POWXQ5302 EN

1 APPLICATION 3 ..........................................................................

2 DESCRIPTION .......................................................................... 3

3 PACKAGE CONTENT LIST ...................................................... 3

4 SYMBOLS ................................................................................. 3

5 GENERAL POWER TOOL SAFETY WARNINGS ..................... 4

5.1 Working area ................................................................................................................. 4

5.2 Electrical safety ............................................................................................................ 4

5.3 Personal safety ............................................................................................................. 4

5.4 Power tool use and care ............................................................................................... 5

5.5 Service ........................................................................................................................... 5

6 SPECIAL SAFETY INSTRUCTIONS FOR JIG SAWS .............. 5

7 ADDITIONAL SAFETY INSTRUCTIONS FOR LASERS ........... 6

8 OPERATING INSTRUCTIO NS .................................................. 6

8.1 Starting up ..................................................................................................................... 6

8.1.1 Switching on and o .................................................................................................... 6

8.1.2 Adjusting the cutting speed ......................................................................................... 6

8.2 Changing the saw blade (g 2) 7 ....................................................................................

8.3 Angle cutting adjustment( g3) 7 ...................................................................................

8.4 Edge guide( g 4) .......................................................................................................... 7

8.5 Using the laser (6) ......................................................................................................... 7

8.6 Use of pendulum (10) ................................................................................................... 7

8.7 Replacing battery (g 5) ............................................................................................... 8

8.8 Dust blowing switch (11) .............................................................................................. 8

9 CLEANING AND MAINTENANCE ............................................ 8

9.1 Cleaning ........................................................................................................................ 8

9.2 Service department ....................................................................................................... 8

10 TECHNICAL DATA ................................................................. 8

11 NOISE ..................................................................................... 9

12 WARRANTY ............................................................................ 9

POWXQ5302 EN

13 ENVIRONMENT .................................................................... 10

14 DECLARATION OF CONFORMITY ...................................... 11

POWXQ5302 EN

JIG SAW 900W

POWXQ5302

1 APPLICATION

The power tool is intended for sawing wood, metal and plastics. It is not designed for

commercial use.

WARNING! For your own safety, read this manual and the general safety

instructions carefully before using the appliance. Your power tool should

only be given to other users together with these instructions.

2 DESCRIPTION

Fig 1

1. Power cable

2. Lock button

3. On/O switch

4. Speed regulator

5. Laser switch

6. Laser

7. Transparent guard

8. Guide wheel

9. Saw blade

10. Pendulum switch (4 positions)

11. Dust blowing switch

12. Adjustable base

Fig 4

13. Edge guide screw

14. Edge guide

3 PACKAGE CONTENT LIST

 Remove all packaging materials.

 Remove remaining packaging and packing inserts (if included).

 Check that the package contents are complete.

 Check the appliance, the power cord, the power plug and all accessories for transportation

damage.

 Keep the packaging materials as far as possible until the end of the warranty period. Then

take it to your local waste disposal system.

WARNING Packaging materials are not toys! Children must not play with

plastic bags! There is a danger of suocation!

Jig saw

1 set of batteries (2xAA, pre-installed)

2 hex key (Allen)

Edge guide

Instruction m anual

If any parts are missing or damaged, please contact your dealer.

4 SYMBOLS

The following symbols are used in this manual and/or on the machine:

Denotes risk of personal injury

or damage to the tool.

Read manual before use.

In accordance with essential

safety standards of applicable

European directives.

Class II - The machine is double

insulated; earth wire is therefore

not necessary.

Produktspecifikationer

Varumärke:	Varo
Kategori:	såg
Modell:	POWXQ5302
Mjukt grepp:	Ja
Skärdjup i trä:	80 mm
Kabellängd:	4 m
AC-inspänning:	230-240 V
Växelström Frekvens:	50 hz
Strömkälla:	AC
Ineffekt:	900 W
Obelastad slagtal:	3000 spm
Sågdjup i olegerat stål:	6 mm
