VITEKCCTV.COM

(888) VITEK-70

VTC-TNB4RMA3

4 MegaPixel Advanced A.I. Motorized IP Bullet Camera

Image Sensor

Image Size

Resolution

Min. Illumination

Lens

Day/Night

IR LEDs

IR Distance

Video Compression

Audio Compression

Main-Stream

Bit Rate

Wide Dynamic Range (WDR)

Digital Noise Reduction (DNR)

Quality

Image Setting

Intelligent Analytics

Smart Alarm

Region of Interest (ROI)

Audio

Local Storage

Remote Viewing

Supported Browsers

Connection Protocol

Resistance

Power Input

Power Consumpt. (12VDC)

Power Consumpt. (PoE)

Working Environment

Weight

Dimensions: L × W × H

1/3” 4.0 Megapixel Progressive Scan CMOS

4 MegaPixel (2592 × 1520)

4 MP (2592 × 1520) / 3 MP (2304 × 1296) /

1080P (1920 × 1080) / 720P (1280 × 720) /

D1/CIF (480 × 240)

0 Lux (IR LED ON)

2.8mm~12mm Motorized Varifocal Lens

True Day/Night by ICR

2 Matrix Style IR LEDs

Up to 165’

Smart H.265 / H.265+ / H.265 / Smart H.264 /

H.264+ / H.264 / MJPEG

G.711A / G.711U

4 MP, 2K, 3MP, 1080P, 720P

(60Hz: 1 ~ 30fps; 50Hz: 1~25fps )

HFR mode: 1080P / 720P( 60Hz: 1~60fps; 50Hz: 1~50fps)

64 Kbps ~ 8 Mbps

120dB Super WDR

XD-DNR (2D-DNR & 3D-DNR)

VBR (Five Levels of Adjustment) / CBR (Adjustable)

ROI, Saturation, Brightness, Chroma, Contrast,

Sharpen, NR; Adjustable through client software or web

browser

Face Detection, Target Counting, Intrusion, Region

Entrance / Exit, Line Crossing, Scene Change, Video Blur

Motion Detection, SD card error, SD card full

Each ROI to be configured separately

1 Ch. Audio In

Built-in Micro SD card slot up to 256GB

CMS / Web Browser / Mobile (iOS/Android)

Internet Explorer, Chrome and Firefox with IE Tab

ONVIF

IP67

12VDC / PoE

350mA (LEDs Off) / 600mA (LEDs On)

< 9.5W

-22° ~140° / < 95% Humidity

24.34oz / 1.52lb (690g)

8.68 × 3.15 × 2.78” (220.5 × 80.1 × 70.5mm)

SPECIFICATIONS

*Please research local, state and federal laws regarding the

implementation of audio surveillance.

KEY FEATURES

• 1/3” 4.0 Megapixel CMOS Image Sensor

• Up to 30fps @ 4 MegaPixel (2592 × 1520)

• 2.8~12mm Motorized Varifocal Lens

• 2 Matrix IRs (up to 165’ IR Range)

• True Wide Dynamic Range

• True Mechanical Day/Night function by ICR

• 3D-DNR (Digital Noise Reduction)

• Fully Programmable Intelligent Analytics: Face Detection, Target

Counting, Intrusion, Region Entrance / Exit, Line Crossing, Scene

Change, Video Blur

• 1 Channel Audio In*

• Smart H.265 / H.265+ / H.265 / Smart H.264 / H.264+ / H.264 / MJPEG

• Remote Viewing via CMS, Internet Explorer, and iOS & Android Apps

• ONVIF Compliant

• MicroSD Card Slot for Local Recording (256GB)

• IP67 Weather Resistance + IK10 Impact

• Wall Mount Included and Optional Junction Box (VT-TJB08) Available

• 12VDC & PoE (Power over Ethernet) Operation

• Available in Ivory or Charcoal Grey (VTC-TNB4RMA3B)

• 3-Year Warranty

MOUNTS

RECORDERS

Pair with VITEK Transcendent Series

Network Recorders VT-TNR818PF,

VT-TNR1646PF, and VT-TNR3216PF

with Built-in PoE and Advanced

Analytics including Face Detection.

(888) VITEK-70 | WWW.VITEKCCTV.COM

28492 Constellation Road Valencia, CA

VT-TJB08/B

Optional Junction Box

for Cable Management

VT-TPLMT

Universal Pole

Mount - Ivory,

reqs. VT-TJB08

VT-TCNMT

Universal Corner

Mount - Ivory, reqs.

VT-TJB08
