Sida 1/28
ViewBoard S
IFP2710
Touch Display
User Guide
Model No. VS17394
P/N: IFP2710
IMPORTANT: Please read this User Guide to obtain important information on installing
and using your product in a safe manner, as well as registering your product for future
service. Warranty information contained in this User Guide will describe your limited
coverage from ViewSonic Corporation, which is also found on our web site at http://
www.viewsonic.com in English, or in specic languages using the Regional selection
box in the upper right corner of our website. “Antes de operar su equipo lea cu
idadosamente las instrucciones en este manual”
i
Compliance Information
NOTE: This section addresses all connected requirements and statements regarding
regulations. Confirmed corresponding applications shall refer to nameplate labels
and relevant markings on unit.
FCC Compliance Statement
This device complies with part 15 of FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Warning: You are cautioned that changes or modifications not expressly approved
by the party responsible for compliance could void your authority to operate the
equipment.
Industry Canada Statement
CAN ICES-3 (B)/NMB-3(B)
CE Conformity for European Countries
The device complies with the EMC Directive 2014/30/EU and Low Voltage
Directive 2014/35/EU.
Following information is only for EU-member states:
The mark shown to the right is in compliance with the Waste Electrical and
Electronic Equipment Directive 2002/96/EC (WEEE).The mark indicates
the requirement NOT to dispose the equipment as unsorted municipal
waste, but use the return and collection systems according to local law.
ii
Indian Restriction of Hazardous Substances
Restriction on Hazardous Substances statement (India) This product complies
with the “India E-waste Rule 2011” and prohibits use of lead, mercury, hexavalent
chromium, polybrominated biphenyls or polybrominated diphenyl ethers in
concentrations exceeding 0.1 weight % and 0.01 weight % for cadmium, except for
the exemptions set in Schedule 2 of the Rule.
iii
Declaration of RoHS2 Compliance
This product has been designed and manufactured in compliance with Directive
2011/65/EU of the European Parliament and the Council on restriction of the use
of certain hazardous substances in electrical and electronic equipment (RoHS2
Directive) and is deemed to comply with the maximum concentration values issued
by the European Technical Adaptation Committee (TAC) as shown below:
Substance
Proposed Maximum
Concentration
Actual Concentration
Lead (Pb) 0.1% < 0.1%
Mercury (Hg) 0.1% < 0.1%
Cadmium (Cd) 0.01% < 0.01%
Hexavalent Chromium (Cr6+) 0.1% < 0.1%
Polybrominated biphenyls (PBB) 0.1% < 0.1%
Polybrominated diphenyl ethers (PBDE) 0.1% < 0.1%
Certain components of products as stated above are exempted under the Annex III
of the RoHS2 Directives as noted below:
Examples of exempted components are:
1. Mercury in cold cathode uorescent lamps and external electrode uorescent
lamps (CCFL and EEFL) for special purposes not exceeding (per lamp):
(1) Short length ( 500 mm): maximum 3.5 mg per lamp.≦
(2) Medium length ( 500 mm and 1,500 mm): maximum 5 mg per lamp.＞ ≦
(3) Long length ( 1,500 mm): maximum 13 mg per lamp.＞
2. Lead in glass of cathode ray tubes.
3. Lead in glass of uorescent tubes not exceeding 0.2% by weight.
4. Lead as an alloying element in aluminium containing up to 0.4% lead by weight.
5. Copper alloy containing up to 4% lead by weight.
6. Lead in high melting temperature type solders (i.e. lead-based alloys containing
85% by weight or more lead).
7. Electrical and electronic components containing lead in a glass or ceramic other
than dielectric ceramic in capacitors, e.g. piezoelectronic devices, or in a glass or
ceramic matrix compound.
iv
Cautions and Warnings
1. Read these instructions completely before using the equipment.
2. Keep these instructions in a safe place.
3. Heed all warnings and follow all instructions.
4. Sit at least 18” / 45cm from the LCD display.
5. Always handle the LCD display with care when moving it.
6. Never remove the rear cover. This LCD display contains high-voltage parts. You
may be seriously injured if you touch them.
