TENT PITCHING INSTRUCTIONS GENESIS 400/500 (UK) –

FLYSHEET FIRST PITCHING:

• Open out inner and position in required direction.

• Peg out the four main corners of the tent using the pegs supplied

• Locate inflating points at the base of each beam

• Access the beams through the zipped entry points and through the side door

• For the first use of the AirBeam, fully unscrew all the valves from the AirBeams and

screw back in carefully before inflating - this ensures that the valve is not cross-

threaded.

• Remove smaller screw-cap on valve and insert pump nozzle, of the Vango

AirBeam™ pump supplied

• Inflate all tubes to 7psi. The tubes MUST be guided into an arch as they are inflated.

• Final tube pressure MUST NOT exceed 8psi

• DO NOT OVER-INFLATE THE BEAMS

• Start with the centre tube and guide the beam into an upright position while it is

inflating

• Inflate the other beams.

• Remove pump & tighten screw-cap. Ensure both parts of valve are well fitted so it is air tight but do not over tighten.

• Ensure the tent is in a straight line

• The groundsheet should be flat and wrinkle free

• Peg out the remaining poles and pegging points using pin pegs at the base of poles

• Peg out ALL guy lines using pin-pegs ensuring that guy line fabric attachment points are evenly tensioned.

Reposition and adjust tensioning where necessary

CORRECT PUMP SET-UP:

• Pump Body > Pressure Valve > Pressure Gauge > Hose

• (Ensure the valve/gauge/hose are connected to the inflation port of the pump)

INNER ATTACHMENT:

• Open out inner tent inside flysheet and position doorways to correspond with the living area

• Starting from the rear corners of the tent, attach the elasticated hooks on the groundsheet to

corresponding rings on the flysheet

• Suspend the inner by attaching toggles of inner tent through rings on inside of flysheet

• Do the rear first and work forward

TENSION BAND SYSTEM:

• Remove Tension Band System from pockets and attach into the corresponding clips at the apex of the pole

• Adjust the straps until they are taut

• DO NOT OVERTENSION. Excess tension will alter the shape of the tent

TO DEFLATE THE AIRBEAM TENT:

• Unscrew the valve fully from the beam, taking care as the valve will be under pressure from the air inside the tube.

IN THE UNLIKELY EVENT OF A PUNCTURE:

• Note - most apparent punctures are the result of the valve not being screwed in correctly. Please check the valves before changing the AirBeam in

question

• Deflate the air beam. Unzip the internal flysheet sleeve which contains the affected beam.

• Remove the tube and its protective outer.

• The zips for the protective outer are cable tied together to prevent accidental access. Cut the cable tie and open the zip.

• DO NOT open these zips when the tube inflated. is

• Remove the clear rubberised tube from the protective sleeve taking care when removing the valve from the sleeve.

• Partially inflate the tube and pass through a bucket or basin of water, looking for air bubbles. This will indicate location of puncture

• Use the repair patch provided and cover hole, using instructions on patch. Re-insert tube into protective outer, closing zip from both ends, so that zip

pullers are in the flysheet sleeve (this might be easier with the tube partially inflated)
