User Manual

VWM198PBA-R, VWM198PBA-L

VWM198SBA-R, VWM198SBA-L

vintec.com

As the appliance contains

a ammable refrigerant, it

is essential to ensure that

the refrigerant pipes are not

damaged.

The quantity and type of

the refrigerant used in your

appliance is indicated on the

rating plate.

Standard EN378 species that

the room in which you install

your appliance must have

a volume of 1m³ per 8g of

hydrocarbon refrigerant used in

the appliances. This is to avoid

the formation of ammable gas/

air mixtures in the room where

the appliance is located in the

event of a leak in the refrigerant

circuit.

WARNING:

Keep ventilation openings in

the appliance’s cabinet or in

the built-in structure clear of

obstruction.

WARNING:

Do not use mechanical devices

or other means to accelerate

the defrosting process than

those recommended by the

manufacturer.

WARNING:

Do not damage the refrigerant

system.

WARNING:

Do not use electrical

appliances inside the

refrigerated storage

compartment, unless they are

of a type recommended by the

manufacturer.

WARNING:

This appliance is suitable for

indoor use only.

WARNING:

This appliance is not intended

for use by persons (including

children) with reduced physical,

sensory or mental capabilities,

or lack of experience and

knowledge, unless they have

been given supervision or

instruction concerning use

of the appliance by a person

responsible for their safety.

Children should be supervised to

ensure that they do not play with

the appliance.

Warning

User Manual

WARNING:

Children must not clean the

appliance or carry out general

maintenance unless they are at

least 8 years old and are being

supervised.

WARNING:

Children must not play with, on,

or around the appliance.

WARNING:

This appliance contains

insulation formed with ammable

blowing gases. Avoid safety

hazards by carefully disposing of

this appliance.

WARNING:

Do not store explosives, such

as aerosol cans with ammable

propellants in the appliance.

WARNING:

When this symbol is used, it

indicates ammable materials

are used. To avoid relevant

hazards, it is required to carefully

dispose of this appliance.

!R600A REFRIGERANT

WARNING:

This appliance contains R600a

refrigerant. Avoid safety hazards

by carefully installing, handling,

servicing and disposing of this

appliance.

●It is hazardous for anyone

other than an Authorised

Service Person to service this

appliance. In Queensland –

the authorised Service Person

MUST hold a Gas Work

Authorisation for hydrocarbon

refrigerants, to carry out

Servicing or repairs which

involve the removal of covers.

●Ensure that the tubing of

the refrigerant circuit is not

damaged during transportation

and installation.

WARNING:

When positioning the appliance,

ensure the power cord is not

trapped or damaged.

WARNING:

Do not locate multiple portable

socket-outlets or portable power

supplies at the rear of the

appliance.

User Manual

WARNING:

If the power cord is damaged,

it must be replaced by the

manufacturer, its service agent

or similarly qualied persons

in order to avoid a hazard (For

Australia and New Zealand).

●Always keep the keys in a

separate place and out of

reach of children.

●Before servicing or cleaning

the appliance, unplug the

appliance from the mains

or disconnect the electrical

power supply.

●Frost formation on the

interior evaporator wall and

upper parts is a natural

phenomenon. Therefore, the

appliance should be defrosted

during normal cleaning or

maintenance.

●Please note that changes to

the appliance construction

may cancel all warranty and

product liability.

●If the supply cord is damaged,

it must be replaced by the

manufacturer, its service

agent, or similarly qualied

persons inorder to avoid a

hazard.

●Do not use extension cords.

●This appliance is intended to

be used exclusively for the

storage of wine.

CLASS 1 LED PRODUCT

WARNING:

LED lighting

Your appliance is tted with long

life LED lighting. In the unlikely

event the LED lights should fail,

then the LED lights should be

serviced by the service agent,

to avoid a safety hazard. Refer

to the warranty page for contact

details.