7. Do not use this equipment near water. Warning: To reduce the risk of fire or
electric shock, do not expose this apparatus to rain or moisture.
8. Avoid exposing the LCD display to direct sunlight or another heat source. Orient
the LCD display away from direct sunlight to reduce glare.
9. Clean with a soft, dry cloth. If further cleaning is required, see “Cleaning the
Display” in this guide for further instructions.
10. Avoid touching the screen. Skin oils are difficult to remove.
11. Do not rub or apply pressure to the LCD panel, as it may permanently damage
the screen.
12. Do not block any ventilation openings. Install the equipment in accordance with
the manufacturer’s instructions.
13. Do not install near any heat sources such as radiators, heat registers, stoves, or
other devices (including amplifiers) that produce heat.
14. Place the LCD display in a well ventilated area. Do not place anything on the
LCD display that prevents heat dissipation.
15. Do not place heavy objects on the LCD display, video cable, or power cord.
16. If smoke, an abnormal noise, or a strange odor is present, immediately switch
the LCD display off and call your dealer or ViewSonic. It is dangerous to continue
using the LCD display.
17. Do not attempt to circumvent the safety provisions of the polarized or grounding-
type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade
and the third prong are provided for your safety. If the plug does not fit into your
outlet, consult an electrician for replacement of the outlet.
18. Protect the power cord from being tread upon or pinched, particularly at the plug,
and the point where if emerges from the equipment. Be sure that the power outlet
is located near the equipment so that it is easily accessible.
19. Only use attachments/accessories specified by the manufacturer.
(Continued on next page)
1
Copyright Information
Copyright © ViewSonic® Corporation, 2018. All rights reserved.
Macintosh and Power Macintosh are registered trademarks of Apple Inc.
Microsoft, Windows, and the Windows logo are registered trademarks of Microsoft
Corporation in the United States and other countries.
ViewSonic, the three birds logo, OnView, ViewMatch, and ViewMeter are registered
trademarks of ViewSonic Corporation.
VESA is a registered trademark of the Video Electronics Standards Association.
DPMS, DisplayPort, and DDC are trademarks of VESA.
ENERGY TAR S ® is a registered trademark of the U.S. Environmental Protection
Agency (EPA).
As an E SNERGY TAR® partner, ViewSonic Corporation has determined that this
product meets the E SNERGY TAR® guidelines for energy efficiency.
Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors
or omissions contained herein; nor for incidental or consequential damages resulting
from furnishing this material, or the performance or use of this product.
In the interest of continuing product improvement, ViewSonic Corporation reserves
the right to change product specifications without notice. Information in this
document may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means,
for any purpose without prior written permission from ViewSonic Corporation.
2
Product Registration
To fulfill possible future product needs, and to receive additional product information
as it becomes available, please visit your region section on ViewSonic’s website to
register your product online.
The ViewSonic CD also provides an opportunity for you to print the product
registration form. Upon completion, please mail or fax to a respective ViewSonic
office. To find your registration form, use the directory “:\CD\Registration”.
Registering your product will best prepare you for future customer service needs.
Please print this user guide and fill the information in the “For Your Records” section.
Your LCD displays serial number is located on the rear side of the display.
For additional information, please see the “Customer Support” section in this guide.
For Your Records
Product Name:
Model Number:
Document Number:
Serial Number:
Purchase Date:
IFP2710
ViewSonic Widescreen LCD Display
VS17394
IFP2710_UG_ENG Rev. 1A 07-26-18
Product disposal at end of product life
ViewSonic respects the environment and is committed to working and living green.
Thank you for being part of Smarter, Greener Computing.
Please visit ViewSonic website to learn more.
USA & Canada: http://www.viewsonic.com/company/green/recycle-program/
Europe: http://www.viewsoniceurope.com/eu/support/call-desk/
Taiwan: https://recycle.epa.gov.tw/
3
Getting Started
Congratulations on your purchase of a ViewSonic® LCD display.
