Sida 1/11
RIFLESCOPE
Razor® HD GEN III
PRODUCT MANUAL
R
2
Waterproof IPX7
Fogproof Argon gas purged
Length 10.1" (256.5mm)
Mounting Length 4.5" (114.3mm)
Weight 21.5 oz. (w/o battery)
Eye Relief 3.32" (84.3mm)
Field of View 1x magnification: 116' @ 100 yds. (22°)
10x magnification: 11.7' @ 100 yds. (2.23°)
Battery CR2032
SPECIFICATIONS
3.4" / 86.36mm 2.5" / 63.5mm
1.33" /
34mm
1.81" /
46mm
2.0" / 50.8mm
10.1" / 256.5mm
(Front Mounting Length)
(Tube
Diameter)
(Eyepiece) (Rear Mounting Length)
R
4
UNDERSTANDING THE RIFLESCOPE
Reticle Focal Plane
All riflescope reticles can be termed either first focal plane (FFP) or
second focal plane (SFP), depending upon the reticle’s internal location
within the riflescope. This riflescope features a first focal plane reticle.
First Focal Plane Reticles
FFP reticles are located within the riflescope near the windage and
elevation turrets in front of the image-erecting and magnifying lenses.
This style of reticle will visually grow and shrink as you change the
magnification. The advantage of an FFP reticle is that the reticle
subtensions used for ranging, holdovers, and wind drift corrections
are consistent at all magnifications. Usually, the reticle will appear
heavier at higher magnifications and finer at lower magnifications.
Low magnification
example of EBR-9C MRAD Reticle
High magnification
example of EBR-9C MRAD Reticle