User Manual

Contents

Warning ......................................................2

Before use ..................................................6

Savings in energy consumption in the use .6

Get to know your wine cooler .....................7

Electrical connection ...................................9

Installation and start-up ..............................9

Installation ................................................10

Operation and function .............................13

Defrosting, cleaning and maintenance .....18

Fault nding ..............................................19

Charcoal Filter Location & removal .........20

Disposal ....................................................21

Warranty for Australia and New Zealand ..22

User Manual

On receipt, check to ensure that the

appliance has not been damaged during

transport. Transport damage should be

reported to the local distributor before the

wine cooler is put to use.

Remove the packaging. Clean the inside of

the cabinet using warm water with a mild

detergent. Rinse with clean water and dry

thoroughly (see cleaning instructions). Use

a soft cloth.

If during transport the appliance has been

laid down, or if it has been stored in cold

surroundings (colder than + 5°C), it must be

allowed to stabilise in an upright position for

at least 24 hours before being switched on.

Note: Do not switch on for at least

24 hours

Before use

The energy consumption reduces ..

● the lower the ambient temperature is.

● the warmer thermostat set point is.

● the lower the number and the shorter the

length of the door openings is.

Savings in energy consumption in the use

Note: for household use only

This appliance is intended to be used in

household and similar applications such as

● sta󰀨 kitchen areas in shops, o󰀩ces and

other working environments;

● farm houses and by clients in hotels,

motels and other residential type

environments;

● bed and breakfast type environments;

● catering and similar non-retail

applications.

Important Information that may

impact your Manufacturer’s

Warranty

Adherence to the directions for use in this

manual is extremely important for health

and safety. Failure to strictly adhere to the

requirements in this manual may result in

personal injury, property damage and af-

fect your ability to make a claim under the

Vintec manufacturer’s warranty provided

with your product. Products must be used,

installed and operated in accordance with

this manual. You may not be able to claim

on the Vintec manufacturer’s warranty in the

event that your product fault is due to failure

to adhere to this manual.

User Manual

Get to know your wine cooler

g.1

Control panel

Lighting

Fan

Door

Position 1 Display shelf

Name plate

Position 2 Fixed shelf sits on

liner rib with screw xation

bracket at the rear.

Sealing strip

Position 3-9

Telescopic shelf

Position 10 Fixed 3/4 shelf-

site on liner rib

Position 11 Bottom liner

Wheel

Kick plate

Adjustable feet

Light

Lock

VWM198PBA-L - VWM198PBA-R

User Manual

Placement

For safety and operational reasons, the

appliance must not be installed outdoors.

The appliance should be placed on a level

surface in a dry, well ventilated room (max.

75% relative air humidity). Never place the

appliance close to sources of heat such as

cookers or radiators, and avoid placing it in

direct sunlight.

Ambient temperature

The climate class is stated on the name

plate. This species the optimum ambient

temperature. Wine coolers with winter

position, however, function at ambient

temperatures as low as 5ºC.

Installation and start-up

Electrical connection

Climate class Optimum room

temperature

SN +10 ºC to +32 ºC

N +16 ºC to +32 ºC

ST +16 ºC to +38 ºC

T +16 ºC to +43 ºC

g.3

xxxxxxxxxxx

xxxxx

x.xxx

xxxxxxxxxxxxxxx

Wiring and connections in power supply

systems must been all applicable (local and

national) electrical codes. Consult these

codes lengths and sizes prior to cabinet

installation.

The socket should be freely accessible.

Connect the appliance only to 220/240 V

/ 50Hz alternating current via a correctly

installed earthed socket.

The socket must be fused with a 10-13 A

fuse.

Information regarding voltage, current or

power are given on the rating plate

The power cord may be replaced by a

technician only.

CAUTION: Never put the appliance in a

location that is too cold or unprotected, for

example in a garage or on a verandah.

The rating plate provides various technical

information as well as type and serial

number.

Max ambient temperature

class.

Class 3 25 °C

Class 4 30 °C

Class 5 40 °C

Class 7 35°C

User Manual

The surface on which the appliance is to be

placed must be level. Do not use a frame or

similar.

The appliance can be installed as a free-

standing unit against a wall, built into a

closet or lined up with other appliances.

