User manual
FLUSH-MOUNTING WI-FI CHRONOTHERMOSTAT
Read all instructions carefully
Vemer S.p.A.
I - 32032 Feltre (BL) • Via Camp Lonc, 16
e-mail: info@vemer.it - web site: www.vemer.it
V3IS01070-011
Mod. Asso Wi-Fi
Flush-mounting Wi-Fi chronothermostat powered by mains (230V ~), suitable for
controlling heating and air conditioning systems. The Wi-Fi module allows you to
control the device remotely with your smartphone. Simply connect the device to your
home router and install the free Vemer Wi-Fi app on your smartphone, available free
of charge for iOS and Android devices. The adapters in the package allow you to
install the device with the plates of the main civil series.
Code Model Description
VE780200 Asso Wi-Fi Flush-mounting Wi-Fi chronothermostat
VE780201 Asso Wi-Fi-INT Flush-mounting Wi-Fi chronothermostat
SAFETY WARNINGS
During installation and operation of the device, it is necessary to comply with the
following instructions:
1) The device must be installed by a qualified person, in strict compliance
with the connection diagrams.
2) Do not power on or connect the device if any part of it is damaged.
3) After installation, inaccessibility to the connection terminals without appropriate
tools must be guaranteed.
4) The device must be installed and activated in compliance with current electric
systems standards.
5) Before accessing the connection terminals, verify that the leads are not live.
6) In the electrical system of the building where the chronothermostat must be
installed, a protection device from the overcurrents must be present.
7) The device performs actions of 1B type and is suitable for environments with
pollution degree 2 and overvoltage category III (EN 60730-1).
TECHNICAL FEATURES
• Power supply: 230V AC (± 10%) 50/60Hz
• Output: bistable relay with 5A / 250V AC breaking capacity
• Operating mode: summer/winter/off (with antifreeze)
• Weekly programming via app with 3 temperature levels T1, T2, T3
• Programming resolution: 1 hour
• Type of regulation: on/off or proportional
• Installation on flush-mounting box with 45mm height (occupied space: 2 modules)
• Terminal block for cables with a maximum section of 1.5mm
2
• 3-digit LED display with brightness settable from the App
• Configuration/programming key T
• Red LED: when lit it indicates that the load is active
• Green LED: configuration status
• Measurement accuracy: ± 0.5°C
• Measured temperature resolution: 0.1°C
• Temperature setting range: 2 ÷ 50°C
• Operating frequency band: 2.4GHz IEEE 802.11 b/g/n
• Maximum transmitted radiofrequency power: 18.3 dBm
• Operating temperature and humidity: 0 ÷ 50°C / 20% ÷ 90% (not cond.)
• Storage temperature: -10 ÷ 65 ° C
• Degree of protection: IP40
• Insulation: reinforced between accessible parts (front) and all other terminals
For information on the possibility of adapting the device with plates
different from those shown, contact the Technical Assistance Service.
Adapters for civil series plates for Asso Wi-Fi
Brand Series Adapter
ABB Mylos AM
AVE S44 A4
BTICINO
Axolute, Axolute AIR BA
Light, Living International,
LivingLight, LivingLight AIR
BL
Matix BM
GEWISS Chorus GC
VIMAR
Arkè, Eikon, Eikon Evo VE
Plana VP
7
EMERGENCY REGULATION
If the connection to the cloud fails (for example due to a problem with the router) it is impossible to control the device, so this regulates the temperature based on the last
programming downloaded from the cloud.
In this situation, if the temperature provided by the program does not meet your needs, you can activate the emergency mode to set a different temperature to maintain until the
connection to the cloud is re-established.
To activate the emergency regulation, proceed as follows:
① press the T key for about 5 seconds until SET appears on the display
② the emergency temperature value flashes: pressing the T key for a long time changes the temperature value, in steps of 0.5 ° C.
With each new press, the change direction is inverted: increase-decrease-increase -...
