HEAT REGULATION
HEAT REGULATION
TECHNICAL INFORMATION
HT Pt-JK
H2T Pt-JK
6
5
4
3
2
1
12
11
10
9
8
7
OUT1
OUT2
+
Pt100
3fili
Pt100
2fili
0÷50mV
0÷60mV
12÷60mV
TCJ,K,S
*
CodeModelDescriptionPower supplyRelays no.
VE247300HT Pt-JK 2P4D48x48 heat regulator with one display24V ac/dc2
VE248100HT Pt-JK 2P4A48x48 heat regulator with one display100÷240V ac2
VE249900H2T Pt-JK 2P4D48x48 heat regulator with two displays24V ac/dc2
VE250700H2T Pt-JK 2P4A48x48 heat regulator with two displays100÷240V ac2
48X48 DIGITAL HEAT REGULATORS
•Powersupply:
24V ac/dc (HT Pt-JK 2P4D e H2T Pt-JK 2P4D)
100÷240V ac (HT Pt-JK 2P4A e H2T Pt-JK 2P4A)
•Screwterminalblock
•Possibilityofsettingfunctioningmodeinheatingorcooling
•ON/OFFregulationorPID
•AutomaticPIDparametercalculation
•Twooutputrelayswith8A/250Vchange-overcontactforregulationsoralarms
•Absoluteorrelativealarmfunction,minimumlevelormaximumlevelorwindow
•Connectingprobes:thermocouples(J,K,S),Pt100thermo-resistances,
probeswithoutputsignals0-50mV,0÷60mV,12÷60mV
•Possibilitytochangetheparameterstoprotectbypassword
1 Leddisplayforthedisplayingofthevaluesoftemperature,ofthe
setparametersandthestatusoftheoutputs/alarms
2Keysforthesettingoftheinstrumentparameters
348x48compactdimensions
4Screwterminalblock
•Measurementrangeonthebasisoftheusedprobe:
-Pt100(-200°C÷+850°C)
- K (0°C ÷ +1370°C)
- J (0°C ÷ +1000°C)
-S(0°C÷+1760°C)
-normalizedsignals0÷50mV,0÷60mV,12÷60mV
(rangeonthebasisofthesignal)
Seriesofpanel-mountingdigitalheatregulatorsof48x48dimensionsfortheregulationofthetemperature
bothinheatingandcoolingfunctions.
Digital heat regulators
DIMENSIONS (mm)CONNECTION DIAGRAM
*Powersupply:
•100÷240Vac56/60HzforHTPt-JK2P4AandH2TPt-JK2P4A
•24Vac/dcforHTPt-JK2P4DandH2TPt-JK2P4D
Front viewDiagramSide view
GENERAL CHARACTERISTICS
Power supply
(2P4Dversions)VAC/DC24
(2P4Aversions)V AC100÷240 (-10%÷+10%)
Frequency50/60Hz
Maximumownconsumption~5VA
Termination2x1mm²
screwterminalblock
Regulation typeON/OFForPID
Output:2NOrelays
8A/250Vac
Resolution:
-thermocouples°C1
- Pt1000.1 or 1°C
-normalizedsensors°C0.001 or 0.01 or 0.1 or 1
Precision±0.5%ofthefullscale
(±1%f.s.forsignals
0÷50mV,0÷60mV,
12÷60mV)
Weightg150
Operatingtemperature0÷+50°C
Operatinghumidity30÷95%°C
non condensing
DegreeofprotectionIP54
REFERENCE STANDARDS
ConformitywithCommunityDirectives:2006/95/EC(Lowvoltage)and2004/108/EC(E.M.C.)
isdeclaredwithreferencetothefollowingharmonisedregulations:•EN61010-1,EN61326
1
2
3
4
