4

5

130

85

28

CLIMATE CONTROL

TECHNICAL INFORMATION

WIRING DIAGRAMDIMENSIONS (mm)

Front viewSide viewDiagram

GENERAL CHARACTERISTICS

L

N

NC

NO

C

REFERENCE STANDARDS

Compliance with Community Directives: 2014/35/EU (LVD) • 2014/30/EU (EMCD)

is declared with reference to the following standards: EN 60730-2-7 • EN 60730-2-9

Digital chronothermostatsTUO WI-FI

CodeModelDescriptionColourPower supply

VE772000Tuo Wi-Fi Bianco

Touch screen weekly chronothermostat with multicolour backlit LCD and with WI-FI

White230 V~

VE772100Tuo Wi-Fi Nero

Touch screen weekly chronothermostat with multicolour backlit LCD and with WI-FI

Black230 V~

VE785700Tuo Wi-Fi Lite Bianco

Touch screen weekly chronothermostat with blue backlit LCD and with WI-FI

White230 V~

VE793800Tuo Wi-Fi Lite Nero

Touch screen weekly chronothermostat with blue backlit LCD and with WI-FI

Black230 V~

Touch screen electronic chronothermostats with Wi-Fi connection, weekly programming and wall installation,

designed to control the ambient temperature both in heating mode (winter) and in cooling mode (summer).

The free app, available on the AppStore and Google Play, allows the programming and the complete

control from your smartphone or tablet. Any alarm situations are signaled by sending an email

to the speci ed address. The keypad consists of four touch keys placed on the sides of the display.

The colour of the display backlighting can be customized by the user (in the Lite version, only blue backlit).

1Plastic base for wall-mounting or to cover the 3 modules

 ush-mounting box

2Wide backlit display to view the measured temperature

and humidity and the set programming

(displayed humidity not available in the Lite version)

3Backlit touch keys on the sides of the display

4Terminals on the back of the device for connecting the load

and the power supply

5Integrated Wi-Fi module compatible with 802.11 b/g/n

standard

6Free app available for iOS and Android systems

7Compatible with Google Home and Amazon Echo

What allows you to do the App?

• switch on and switch o the air conditioning system

• create and modify weekly programs

• change the operating temperatures values

• simplify programming through copy-paste of one program

on several days

• set holiday days when the system is o

TUO-Wi-Fi alerts you when...

.. the measured temperature exceeds a minimum or

maximum set value

Appaccess pointTuo Wi-FiInternet network

WEEKLY WALL-MOUNTING WI-FI CHRONOTHERMOSTATS

•Automatic programming on a weekly basis with 3 temperature levels T1, T2, T3

•On/o temperature regulation type (with adjustable di erential) or proportional

•Antifreeze temperature to prevent system freezing when the device is switched o

•Con gurable backlighting display: always o , of a colour chosen among 48 possible shades or variable

between red, green and blue based on the di erence between the measured temperature and the set one

(in the Lite version only blue backlit)

•Display of the measured humidity value (not in the Lite version)available

•Timing function: allows you to extend the current operation for the specifed period (hours or days),

after which the device changes operation from automatic to o , from manual to automatic,

from o to on (manual or automatic)

•Delay function (settable for each hour independently): allows to adjust the temperature for the  rst 15,

30 or 45 minutes of the current time on the basis of the temperature level set for the previous hour

•“Local operation block” function: allows the device control only with the app (keypad changes are ignored)

•Possibility to reduce the settable temperature range (factory 2÷50°C)

•Automatic summer time change and automatic synchronization when connected to the electricity network

•Keypad lock with password to prevent changes by unauthorized persons

•Classi cation according to point 6 of the Communication 2014 /C 207/02 of the European Commission: class IV

Regulation typeON-OFF or proportional

Adjustable di erential (in OFF-ON)0.1 ÷ 1°C

Displayed humidity (not present in Lite version)

Range RH+20÷ +90%

Resolution RH0.1%

Precision RH5%

Protection degreeIPXXD

Operating temperature0 ÷ 50°C

Storage temperature-20 ÷ 65°C

Relative humidity20%÷90% non condensingRH

Power supplyV AC230 (-10% ÷ +10%)

Frequency Hz50/60

MountingWall /Box 503

ProgrammingWeekly

Operating modesummer/winter

Settable temperatures3 + antifreeze + manual

Temperature regulation range

Automatic °C2 ÷ 50

Manual °C2 ÷ 50

Antifreeze °COFF, 1 ÷ 50

Relay capacity 250 V ACA5

Temperature measurement range0 ÷ 50°C

Measurement precision°C0.5

Temperature resolution°C0.1

Programming resolutionh1

Gap between two temperature measurementss20

2

1

3

Tuo Wi-Fi-ENG-202203