It is important that the appliance be

well ventilated and that air can circulate

unhindered above, below and around it.

The gures below illustrate how the

necessary air circulation around the

appliance can be ensured (g 4).

Ensure the plug is accessible when the ap-

pliance is in position, or a switch is incor-

porated in the xed wiring according to the

wiring rules. (See a licensed electrician for

further advice).

g. 4

g. 5

Installation

50mm

min.30mm min.30mm

609mm

10mm

30mm

35mm

1072mm

595mm

145

The spacers on the rear of the appliance

ensure su󰀩cient air circulation. Fit the two

spacers with the appliance as shown in g. 6

g. 6

User Manual

It is recommended to install the anti-tip

device to avoid the unit from tipping over.

The anti-tip device must either be secured

to the oor or wall, whatever is most

appropriate.

Please note a distance part must be applied

if anti-tip is secured to wall.

Anti-tip

g. 7

g. 8 g. 9

User Manual

It is important that the appliance be

absolutely level. It can be levelled by

screwing the adjustable feet at the front of

the appliance up or down (g. 10).

Use a spirit level to check that the appliance

is absolutely level sideways.

Setting up

Fixed shelf

Max. 65 kg.

g. 11

g. 13

g. 12

Telescopic shelf

Max. 13 kg.

g. 10

To optimise the storage capacity of you

wine cabinet it has been designed so that

only Bordeaux can be stored on the outer

position of the shelf.

User Manual

Lights settings menu

Press & hold Light button for 3 seconds to

enter the Lights settings menu.

Both temperature displays blink and show a

specic code.

Any alert turns o󰀨 temporarily.

Press “-/+” to increase/decrease the light

“level”.

Light behaviour

Upper temperature display enables the

following settings.

1A: Lights always ON bright when door is

open. Lights dim to selected level when the

door is closed. This is the factory default

setting.

2A: Lights always ON bright when door

is open. Light turn OFF when the door is

closed.

3A: Lights always ON.

4A: Lights always ON at selected dim level

when door is open. LIghts change to the

highest dim level when the door is closed.

Light dim level

Lower temperature display controls light

dim level. There are 9 light levels

1L: Lowest level / least bright

9L: Highest level / brightest. This is the

factory default dim level.

Child Lock

Press and hold Mode button for 3 seconds

to activate/deactivate child lock.

Child lock indicator. Enabling Child lock

prevents changes to the UI until disabled.

Sabbath mode Activation

Simultaneously press and hold

Upper Zone “-/+” button and Lower Zone "-"

button for 5 seconds to activate/deactivate

Sabbath mode. When activated, both Upper

and Lower temperature displays show "Sb"

and "On" until it is deactivated.

While inSabbath mode:

● All button functionality is disabled except

for deactivating Sabbath Mode

● All lights except for Upper and Lower

temperature displays are disabled, and

all sounds are munted.

● Opening or closing the door will not

enable any notications or alarms. The

compressor will only engage or change

speeds after the door has been left open

for at least 30 seconds.

● No alerts will be displayed until the

Sabbath Mode is deactivated, except the

High/Low temperature alerts.

● All sounds are muted except the audio

alarm for High/Low temperature alerts.

User Manual

Sabbath Mode exception:

The High/Low Temperature alert will

displayed in case of a high or low

temperature inside the appliance. The

alert icon will turn On, but will not blink and

it will remain until the Sabbath mode is

deactivated. An audio alarm will sound and

automatically turn O󰀨 after 10 minutes.

When Sabbath mode is deactivation,

temperature displays will show the current

temperatures.

Changing between°C/°F

Single combined press & release on

increase bottom temperature set & Light

button to change the temperature type

(°C/°F).

When °C is set, Bottom & Upper

temperature display shows and blinks

“°C”for 5 seconds before returning to set

temperature & “°C” for 5 seconds.

Any alert turns o󰀨 temporarily.

When F° is set, Bottom & Upper

temperature display shows and blinks “F°”

& “F°” for 5 seconds.

Any alert turns o󰀨 temporarily.

