TABLE OF CONTENTSRev. 11/3/2021FPG, MANUAL
TABLE OF CONTENTSCopyright 2021 Vestil Manufacturing Co. Page 1 of 11
FPG SERIES PORTABLE GANTRY CRANES
Receiving Instructions
After delivery,remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of it
on the bill of lading. If the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department can also
be contacted online at https://www.vestil.com/page-parts-request.php
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php
Table of Contents
Page
Specifications……….……………………………………………………...…………………………………………...
2
Signal Words……………………………………………………………………………………………………………..
2
Safety Instructions……………………………...………………………………..……………………………………..
3
National Standards…………………………………………………………………………………………………….
3
FIG. 1: FPG-3 Exploded Viewand Bills of Materials……….…..………….……………………..……………….
4
FIG. 2: FPG-6 Exploded View and Bill of Materials……………………………………………………………….
4
FIG. 3: FPG-10 Exploded View andBill of Materials……………………………………………………………...
5
FIG. 4: FPG-20 Exploded View and Bill of Materials……………………………………………………………...
5
Assembling the Crane.………………………………………………………………………………………………..
6 - 7
Using the Crane………………………………………………………………………………………………..……….
8
Recordof Satisfactory Condition………………………………………….………………………………………..
9
Inspectionsand Maintenance……………………………………………………………………………………....
9
Labeling Diagram………………………………………………………..………………………………………….…
10
Limited Warranty…………………………………………………………………………………….…………………
11
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail:
