TABLE OF CONTENTSRev. 3/28/2022 CBFC, MANUAL
TABLE OF CONTENTSCopyright 2022 Vestil Manufacturing Co. Page 1 of 13
CBFC Counterbalanced Floor Crane
Receiving Instructions
After delivery,remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description
of it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our TechnicalService and Parts Department at (260) 665-7586. The department
can also be contacted online at http://www.vestilmfg.com/parts_info.htm
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php.
V
ESTIL
M
ANUFACTURING
C
ORP
.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com[email protected]
Table of Contents
Page
Signal Words….………………………………………………………………………………………………….
2
Safety Instructions………………………………………………..……………………………...………………
2
CBFC-500 & CBFC-1000 Exploded View & Bill of Materials……………………..………………………
3
CBFC-500 Rated Loads for Specified Boom Lengths…….………………………………………………
4
CBFC-1000 Rated Loads for Specified Boom Lengths …….……………………….……….………….
5
CBFC-2000 Exploded View & Bill of Materials………………….…..………………………..……………
6
CBFC-2000 Rated Loads for Specified Boom Lengths…………..………………………....……………
7
Manual Hydraulic Pump Exploded View & Bill of Materials.……………………………………...……
8
Operating the Manual Hydraulic Pump………………..………………………………………..…………
9
Using the Crane………………………………………………………………………...…………………….…
9
Air Purging Procedure…………………………………………………………………………………………
10
Boom Length Adjustment…………………..…………………………………………………………………
10
Record of Satisfactory Condition……………………………………………………………………………
10
Inspections & Maintenance………………………………………………………………………………….
10 - 11
Troubleshooting…………………………………………………………………………………………………
11 - 12
Labeling Diagram……...……………………………………..…………………………………………..……
12
Limited Warranty…...……………………………………………………………………………………………
13