Important! Save the original box and all packing material for future shipping needs.
NOTE: The word “Windows” in this user guide refers to Microsoft Windows operating
system.
Package Contents
Your LCD display package includes:
• LCD display
• Power cord
• Audio cable
• D-Sub cable
• HDMI cable
• USB cable
• Quick Start Guide
• Passive Touch Pen
NOTE: The INF file ensures compatibility with Windows operating systems, and
the ICM file (Image Color Matching) ensures accurate on-screen colors. ViewSonic
recommends that you install both the INF and ICM files.
4
Quick Installation
1. Connect video cable
• Make sure both the LCD display and computer are turned OFF.
• Remove rear panel covers if necessary.
• Connect the video cable from the LCD display to the computer.
2. Connect power cord (and AC/DC adapter if required)
100-240 cVa
50/60 Hz
Power Adapter
Supplier: Channel Well Technology Co., Ltd
Model: KPL-040F-VI
*1: HDMI Out
*2: HDBT Out
HDBT: is transmitted over category 5e cables
or above up to 100 m (328 ft) long, with 8P8C
modular connectors of the type commonly used
for Ethernet local area network connections.
*1
*2
3. Turn ON LCD display and computer
Turn ON the LCD display, then turn ON the computer. This sequence (LCD
display before computer) is important.
NOTE: Windows users may receive a message asking them to install the INF file.
To access the file, please use the directory ":\CD\vsfiles".
4. Windows users: Set the timing mode (example: 1024 x 768)
For instructions on changing the resolution and refresh rate, see the graphics
card’s user guide.
5. Installation is complete. Enjoy your new ViewSonic LCD display.
Additional Software Installation (Optional)
"Issue a 1 year myViewBoard Personal Subscription Coupon"
1. Please visit https://myviewboard.com and sign up an account.
2. Sign in and “Enter a Coupon” in the menu.
3. Fill in the S/N of IFP2710 and your account will be upgraded from Basic to
Personal.
5
Hardware Installation
1
2
3
Magnetic adsorption Passive Touch Pen
6
Control of the Touch Function
1. Before using the touch function, make sure the USB cable is connected and the
Windows operating system is started.
NOTE:
1. The touch function may need about 5 seconds to resume if the USB cable is re-
plugged or the computer resumes from sleep mode.
2. The touchscreen can only detect up to 10 fingers simultaneously.
3. Cursor does not accurately follow your finger when you touch the screen, please
follow the steps below to recover.
(OS: Windows 7, Windows 8, Windows 8.1 and Windows 10 Calibration)
1. Open Control Panel, open Hardware and Sound, and then open Tablet PC Settings
2. Select Calibration
3. Follow the instructions to recalibrate your screen
Tilt angle adjustment
1. Tilt angle adjustment (-5˚ to 90˚)
2. Swivel angle adjustment(L/R 177.5˚)
7
Using the Security Lock
The security connector is located on the back side of the monitor. For more
information on installation and usage.
Below is an example of setting up the lock on a table for your reference.
8
Wall Mounting (Optional)
NOTE: For use only with UL Listed Wall Mount Bracket.
To obtain a wall-mounting kit or height adjustment base, contact ViewSonic® or
your local dealer. Refer to the instructions that come with the base mounting kit. To
convert your LCD display from a desk-mounted to a wall-mounted display, do the
following:
1. Verify that the power button is turned Off, then disconnect the power cord.
2. Lay the LCD display face down on a towel or blanket.
3. Remove the base. (Screws removal might be required.)
4. Find and identify one of the following VESA mount interfaces (a,b,c) located on
the back of your display (refer to “Specifications” page for your displays mounting
interface). Attach the mounting bracket from the VESA compatible wall mounting
kit using screws of the appropriate length.
a. b. c.
75mm
75mm
100mm
100mm
100mm
100mm
200mm
5. Attach the LCD display to the wall, following the instructions in the wall-mounting
kit.