③ when the desired value flashes on the display, wait 5 seconds without pressing the T key until MEM appears to indicate that the device has memorized the value.
When the emergency regulation is active, the measured temperature value flashes
The device automatically stops the emergency regulation as soon as the connection to the cloud is restored.
8
DEVICE RESET
The reset procedure deletes all the settings made and returns the device to
the factory conditions.
The reset also deletes the configuration of the connection with the home network.
To reset, press the T key for about 15 seconds until the display shows
the word DEF.
Note. After a few seconds from the start of the pressure, the display shows
the word SET: continue to press the key without releasing it.
21.7 SET DEF
15s
MESSAGGES
During normal operation, the device displays the measured temperature.
In the initial configuration phase and in particular situations, the temperature
display is alternated with the following messages:
• CFG: device waiting for the first configuration. This situation occurs during the
initial configuration or after a device reset.
• LAN: device not yet connected to the home router. If this condition persists, check
that the password of the home wi-fi network entered in the app is correct and that
the home router is turned on.
• NET: device connected to the home router but not yet connected to the Vemer
server
• CLD: device not associated with any user (for example because it has been
disconnected or because an error has occurred in the server).
• UDP: device not connected to the NTP server for clock synchronization.
Check that the UDP123 port on the router is not blocked
• ERP: malfunction of the temperature probe
INITIAL CONFIGURATION
To configure the device proceed as follows:
① Install and start the Clima Wi-Fi app on your smartphone.
Create a personal account on the Vemer cloud (if you already have an account,
go to step 2):
ⒶTap on “Register”
ⒷEnter an email address and password and tap on “Register”.
For security reasons, it is advisable to enter a password different
from the one used to access your email
ⒸCheck your email box: click on the link contained in the email received
to confirm the activation of the account.
② Enter the email and password of your personal Vemer account.
Tap on “New thermostat” and choose the Asso Wi-Fi model.
③ Power up the device: the green LED flashes quickly for a few seconds,
then flashes slowly for about 5 minutes (access point mode).
If the green LED does not flash, press the key T.
④ Tap on “next” and then on the name of the network “AWV...”
(the last 3 digits of the AWV network are also shown on the device
display)
Wait for the green LED to stop flashing and become steady on to indicate
that the connection between the device and the app has taken place.
⑤ In the next screen tap on the name of the home wi-fi network to which
to connect the device. Enter the password of the home wi-fi network.
⑥ Enter a name and choose an icon to help identify the Asso Wi-Fi device.
The configuration procedure has ended.
The newly configured device will appear in the list screen of the devices
associated with your account and from this moment it is possible to control
it remotely via the app.
6
3
CONNECTION DIAGRAMS
L N
5A/250V~
DIMENSIONS
2
40 42
40
4
PLACEMENT
We recommend installing the device at a height of 1.5 meters from the floor, in an area that reflects as much as possible the average temperature conditions of the room.
Avoid installation near doors or windows, in niches, behind doors and curtains or in positions with excess or total lack of ventilation.
Also make sure that the distance from the router is such as to ensure stable communication.
5a
ASSO WI-FI MOUNTING (code VE780200)
① Apply the adapter corresponding to the plate of the civil series to be mounted (see table)
② Connect the load and the power supply (see connection diagram)
③ Insert the device into the adapter
5b
ASSO WI-FI -INT MOUNTING (code VE780200)
① Connect the load and power supply (see connection diagram)
② Fasten the device with the metal frame to the flush mounting box
③ Apply the cover plate and the 50x50mm intermediate panel
④ Finally insert the closing frame
The device can be adapted to the cover plates of Berker, Busch-Jaeger, Gira,
Jung and Merten.
The complete list of compatible cover plates is available on the website
www.vemer.it on the product page.
