Side: A

45 RPM

THE REVOLUTIO N GO

VSC -750SB

FOR MORE INFORMATI ON

SCAN BELOW

FUNCTION KNOB - BASIC OPERATION

FUNCTION KNOB - TO CYCLE THROUGH FEATURES

POWER: Press and hold for 1-2 seconds to turn the unit ON or OFF.

VOLUME: Rotate to raise or lower volume.

VINYL: Press to enter record player function mode.

VINYL STREAM: Press to connect the unit to an external Bluetooth speaker.

BLUETOOTH: Press to pair the unit with a Bluetooth device (smartphone).

FUNCTION & VOICE PROMPT

Press for: VINYL PLAYING: “Vinyl”

LOWER VOLUME: Rotate dial COUNTER-CLOCKWISE.

Dial will brighten when in use.

RAISE VOLUME: Rotate dial CLOCKWISE.

Dial will brighten when in use.

Unit will chime when MAX volume is reached.

Press for: VINYL STREAM: “Vinyl Stream”

“Vinyl Stream”

Dial will FLASH when searching.

When connected, prompt will say & dial will turn SOLID“Connected”

In Vinyl Stream mode, internal speakers will be disengaged.

Press for: BLUETOOTH: “Bluetooth”

Dial will FLASH when searching.

When connected, prompt will say & dial will turn SOLID. “Connected”

POWER ON: Press and hold for 1-2 seconds.

POWER OFF: Press and hold for 1-2 seconds.

When powering back ON, the unit will return

in the last used function mode.

RING COLOR

W H I T E

BATTERY VOICE PROMPTS

>80% “Battery Full”

26%–79% “Battery Medium”

<25% “Battery Low”

<10% “Low Battery”

B L U E

OPERATION

Q U I C K S T A R T G U I D E

WHEN THE UNIT IS DISCONNECTED

FROM A POWER SOURCE,

battery level will prompt as needed.

R E V O L U T I O N G O O V E R V I E W

Top View

Function Knob

Tone Arm Stylus

Tone Arm

Speed / Auto Stop Switches

Lift Lever

45 RPM Adaptor

Turntable Platter

Speaker

Rear View

R L

DC I N 9V

RE SET

CHAR GI NG

Charging LED

Unit Reset

RCA Line Out Jack

DC Power

Input Jack

Headphone

(3.5mm) Jack

Bottom View

Portable Charging Cable

Storage Area