9
Using the LCD Display
Setting the Timing Mode
Setting the timing mode is important for maximizing the quality of the screen image
and minimizing eye strain. The consists of the (example timing mode resolution
1024 x 768) and (or vertical frequency; example 60 Hz). After setting refresh rate
the timing mode, use the OSD (On-screen Display) controls to adjust the screen
image.
For optimal picture quality, please use the recommended timing mode specific to
your LCD display listed on the “Specification” page.
To set the Timing Mode:
• Setting the resolution: Access "Appearance and Personalization" from Control
Panel via the Start Menu, and set the resolution.
• Setting the refresh rate: See your graphic card’s user guide for instructions.
IMPORTANT: Please make sure that your graphics card is set to 60Hz vertical
refresh rate as the recommended setting for most LCD displays. Choosing a non-
supported timing mode setting may result in no image being displayed, and a
message showing “Out of Range” will appear on screen.
OSD and Power Lock Settings
• Press and hold [1] and the up arrow ▲ for 10 seconds. If any buttons OSD Lock:
are pressed the message will display for 3 seconds.OSD Locked
• Press and hold [1] and the up arrow ▲ again for 10 seconds.OSD Unlock:
• Press and hold [1] and the down arrow ▼ for 10 seconds. Power Button Lock:
If the power button is pressed the message will display Power Button Locked
for 3 seconds. With or without this setting, after a power failure, your LCD
display’s power will automatically turn ON when power is restored.
• Press and hold [1] and the down arrow ▼ again for 10 Power Button Unlock:
seconds.
10
Adjusting the Screen Image
Use the buttons on the front control panel to display and adjust the OSD controls
which display on the screen.
Standby Power On/Off
Power light
Blue = ON
Orange = Power Saving
[1] Displays the Main Menu or exits the control screen and saves
adjustments.
[2] Displays the control screen for the highlighted control.
Also a shortcut to toggle analog and digital connection.
▲ ▼/Scrolls through menu options and adjusts the displayed control.
Brightness/Contrast ( ) / Audio Adjust ( )▼ ▲
Do the following to adjust the display setting:
1. To display the Main Menu, press button [1].
NOTE: All OSD menus and adjustment screens disappear automatically after
about 15 seconds. This is adjustable through the OSD timeout setting in the
setup menu.
2. To select a control to adjust, press ▲ or ▼ to scroll up or down in the Main
Menu.
3. After the desired control is selected, press button [2].
4. To save the adjustments and exit the menu, press button [1] until OSD
disappear.
The following tips may help you optimize your display:
• Adjust the computer’s graphics card to support a recommended timing mode
(refer to “Specifications” page for recommended setting specific to your LCD
display). To find instructions on “changing the refresh rate”, please refer to the
graphics card’s user guide.
• If necessary, make small adjustments using H. POSITION and V. POSITION
until the screen image is completely visible. (The black border around the edge
of the screen should barely touch the illuminated “active area” of the LCD
display.)
13
Other Information
Specifications
LCD Type
Display Size
Color Filter
Glass Surface
TFT (Thin Film Transistor), Active Matrix 1920 x 1080 LCD,
0.31125 mm pixel pitch
Metric: 69 cm
Imperial: 27” (27” viewable)
RGB vertical stripe
Glare*
Input Signal Video Sync RGB analog (0.7/1.0 Vp-p, 75 ohms)
HDMI (TMDS digital, 100ohms)
Composite Sync, Separate Sync, Sync on Green
fh:24-83 kHz, fv:50-76 Hz
Compatibility PC Up to 1920 x 1080 Non-interlaced
Resolution1Recommended
Supported
1920 x 1080 @ 60 Hz
1680 x 1050 @ 60 Hz
1600 x 1200 @ 60 Hz
1440 x 900 @ 60, 75 Hz
1280 x 1024 @ 60, 75 Hz
1024 x 768 @ 60, 70, 72, 75 Hz
800 x 600 @ 56, 60, 72, 75 Hz
640 x 480 @ 60, 75 Hz
720 x 400 @ 70 Hz
Power Voltage 100-240 VAC, 50/60 Hz (auto switch)
Display area Full Scan 597.6 mm (H) x 336.15 mm (V)
23.53” (H) x 13.23” (V)
Operating
conditions
Temperature
Humidity
Altitude
+32 °F to +104 °F (0 °C to +40 °C)
20% to 90% (non-condensing)
To 10,000 feet
Storage
conditions
Temperature
Humidity
Altitude
-4 °F to +140 °F (-20 °C to +60 °C)
5% to 90% (non-condensing)
To 40,000 feet
Dimensions Physical 653.20 mm (W) x 449.07 mm (H) x 270 mm (D)
25.74” (W) x 17.68” (H) x 10.63” (D)
Wall Mount Distance 100 x 100 mm
Weight Physical 21.16 lb (9.6 kg)
Power saving
modes
On
Off
26W (Typical) (Blue LED)
<0.3W
1 Do not set the graphics card in your computer to exceed these timing mode; doing so may result in permanent
damage to the LCD display.
* For displays with glossy bezels the user should consider the placement of the display as the bezel may cause
disturbing reections from surrounding light and bright surfaces.
14
Cleaning the LCD Display
• MAKE SURE THE LCD DISPLAY IS TURNED OFF.
• NEVER SPRAY OR POUR ANY LIQUID DIRECTLY ONTO THE SCREEN OR
CASE.
To clean the screen:
1. Wipe the screen with a clean, soft, lint-free cloth. This removes dust and other
particles.
2. If the screen still not clean, apply a small amount of non-ammonia, non-alcohol
based glass cleaner onto a clean, soft, lint-free cloth, and wipe the screen.
To clean the case:
1. Use a soft, dry cloth.
2. If the case still not clean, apply a small amount of a non-ammonia, non-alcohol
based, mild non-abrasive detergent onto a clean, soft, lint-free cloth, then wipe
the surface.
Disclaimer
• ViewSonic® does not recommend the use of any ammonia or alcohol-based
cleaners on the LCD display screen or case. Some chemical cleaners have been
reported to damage the screen and/or case of the LCD display.
• ViewSonic will not be liable for damage resulting from use of any ammonia or
alcoholbased cleaners.
16
Customer Support
For technical support or product service, see the table below or contact your reseller.
NOTE: You will need the product serial number.
Country/Region Website T= Telephone
C = CHAT ONLINE Email
Australia/New
Zealand www.viewsonic.com.au AUS= 1800-880-818
NZ= 0800-008-822 service@au.viewsonic.com
Canada www.viewsonic.com T= 1-866-463-4775 service.ca@viewsonic.com
Europe www.viewsoniceurope.com www.viewsoniceurope.com/eu/support/call-desk/
Hong Kong www.hk.viewsonic.com T= (852)-3102-2900 service@hk.viewsonic.com
India www.in.viewsonic.com T= 1800-419-0959 service@in.viewsonic.com
Korea ap.viewsonic.com/kr/ T= 080-333-2131 service@kr.viewsonic.com
Latin America www.viewsonic.com/la/ C= http://www.viewsonic.com/
la/soporte/servicio-tecnico soporte@viewsonic.com
Nexus Hightech Solutions, Cincinnati #40 Desp. 1 Col. De los Deportes Mexico D.F.
Tel: 55) 6547-6454 55)6547-6484
Other places please refer to http://www.viewsonic.com/la/soporte/servicio-tecnico#mexico
Macau www.hk.viewsonic.com T= (853)-2833-8407 service@hk.viewsonic.com
Middle East ap.viewsonic.com/me/ Contact your reseller service@ap.viewsonic.com
Puerto Rico &
Virgin Islands www.viewsonic.com
T= 1-800-688-6688 (English)
C= http://www.viewsonic.com/
la/soporte/servicio-tecnico
"service.us@viewsonic.com
soporte@viewsonic.com"
Singapore/ www.viewsonic.com/sg/ T= 65 6461 6044 service@ap.viewsonic.com
Malaysia www.viewsonic.com/my/ T= 1800 - 88 - 8997 service@ap.viewsonic.com
Thailand www.viewsonic.com/th/ T= 02-7214091-3 service@ap.viewsonic.com
South Africa ap.viewsonic.com/za/ Contact your reseller service@ap.viewsonic.com
United States www.viewsonic.com T= 1-800-688-6688 service.us@viewsonic.com
Indonesia www.viewsonic.com/id/ Contact your reseller service@ap.viewsonic.com
Japan www.viewsonic.com/jp/ T= 050-3388-6832 service@ap.viewsonic.com
Philippines www.viewsonic.com/ph/ Contact your reseller service@ap.viewsonic.com
Vietnam www.viewsonic.com/vn/ Contact your reseller service@ap.viewsonic.com
Taiwan www.viewsonic.com/tw/ T= 0800-899-880 service@tw.viewsonic.com
17
Limited Warranty
ViewSonic® LCD Display
What the warranty covers:
ViewSonic warrants its products to be free from defects in material and workmanship, under normal
use, during the warranty period. If a product proves to be defective in material or workmanship during
the warranty period, ViewSonic will, at its sole option, repair or replace the product with a like product.
Replacement product or parts may include remanufactured or refurbished parts or components.
How long the warranty is effective:
ViewSonic LCD displays are warranted for between 1 and 3 years, depending on your country of
purchase, for all parts including the light source and for all labour from the date of the first consumer
purchase
Who the warranty protects:
This warranty is valid only for the first consumer purchaser.
What the warranty does not cover:
1. Any product on which the serial number has been defaced, modified or removed.
2. Damage, deterioration or malfunction resulting from:
a. Accident, misuse, neglect, fire, water, lightning, or other acts of nature, unauthorized product
modification, or failure to follow instructions supplied with the product.
b. Any damage of the product due to shipment.
c. Removal or installation of the product.
d. Causes external to the product, such as electrical power fluctuations or failure.
e. Use of supplies or parts not meeting ViewSonic’s specifications.
f. Normal wear and tear.
g. Any other cause which does not relate to a product defect.
3. Any product exhibiting a condition commonly known as "image burn-in" which results when a
static image is displayed on the product for an extended period of time.
4. Removal, installation, one way transportation, insurance, and set-up service charges.
How to get service:
1. For information about receiving service under warranty, contact ViewSonic Customer Support
(Please refer to Customer Support page). You will need to provide your product's serial number.
2. To obtain warranty service, you will be required to provide (a) the original dated sales slip, (b)
your name, (c) your address, (d) a description of the problem, and (e) the serial number of the
product.
3. Take or ship the product freight prepaid in the original container to an authorized ViewSonic
service center or ViewSonic.
4. For additional information or the name of the nearest ViewSonic service center, contact
ViewSonic.
Limitation of implied warranties:
There are no warranties, express or implied, which extend beyond the description contained herein
including the implied warranty of merchantability and fitness for a particular purpose.
Produktspecifikationer
| Varumärke: | Viewsonic |
| Kategori: | Övervaka |
| Modell: | IFP2710 |
| Vikt: | 130 g |
| Förpackningens vikt: | 150 g |
| Varumärkeskompatibilitet: | Neff |
Behöver du hjälp?
Om du behöver hjälp med Viewsonic IFP2710 ställ en fråga nedan och andra användare kommer att svara dig
Övervaka Viewsonic Manualer
30 Mars 2025
22 Mars 2025
19 Mars 2025
19 Mars 2025
15 Februari 2025
6 Februari 2025
5 Januari 2025
5 Januari 2025
3 Januari 2025
3 Januari 2025
Övervaka Manualer
- Optoma
- MSI
- HKC
- ONYX
- IOIO
- Hitachi
- KTC
- Thomson
- Medion
- Elvid
- Renkforce
- PeakTech
- Xenarc
- Raysgem
- PreSonus
Nyaste Övervaka Manualer
9 April 2025
9 April 2025
8 April 2025
8 April 2025
7 April 2025
5 April 2025
5 April 2025
4 April 2025
4 April 2025
2 April 2025
