Rev. 6/12/2018 JIB-P, MANUAL

Copyright 2016 Vestil Manufacturing Co. Page 1 of 14

JIB-P-Series Multi-Station Jib Cranes

Instruction Manual

Receiving instructions:

After delivery, IMMEDIATELY remove the packaging from the product. Inspect the product closely to determine

whether it sustained damage during transport. If damage is discovered, immediately record a complete

description of the damage on the bill of lading. If the product is undamaged, discard the packaging.

NOTICES:

1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the

product is used is exclusively the responsibility of the owner/end-user.

2) VESTIL is not liable for any injury or property damage that occurs as a consequence of failing to apply either:

a) Instructions in this manual; or

b) Information provided on labels affixed to the product.

Vestil is not responsible for any consequential damages sustained while assembling, using, or maintaining this

product.

Table of Contents

Crane specifications…..……………………………………………………………………………………………………… 2

Signal words…………………………………………………………………………………………………………………… 2

Safe use recommendations……………………………………………………………..…………………………………… 3

Function tests………………………………………………………………………………………………………………….. 3

FIGS. 1-3: Exploded parts diagrams and bills of materials………..……………………………………………………... 4 - 6

Assembly instructions………………………………………………………………………………………………………… 7 - 9

Operation instructions………………………………………………………………………………………………………… 10-11

Inspections & Maintenance…………………………………………………………………………………………………... 11-12

Labeling diagram………………………………………………………..…………………………………………………….. 13

Limited warranty……………………………………………………………………………………………………………….. 14

VESTIL MANUFACTURING CORP.

2999 North Wayne Street, P.O. Box 507, Angola, IN 46703

Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868

Fax: (260) 665-1339

www.vestilmfg.com e-mail:

HU[email protected]U

Produktspecifikationer