Reset Filter alert

Press & Hold combined on Mode &

decrease bottons for 5 seconds to reset the

lter change counter.

If the alert is on, it turns o󰀨.

Single/Muliti/Cellaring zone set

Single press Mode to change the Single

zone, Multi zone, and Cellaring mode.

If the mode set is Single, the Single zone

feedback will light-up, and blink and both

temperatures change to 18°C. After 5

seconds without any interaction wih the

Mode button, the Single zone feedback

stops blinking and keeps steady, and both

temperatures show the current temperature.

In Single zone mode, both temperature

controls will work in sync.

If the mode set is Multi, the Multi zone

feedback will light-up, and blink and the

upper temperature changes to 18°C and

8°C on the bottom. After 5 seconds without

any interaction with the Mode button, the

Multi zone feedback stops blinking and

keeps steady and both temperatures show

the current temperature.

In Multi zone mode, each temperature

control will work separately.

User Manual

If the mode set is Cellaring, the Single and

Multi zone feedback will be O󰀨, and Bottom

& Upper temperature display shows “CE” &

“CE” blinking. After 5 seconds without any

interaction with the Mode button, the ”CE”

stops blinking and keeps showing ”CE” until

the Cellaring mode is deactivated.

In Cellaring mode, the temperature is xed

and can not be changed - 12°C.

Demo mode

Press & Hold combined on Mode & Lights

buttons for 5 seconds to activate/deactivate

Demo mode.

When activated, the bottom & Upper

temperature display shows and blinks ”dE &

”ON” for 5 seconds.

Any alert turns o󰀨 temporarily.

To keep communication that the machine

is in Demo mode, - every 5 minutes the

Bottom & Upper temperature display shows

and blinks ”dE & ”OF” for 5 seconds.

When deactivated, Bottom & Upper

temperature display shows and blinks ”dE”

& ”OF for 5 seconds.

Any alert turns o󰀨 temporarily.

Mute sounds

Press & Hold combined on decrease

bottom temperature set & Light buttons for 5

seconds to activate/deactivate Mute sounds.

High / Low temperature alert

If the Current temperature is 5°C above the

Set temperature for more than 60 minutes,

High Temperature alert shows “Hº” and

blinks the alert icon.

If the Current temperature is 2°C below the

Set temperature for more than 60 minutes,

Low Temperature alert shows “Lº” and

blinks the alert icon.

The alerts will not sound in the rst

90 minutes after power on.

Door open alert

When the door stays open for some amount

of time (5 minutes) the icon turns On and

the lights start to dim up and down. If

the door is kept open, after more than 2

minutes a sound is played.

Any interaction on the Control panel

disables the blinking and audio signal. The

icon stays on as long the door is open and

the lights go back to normal.

User Manual

Produktspecifikationer

Varumärke:	Vintec
Kategori:	Vinklimatskåp
Modell:	VWM198SBA
Färg på produkten:	Zwart
Förpackningens vikt:	110 g
Förpackningens bredd:	220 mm
Djuppackning:	160 mm
Förpackningshöjd:	40 mm
Användarmanual:	Ja
Typ av förpackning:	Blister
Videolägen som stöds:	1080p
Ursprungsland:	China
Antal per paket:	1 stuk(s)
Kompatibla operativsystem:	Windows 10, 8, 7
(Ytter) huvudpaketets höjd:	360 mm
(Ytter) huvudförpackningens bredd:	460 mm
(Ytter) huvudförpackningens bruttovikt:	5600 g
(Ytre) huvudpaketets längd:	250 mm
Kvantitet per (yttre) huvudkartong:	50 stuk(s)
Harmoniserad systemkod (HS):	84733020
(Ytter) huvudförpackningens innehåll:	41400 cm³
Förpackningsvolym:	1408 cm³
Anslutning 1:	USB 3.0
Anslutning 2:	HDMI
Anslutning 1 typ:	Mannelijk
Anslutning 2 typ:	Vrouwelijk
Maximal upplösning (HDMI):	1920 x 1080 Pixels