Flush-mounting box
DEVICE
WITH METALLIC FRAME
Cover plate
(not supplied)
Intermediate panel
(not supplied)
CLOSING FRAME
5 Modify a program
Monday SAVE
14.15.0 22.1
my prog1
Monday
Martedì
Mercoledì
Giovedì
Venerdì
00 06 12 18
Copy T1 T2 T3
T1
T2
T3
T1
T2
T3
T1
T2
T3
T1
T2
T3
T2
T3
Copy T1 T2 T3
Copy T1 T2 T3
Copy T1 T2 T3
Copy T1 T2 T3
50° 14.1° 22.1°
50° 14.1° 22.1°
50° 14.1° 22.1°
50° 14.1°
22.1°
50° 14.1° 22.1°
To modify an existing program, tap on the program profile of the day to be modified, then
assign to each hour of the day one of the temperatures T1, T2 and T3 (identified by the
colours blue, green and red). The “copy” function allows you to copy the same program on
several days of the week.
4 Programs List
Program list
HEATING
WINTER DEFAULT
my prog 1
my prog 2
oce
to create a new program
to select, to modify, to delete or to rename an existing
program
Note: WINTER DEFAULT
can not be changed or deleted.
1 Login
Password forgotten
Register
Enter
Clima
Wi-Fi
Password
E-Mail
Access your Vemer account by entering your access
credentials (e-mail, password) chosen during registration.
If you don’t have a Vemer account, choose “Register.
3 Check the device
Home
Asso room_1
HEATING
WINTER DEFAULT
INT
AUTO
25.0 °C
14.1 °C
Measured temperature (25.5°C)
Operating mode (HEATING)
System status:
( ) red = on
( ) grey = off
Set temperature and running program name.
Tap to change the running program.
Operating mode.
Tap to change the operating mode (heating/hair
conditioning) and the mode (automatic/manual/off)
6 Configuration menu
Home
Home
Thermostats list
Programs
Google home
Amazon
Information
Prole
Logout
Vacations
Settings
FAU LT
Home
Asso room_1
HEATING
WINTER DEFAULT
INT
AUTO
25.0 °C
14.1 °C
7 Holidays calendar
Vacation calendar... SAVE
April 2019
May 2019
Mon Tue Wed Thu Fri Sat Sun
Mon Tue Wed Thu Fri Sat Sun
30 31 1 2 3 4 5
6 7 8 9 10 11 12
13 14 15 16 17 18 19
20 21 22 23 24 25 26
27 28 29 23 1 2 3
27 28 29 30 1 2 3
4 5 6 7 8 9 10
11 12 13 14 15 16 17
Set the vacation days in which the regulation results
off (operation off) by selecting them on the calendar.
During the holiday period the
operation field shows VAC
REFERENCE STANDARDS
10-2020
EU declaration of conformity:
Vemer declares that the device complies with the EU directive 2014/53/EU (RED) with
reference to the following standards: EN 60730-2-7, EN 60730-2-9, ETSI EN 300 328,
ETSI EN 301 489-1, ETSI EN 301 489-17
The full text of the EU declaration of conformity is available at the Internet address
www.vemer.it
2 Devices list
Thermostat List
Asso room_1 Asso room_2
Asso bathroom
New Thermostat
Group
ASSO ASSO
ASSO
ASSO
ASSO
ASSO
allows you to record a new device
allows you to group several devices.
For example it’s possible to group all “Asso Wi-Fi”
in a building of 3 floors according to the logic:
“Floor 1”, “Floor 2” and “Floor 3”.
