PITCHING INSTRUCTIONS KALARI (UK) –

Pitching Instrucons Kalari (UK) –

All - in - one pitching

 Park your vehicle in the best locaon on your pitch ensuring that there is at least 4.6m free space at the side where you would like to pitch your AirAway/Awning.

 Ensure that the area where the awning is being pitched is clear of sharp objects and that all door zips are closed. (We recommend laying the AirAwning fabric on a groundsheet prior to aaching

it to your caravan, as this helps prevent the fabric becoming wet & dirty. It also helps prevent damaging the fabric as the awning is fed into the awning rail.)

 Please ensure your caravan’s rail is clean and clear of debris prior to installing the AirAwning. If required, please use an aermarket product to reduce fricon between the kador strip and the

rail during ng and removal of the AirAwning.

 Unpack the AirAwning and posion it in the required direcon, with the rear aachment secon facing the side of the caravan. Place the pump, pegs and other components to one side.

 Feed the leading edge of the kador into the rear of your caravan’s rail and gently pull the AirAwning into the desired posion, ensuring the roof of the AirAwning is posioned on the horizontal

part of the caravan’s awning rail. (Please only pull your AirAwning by the webbing loop at either end of the kador.)

 Peg out the rear corners of the aachment secon of the AirAway/AirAwning at the base of the vehicle.

 Locate inaon points on each beam

 Remove the valve cap (gure 1)

 Insert the correct pump adaptor, which will lock onto the valve

 There is no need to turn the white valve buon as the adaptor will move this to the correct posion

 Inate all tubes to 7psi. The tubes MUST be guided into an arch as they are inated (gure 4)

 DO NOT OVER-INFLATE THE BEAMS

 Inate all AirBeams to 7psi. The Vango AirBeam® pump is supplied with a pressure release valve which will release pressure if more than 7.5 - 8psi is put into the AirBeam.

 Start with the rear AirBeam and guide into an upright posion whilst it is inang

 A small amount of air may leak from the valve when it is being inated but this is normal

 Remove the pump adaptor as soon as the beam is at the correct psi

 Replace the valve cap to create an air ght seal

 Repeat for front AirBeam

 Peg out the remaining poles and pegging points using pin pegs at the base of poles

 With the doors fully zipped up, peg out the front corners of the AirAwning with the rock pegs supplied, ensuring the sides and front of the awning are taut. The adjustable pegging points allow

the pegs to be posioned in a range of places, to avoid rocks and stones in the ground. They are adjustable to allow the webbing to be tensioned, in order to achieve a taut canvas.

 Once the 4 corners of the AirAwning have been posioned, all the other pegging points (both adjustable webbing and elasc) at the base of each door should be pegged out, using the rock pegs

supplied.

 At the base of each door is a webbing strap with 2 eyelets in it. Insert a groundsheet peg (a peg with a at, round top) in to each of these eyelets to hold the webbing strap close to the ground.

 Inside the AirAwning, inate & install the "Bracer" AirBeams between the main AirBeams. The ends of these are located using hook & loop fabrics. The Bracer AirBeams will increase the tension

in the roof and will provide extra stability during poor weather.

 2 long pads are provided: these are ed vercally between the AirAwning and the caravan, reducing draughts. They are aached using hook & loop xings. To hold the pads against the caravan

in windier condions, 2 adjustable steel poles are supplied. Place the at end of these poles into the webbing sleeves at either end of the awning, just below the outermost AirBeams. Place the

lower, pointed end into one of the two eyelets in the base of the rear of the AirAwning. The length of the pole can then be adjusted to apply tension between the top of the AirAwning and the

base. Finally, aach the AirAwning fabric to the steel pole by wrapping the hook & loop tabs around it.

 Idenfy the PVC wheel arch covers & draught skirt. Slide the draught skirt into place using the awning rail at the base of the caravan. The boom of the draught skirt is held in place with

groundsheet pegs. The wheel arch covers are aached using the suckers provided. For a single axle caravan, only one of these covers will be needed.

 In extreme weather, the AirAwning may slide along the awning rail. To prevent this, aach one of the sucker hooks to the caravan, and aach the webbing loop at the end of the kador strip into

the hook.

 Peg out ALL guy lines using pin-pegs ensuring that guy line fabric aachment points are evenly tensioned.

 When the AirAwning is to be used in windy weather condions, Vango recommends using the supplied storm straps

 The straps should be aached to the corresponding clips on the llets aached to the rear AirBeam of the AirAway, and secured using the pegs supplied.

TO DEFLATE AIRBEAM/ AIRAWAY/ AIRAWNING:

 To deate the AirBeam (remove the cap (gure 7)) press & turn (gure 8) the buon from CLOSED to OPEN

In the unlikely event of a puncture:

 Deate the air beam. Unzip the internal ysheet sleeve which contains the aected beam.

 Remove the tube and its protecve outer.

 The zips for the protecve outer are cable ed together to prevent accidental access. Cut the cable e and open the zip.

 DO NOT open these zips when the tube inated.

 Remove the clear rubberised tube from the protecve sleeve taking care when removing the valve from the sleeve.

 Parally inate the tube and pass through a bucket or basin of water, looking for air bubbles. This will indicate locaon of puncture

 Use the repair patch provided and cover hole, using instrucons on patch. Re-insert tube into protecve outer, closing zip from both ends, so that zip pullers are in the ysheet sleeve (this might

be easier with the tube parally inated)

AIRBEAM INFLATION:

AIRBEAM DEFLATION:
