ERA / EBD ELECTRIC FRYER
See GENERAL section for a complete listing of Models
and ML Numbers.
1ER50-Series
1ER85-Series
2ER50-Series
2ER85-Series
2XER50-Series
2XER85-Series
3ER50-Series
3E85-Series
3ER85-Series
4E50-Series
4ER50-Series
4E85-Series
4ER-Series
- NOTICE -
This Manual is prepared for the use of trained Hobart Service Technicians and should not
be used by those not properly qualified.
This manual is not intended to be all encompassing. If you have not attended a Hobart Service
School for this product, you should read, in its entirety, the repair procedure you wish to
perform to determine if you have the necessary tools, instruments and skills required to
perform the procedure. Procedures for which you do not have the necessary tools,
instruments and skills should be performed by a trained Hobart Service Technician.
The reproduction, transfer, sale or other use of this manual, without the express written
consent of Hobart, is prohibited.
This manual has been provided to you by ITW Food Equipment Group LLC ("ITW FEG")
without charge and remains the property of ITW FEG, and by accepting this manual you agree
that you will return it to ITW FEG promptly upon its request for such return at any time in the
future.
SERVICE MANUAL
A product of Vulcan-Hart 3600 North Point Blvd Baltimore, MD 21222
F25385 (1220)

TABLE OF CONTENTS
Service Updates ............................................................................................ 3
TIS DOCUMENT LIST - ERA/EBD ELECTRIC FRYER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
SERVICE UPDATES ................................................................................... 3
GENERAL .................................................................................................. 4
INTRODUCTION ....................................................................................... 4
SINGLE FLOOR MODEL FRYERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
KLEENSCREEN FILTRATION SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SPECIFICATIONS ...................................................................................... 4
TOOLS ................................................................................................. 5
MODELS AND ML NUMBERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
REMOVAL AND REPLACMENT OF PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
COVERS AND PANELS ................................................................................ 7
COOKING CONTROLS ................................................................................. 8
DISCARD VALVE SWITCH (KLEENSCREEN FRYERS ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TEMPERATURE PROBE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
HIGH LIMIT THERMOSTAT ............................................................................ 9
ELECTRICAL COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
CIRCUIT BREAKER / SUPPLY BOX COMPONENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
FILL SOLENOID VALVE (KLEENSCREEN FRYERS ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
HEATING ELEMENTS ................................................................................ 11
LIFT ASSIST SPRINGS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TILT SWITCH ......................................................................................... 13
PUMP AND MOTOR (KLEENSCREEN FRYERS ONLY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
SERVICE PROCEDURES AND ADJUSTMENTS ........................................................... 15
TEMPERATURE PROBE TEST ....................................................................... 15
COOKING CONTROL CALIBRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
LIFT ASSIST SPRING ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
HEATING ELEMENT TEST ............................................................................ 17
ELECTRICAL OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
COMPONENT FUNCTION ............................................................................ 18
COMPONENT LOCATION ............................................................................. 19
SEQUENCE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
SCHEMATIC DIAGRAMS ............................................................................. 23
WIRING DIAGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
ALL MODELS ......................................................................................... 47
FRYMATE (DUMP STATION) WITH OPTIONAL HEATER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
KLEENSCREEN FILTERING SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
ERA / EBD ELECTRIC FRYER
© VULCAN 2020
F25385 (1220) Page 2 of 49

Service Updates
TIS DOCUMENT LIST - ERA/EBD ELECTRIC FRYER
SERVICE TAB
Document Title Document Type
ERA/EBD Service Manual Service Manual
DVI SWITCH MALFUNCTION ON FRYERS WITH OR
WITHOUT KLEENSCREEN PLUS FILTERING
SYSTEMS
Technical Service Instructions (TSI)
SERVICE TAB (Multimedia)
Document Title Document Type
Repair Flood-Damaged Equipment Misc
ERD & ERC Series Electric Fryers With Kleenscreen Plus Filteration
Systems (05/15) Operator
Fryer Computer Control Guide Operator
Fryer Computer Control Guide Service Instructions
Hobart Gas & Electric Fryers Computer Controller Kits Part No. 913012-1
& 913012-4 Service Instructions
ER Series Electric Fryers With Tridelta Controls Service Manual
ERA & EBD Series Electric Fryers With Kleenscreen Plus Filtration
Systems Service Manual
Rating Plate Locations on Current Vulcan-Hart/Wolf Range Equipment TSB
SB900 GR/ER Series Fryers Filtering System Oil Returen Line Solenoid
Valve Leak TSB
TSB 1037A Hobart to Vulcan "Common" MOdel Cross Reference List TSB
HG/HF & GR/ER Series Filtering System Fryer Batteries with Solid State
(D Series) or Computer Controls (Series) - Oil Return Line Solenoid Valve
Leak
TSI
PARTS TAB
Document Title Document Type
ER Series Parts Catalog Parts Catalog
DIAGRAMS TAB
Document Title Document Type
HGC5, DGC5, VC4G, WKGD Series Wiring Diagram
SERVICE UPDATES
December 2020
• Added 15 diagrams to WIRING DIAGRAMS
section.
ERA / EBD ELECTRIC FRYER - Service Updates
Page 3 of 49 F25385 (1220)

GENERAL
INTRODUCTION
This Service Manual covers specific service
information related to the models listed on the front
cover. ERA and EBD series electric fryers come
equipped with behind-the-door solid state controls.
The features and operation of the cooking controls are
the same for both single floor model fryers and
Kleenscreen battery fryers. All pictures and
illustrations are of a 2ER50AF (17kW, 208V) unless
otherwise noted.
SINGLE FLOOR MODEL FRYERS
Fryers with the Filter-Ready option installed, use the
Mobile Filter. For service information related to the
Mobile filter refer to F24599 MOBILE FILTERS. A
GRO Frymate (dump station) can be configured in a
battery with fryers 15½ inches or 21 inches in width.
Model KILOWATT EACH FRY
TANK
FRYER WIDTH (INCHES)
TOTAL SYSTEM
SHORTENING CAPACITY
(LBS) EACH FRY TANK
1ER50A (1E50BD) 17 15.5 50
1ER50AF (1E50BDF) 17 15.5 50
1ER85A (1E85BD) 24 21.0 85
1ER85AF (1E65BDF) 24 21.0 85
2ER50AF (2E50BDF) 17 31.0 50
2ER85AF (2E85BDF) 24 42.0 85
2XER50AF (2XE50BDF) 17 31.0 50
2XER85AF (2E85BDF) 24 42.0 85
3ER50AF (3E50BDF) 17 46.5 50
3ER85AF (3E85BDF) 24 63.0 85
4ER50AF (4E50BDF) 17 62.0 50
4ER85AF 4E85BDF) 24 84.0 85
KLEENSCREEN FILTRATION
SYSTEM
The Kleenscreen filtration system is integrated into the
ERA & EBD Series fryer battery. The filter is housed
in a pull-out drawer assembly at the base of the fryer.
The filtering components in the drawer include a
stainless steel filter tank, crumb-catch basket and a
dual element mesh filter screen. With the filter drawer
closed, a self-seating oil return line provides the path
to return the filtered shortening to the fry tank.
This system is designed to provide a thorough and
easy method to filter the shortening.
Some of the benefits include:
• Self-contained system eliminating the use of
external filter equipment.
• Paperless filtering system.
• Easy to clean and low maintenance.
Kleenscreen fryer batteries are available in a
minimum of two and a maximum of four fryer sections.
The fryer size of each section is identical.
A GRO Frymate (dump station) can also be included
as one or more of the sections.
SPECIFICATIONS
MODEL
KW PER
FRYER
SECTION
AMPS - EACH FRYER
SECTION
(3 PHASE/ 60HZ)*
PER LINE
208V 240V 480V
ALL 50 LB
CAPACITY
FRYERS
14 39 34 17
17 47 41 20
ERA / EBD ELECTRIC FRYER - GENERAL
F25385 (1220) Page 4 of 49

MODEL
KW PER
FRYER
SECTION
AMPS - EACH FRYER
SECTION
(3 PHASE/ 60HZ)*
PER LINE
208V 240V 480V
ALL 85 LB
CAPACITY
FRYERS
24 67 58 29
NOTES: * Amperage values in the table are
nominal. Tolerance is +5/-10%.
Single Floor Model Fryers
• 208VAC, 240VAC or 480VAC (3 phase, 60HZ) to
power the heating elements.
Drawer Filter System
Separate electrical connections are required for
each section of the battery.
• 208VAC, 240VAC or 480VAC (3 phase, 60HZ) to
power the heating elements.
• On 208VAC and 240VAC models, a transformer
provides power for the fryer controls and drawer
filter system controls.
• On 480VAC models, a 120VAC connection is
required for each fryer section.
TOOLS
Standard
• Standard set of hand tools.
• VOM with minimum of NFPA-70E CATIII 600V,
UL/CSA/TUV listed. Sensitivity of at least 20,000
ohms per volt and the ability to measure DC
micro amps. Meter leads must also be rated at
CAT III 600V.
• Digital temperature tester (thermocouple type).
Special
• Electrostatic Discharge Kit.
• Burndy pin extraction tool RX2025 GE1; Newark
Electronics Catalog Number 16F6666. Used for
removing pin terminals on Burndy connectors.
• Clamp on type amp meter with minimum of
NFPA-70E CAT III 600V,UL/CSA/TUV listed.
MODELS AND ML NUMBERS
The following table contains a complete listing of fryer
models addressed by this Service Manual.
Model ML Number
1ER50A ML-136730
1E50BD
1ER50AF ML-136799
1E50BDF
1ER85A ML-136740
1E85BD
1ER85AF ML-136802
1E85BDF
2ER50AF ML-136741
2E50BDF
2ER85AF ML-136742
2E85BDF
2XER50AF ML-136747
2XE50BDF
3ER50AF ML-136743
3E50BDF
3ER85AF ML-136744
3E85BDF
ERA / EBD ELECTRIC FRYER - GENERAL
Page 5 of 49 F25385 (1220)

Model ML Number
4ER50AF ML-136745
4E50BDF
4ER85AF ML-136746
4E85BDF
ERA / EBD ELECTRIC FRYER - GENERAL
F25385 (1220) Page 6 of 49