Tap on the icon of the device to be controlled
8 Device setting
TEMPERATURE VALUES
WINTER SUMMER
ICON
NAME
Asso mountain
Asso room_1
ADVANCED SETTINGS
SAVE
Advanced settings:
alarm temperature configuration
email of the recipient of the alarm
type of regulation
Device name
Icon that identifies the device
Temperatures T1, T2 and T3
of automatic operation
9 Advanced settings
Advanced settings... SAVE
ALARM
TEMPERATURE REGULATION
CLOCK
BRIGHTNESS DISPLAY
TEMPERATURE COMPENSATION
E-mail of the recipient for alarm reports
Minimum temperature threshold for alarm
Maximum temperature threshold for alarm
Alarm delay (seconds)
OFF
OFF
a. email address of the recipient of the alarms
b. Alarm condition (which temperature value must be
exceeded and for how long)
c. Choice of the type of regulation (on/off or proportional)
d. Time zone and automatic summer time change setting
e. Display and led brightness setting
f. Compensation of the measured temperature value
of the probe. Allowed values: -5°C ÷ + 5°C
10 Setting the clock
Setting the clock Save
Time zone
Daylight saving time
WINTER TIME
DATE TYPE
Last week
MONTH
October
DAY
Sunday
HOURS AND MINUTES
03:00
SUMMER TIME
DATE TYPE
Last week
Specify the time zone of the installation area.
If not changed, the setting requires + 1h
(time zone valid for Central Europe).
Enable/disable the automatic change of summer-winter time.
If this setting is not changed, the configuration foresees:
• the passage winter time ➔ summer time (+1h) the last
Sunday of March at 2:00 o’clock
• the passage summer time ➔ winter time (-1h) the last
Sunday of October at 3:00 o’ clock
11 Setting the display brightness
Display brightness setting Save
DAYTIME
NIGHT TIME
Level 1
from to
23:00 08:00
Level 4
from to
08:00 23:00
Display brightness
Display brightness
It is possible to define two time bands (day and night) and
assign a different light intensity level to the display and the led
for each of them. 5 brightness levels are available, plus a 0
level which corresponds to a display that is off (the led instead
lights up with minimum intensity, i.e. level 1, because it can
never be completely off).
Note: to “wake up” the display when brightness level 0 is set,
simply press the T key briefly.
10
HOW TO TRANSFER THE DEVICE CONTROL
FROM ONE ACCOUNT (USER) TO ANOTHER
If it is necessary to assign the control of the device to another user (typical situation
for example when the device is installed in a rented home and tenants change),
proceed as follows:
① Disconnect the device from the old user (using one of the following two ways
to do it alternatively):
ⒶActivate the access point mode on the device (press the T key and check
that the green LED flashes). Then press the same key for a long time until
the display shows DEL
Ⓑon the old user’s app, long tap on the icon that identifies the device
in question until the request for confirmation of deletion appears.
② Perform the initial configuration procedure with the new user app.
11
WHAT TO DO IF THE ROUTER IS REPLACED
If you replace the home network router/access point, proceed as follows:
① Activate the access point mode on the device (press the T key and check that
the green LED flashes)
② Access the app and tap on “New thermostat”, then tap on “Asso wi-fi”
and finally Tap on “Next”
③ Tap on the “AWV...” network and on the next screen tap on the new
wi-fi network and enter the password
④ At this point, exit the app without entering the device name.
9
APP DESCRIPTION
Produktspecifikationer
| Varumärke: | Vemer |
| Kategori: | Termostat |
| Modell: | Asso Wi-Fi |
Behöver du hjälp?
Om du behöver hjälp med Vemer Asso Wi-Fi ställ en fråga nedan och andra användare kommer att svara dig
Termostat Vemer Manualer
27 Augusti 2025
27 Augusti 2025
27 Augusti 2025
27 Augusti 2025
27 Augusti 2025
27 Augusti 2025
27 Augusti 2025
27 Augusti 2025
25 Augusti 2025
24 Augusti 2025
Termostat Manualer
- Eurotronic
- Wachendorff
- THERMAFLEX
- Aube
- Wodtke
- Bulex
- ChiliTec
- VDH
- AcuRite
- IR-V
- Saunier Duval
- Tesla
- Danfoss
- Buderus
- TrickleStar
Nyaste Termostat Manualer
21 September 2025
19 September 2025
18 September 2025
12 September 2025
11 September 2025
10 September 2025
10 September 2025
10 September 2025
10 September 2025
9 September 2025
