Vivotek AW-GEV-104B-130 Bruksanvisning

Vivotek ej kategoriserat AW-GEV-104B-130

Läs gratis den bruksanvisning för Vivotek AW-GEV-104B-130 (297 sidor) i kategorin ej kategoriserat. Guiden har ansetts hjälpsam av 5 personer och har ett genomsnittsbetyg på 4.7 stjärnor baserat på 3 recensioner. Har du en fråga om Vivotek AW-GEV-104B-130 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/297

AW-GEV-104B-130

AW-GEV-184B-250

AW-GEV-264B-370

VivoCam Web Smart Managed PoE Switch

User Manual

trademarks of their respective companies

About This Manual

The products and programs described in this User Guide are licensed products of Manufacture

Technology, This User Guide contains proprietary information protected by copyright, and this User

Guide and all accompanying hardware, software and documentation are copyrighted. No parts of

this User Guide may be copied, photocopied, reproduced, translated or reduced to any electronic

medium or machine-readable from by any means by electronic or mechanical. Including

photocopying, recording, or information storage and retrieval systems, for any purpose other than

the purchaser’s personal use, and without the prior express written permission of Manufacture

Technology.

Purpose

This GUI user guide gives specific information on how to operate and use the management

functions of the WEB SMART SERIES via HTTP/HTTPs web browser

Audience

The Manual is intended for use by network administrators who are responsible for operating and

maintaining network equipment; consequently, it assumes a basic working knowledge of general

switch functions, the Internet Protocol (IP), and Hypertext Transfer Protocol (HTTP).

CONVENTIONS

The following conventions are used throughout this manual to show information.

WARRANTY

See the Customer Support/ Warranty booklet included with the product. A copy of the specific

warranty terms applicable to your Manufacture products and replacement parts can be obtained

from your Manufacture Sales and Service Office authorized dealer.

Disclaimer

Manufacture Technology does not warrant that the hardware will work properly in all

environments and applications, and marks no warranty and representation, either implied or

expressed, with respect to the quality, performance, merchantability, or fitness for a particular

purpose. Manufacture disclaims liability for any inaccuracies or omissions that may have occurred.

Information in this User Guide is subject to change without notice and does not represent a

commitment on the part of Manufacture. Manufacture assumes no responsibility for any

inaccuracies that may be contained in this User Guide. Manufacture makes no commitment to

update or keep current the information in this User Guide, and reserves the righter to make

improvements to this User Guide and /or to the products described in this User Guide, at any

time without notice.

Produktspecifikationer

Varumärke:	Vivotek
Kategori:	ej kategoriserat
Modell:	AW-GEV-104B-130
Vikt:	1950 g
Bredd:	220 mm
Djup:	242 mm
Höjd:	44 mm
LED-indikatorer:	Ja
Snabbstartsguide:	Ja
Lösenordsskydd:	Ja
Strömförbrukning (max):	150 W
Certifiering:	CE, FCC, LVD, VCCI, C-Tick
Återställningsknapp:	Ja
Antal VLAN:	4096
Portspegling:	Ja
Full duplex:	Ja
DHCP-funktioner:	DHCP server, DHCP snooping, DHCP relay, DHCP client
Kabeltyper som stöds:	Cat5, Cat5e
Autentiseringstyp:	RADIUS
Autentisering:	Guest VLAN, MAC-based authentication, Port-based authentication
GARP VLAN Registration Protocol (GVRP):	Ja
Produktens färg:	Svart
bruksanvisning:	Ja
Formfaktor:	1U
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Strömförbrukning (vanlig):	150 W
Total Power over Ethernet (PoE)-budget:	130 W
Power over Ethernet (PoE)-effekt per port:	30 W
Temperatur vid drift:	0 - 50 ° C
Temperaturintervall (förvaring):	-20 - 70 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
VLAN-stöd:	Ja
AC-inspänning:	100 - 240 V
Kryptering/säkerhet:	802.1x RADIUS, SSL/TLS
Kabel inkluderad:	AC
Växelström Frekvens:	50 - 60 hz
Rackmonteringssats:	Ja
Webbaserad adminstraion:	Ja
Lednings Protokoll:	SNMP (v1, v2c, v3)
Kommunikationsstandarder:	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z
Stöd för garanterad tjänstekvalitet (QoS):	Ja
VLAN-funktioner:	Multicast VLAN, Stacked VLAN, Private VLAN, Voice VLAN, VLAN mapping, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN, IP subnet–based VLAN
IGMP-snooping:	Ja
Överföringsbegränsning:	Ja
Multicast-stöd:	Ja
Adresstabellstorlek:	8190 poster
Jumboramar:	10000
Jumbo Frames stöd:	Ja
Switch kapacitet:	20 Gbit/s
Broadcast Storm-kontroll:	Ja
STP (Spanning Tree Protocol):	Ja
10G stöd:	Nej
Antal grundläggande RJ-45 Ethernet-portar:	8
Typ av grundläggande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Switch typ:	hanterad
Länkaggregering:	Ja
Antal SFP-modulplatser:	2
Multicast listener discovery (MLD)-snooping:	Ja
Antal Gigabit Ethernet (koppar)-portar:	8
Power over Ethernet (PoE)-portar kvantitet:	8
Antalet köer:	8
Koppar Ethernet-kablar teknik:	10BASE-T, 100BASE-TX, 1000BASE-T
Algoritmer för schemaläggning av köer:	WFQ, SP, Weighted Round Robin (WRR)
Stöd för automatisk inlärning av MAC-adresser:	Ja
Stöd för automatiskt åldrande av MAC-adresser:	Ja
CD med drivrutiner:	Ja
