Vestil AHS-4-15-10-PNU Bruksanvisning
Sidor 26 Kran
Läs bruksanvisningen för Vestil AHS-4-15-10-PNU gratis online eller ladda ner PDF:en. 15 personer har tyckt att guiden var hjälpsam. Fråga om modellen? Ställ en fråga
Table of ContentsRev. 5/23/2025 AHS, MANUAL
Table of ContentsCopyright 2022 Vestil Manufacturing Co. Page 1 of 26
AHS-Series Steel Adjustable-Height Gantry Cranes
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description
of it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Vestil Manufacturing Co.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868
Fax: (260) 665-1339
Url: www.vestil.com Email: [email protected]
Table of Contents
Page
Table of Figures
Page
Specifications……………….…….
2 - 3
Fig. A Exploded View AHS-2-10-12, 2-10-14, & 2-10-16....
5
Signal Words…………..…………....
4
Fig. B Exploded View AHS-2-15 series …………..…………
6
Safety Instructions………………….
4
Fig. C Exploded View AHS-2-20-12, 2-20-14, & 2-20-16…..
7
Assembly Instructions…….
...18, 19, 20, 21
Fig. D Exploded View AHS-4-10-12, 4-10-14, & 4-10-16…..
8
Using the Crane…………………….
22– 23
Fig. E Exploded View AHS-4-15 series………………….……
9
Festoon Kit…………………………..
23
Fig. F Exploded View AHS-4-20-12, 4-20-14, & 4-20-16……
10
Record of Satisfactory Condition.
24
Fig. G Exploded View AHS-6-10-12, 6-10-14, & 6-10-16.….
11
National Standards………………...
24
Fig. H Exploded View AHS-6-15 series…………….………..
12
Inspections & Maintenance……..
24– 25
Fig. I Exploded View AHS-6-20-12, 6-20-14, & 6-20-16……
13
Labeling Diagram……………….…
25
Fig. J Exploded View AHS-8-10-12, 8-10-14, & 8-10-16……
14
Limited Warranty…………………...
26
Fig. K Exploded View AHS-8-15 series………………………
15
Fig. L Exploded View AHS-8-20-12, 8-20-14, & 8-20-16……
16
Fig. M Exploded View AHS-10-15-10…………………………
17
