1 947500

Issue 3

VIP-422A-V4, VIP--- 422AECV4

LAY-IN TALKBACK IP CEILING SPEAKER

INTRODUCTION

The VIP-422A- and VIP-422A-- Lay- V4ECV4In

Talkback IP Ceiling Speakers enable voice access

to a single zone of paging over an IP-based

network. This allows page zone extension a

anywhere on the network.The speaker output level

is electrically adjusted during setup. The lay-in

ceiling speaker grille is made of steel with a white

baked enamel nish. The VIP-422A- replaces a V4

2’ x 2’ ceiling tile. The VIP-422A-- replaces ECV4

600mm x 600mm ceiling tile. Power is provided to

the unit via a Power over an Ethernet (PoE) switch

meeting the 802.3af specication.

SPECIFICATIONS

Access Methods

•SIP-enabled telephone system

•PBX, FXO Port w/Valcom Station Port adapter

•POTS phone set w/Valcom Station Port adapter

•PBX, FXS Port w/Valcom Trunk Port adapter

•Valcom M Cast Page Group

Features

•Full duplex communication

•Ambient noise adjustment

•-45 network connection RJ

•Power over Ethernet (PoE) 802.3af compliant

•High Eiciency Class-D Amplier ff

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

Dimensions/Weight

VIP-422A-: V4

•23.L x 23. W x D 75” 75”3.75”

(60.33 cm x 60.33 cm x 9.53 cm)

•Weight: 5.5 lbs. (2.49kg)

VIP-422A--ECV4:

•59m L m W x D 4mx 594m95mm

() 23.37” L x 23.37” W x 3.75” D

•Weight: 2.49kg (5.5 lbs.)

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when

the equipment is operated in a commercial

environment. This equipment generates uses,

and can radiate radio frequency energy and if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area

may cause harmful interference in which case

the user will be required to correct the

interference at his own expense.
