1 A
Ljudanslutning:	1
Likströmsdriftspänning:	12 V
Antal USB 3.2 Gen 1 (3.1 Gen 1)typ C-portar:	1
